Volkswagen Amarok II (2022 – 2024) – fuses and relay box diagram
Year of production: 2022, 2023, 2024
This article covers the second-generation Volkswagen Amarok, which has been available since 2022. Inside, you will find fuse box diagrams for the 2022, 2023 and 2024 Volkswagen Amarok, along with details on the locations of the fuse panels within the vehicle and the functions of each fuse (fuse layout).
Assignment of the fuses and relays in the instrument panel
№
Amps
Function / component
SC2
10A
Driver side interior locking button for central locking system
Front passenger side interior locking button for central locking system
DC/AC converter with socket, 12V – 230V
Operating unit for window regulator in driver door
SC3
7.5A
Charging unit 1 for mobile devices (Wireless)
SC4
–
–
SC5
–
–
SC6
10A
Anti-theft alarm system horn
Battery backup sounder
SC7
–
–
SC8
5A
Emergency call module control unit and communication unit
SC9
5A
Interior monitor send and receive module 1
SC10
–
–
SC11
–
–
SC12
7.5A
Data bus diagnostic interface
Selector lever
Heater and air conditioning system control unit
SC13
7.5A
Steering column electronics control unit
Dash panel insert
SC14
–
–
SC15
15A
Multimedia system control unit
Diagnostic connection
SC16
–
–
SC17
7.5A
Control unit for cornering light and headlight range control
Control unit for reducing agent metering system
Trailer brake switch
SC18
7.5A
Relay and fuse carrier A for special vehicles
Auxiliary switch
Tachograph
SC19
5A
Operating unit for lighting (Headlamp switch pack)
SC20
5A
Ignition/starter switch
Starter button
SC21
–
–
SC22
–
–
SC23
–
–
SC24
–
–
SC25
–
–
SC26
–
–
SC27
–
–
SC28
–
–
SC29
15A
Display unit for front information display and operating unit control unit
Tachograph
SC30
5A
Brake switch
SC31
10A
Centre operating unit for dash panel
Switch module 1 in centre console
Entry and start authorisation control unit
SC32
20A
Radio
SC33
–
–
SC34
30A
Run/start relay
Fuse 17 on fuse holder C
Fuse 18 on fuse holder C
Fuse 36 on fuse holder C
Fuse 37 on fuse holder C
SC35
–
–
SC36
15A
Parking aid control unit
Rear seat module
SC37
20A
Steering column electronics control unit
Heatedsteering wheel
Automatic anti-dazzle interior mirror
Assignment of the fuses in the engine compartment (-SB-/-SX1-)
№
Amps
Function / component
SB1
30A
Onboard supply control unit (BCM 1)
SB2
20A
Heater element for crankcase breather (Diesel 2.0L)
SB3
30A
Onboard supply control unit (BCM 2)
SB4
30A
Fuel pump control unit
Fuse 120 on fuse holder B
SB6
25A
Engine/motor control unit
SB7
30A
Charge pressure control solenoid valve 2 (Diesel 2.0L, 3.0L)
Turbine changeover valve (Diesel 2.0L, 3.0L)
Exhaust gas recirculation cooling bypass valve (Diesel 2.0L, 3.0L)
Camshaft control valve 1 (Petrol)
Exhaust camshaft control valve 1 (Petrol)
Lambda probe 1 before catalytic converter (Petrol)
Lambda probe 1 after catalytic converter (Petrol)
Activated charcoal filter solenoid valve 1 (Petrol)
SB8
20A
Radiator blind control motor 2
Radiator fan relay
Radiator fan 2 relay
Valve for oil pressure control
Heater element for crankcase-breather (Diesel 3.0L)
Air conditioner compressor
Turbocharger air recirculation valve (Petrol)
SB9
20A
Control unit for NOx sender (Diesel 2.0L, 3.0L)
Control unit 2 for NOx sender (Diesel 2.0L, 3.0L)
Control unit 3 for NOx sender (Diesel 2.0L, 3.0L)
Control unit 1 for particulate sensor (Diesel 2.0L)
Glow plug relay (Diesel 2.0L, 3.0L)
Automatic glow period control unit (Diesel 2.0L, 3.0L)
Onboard supply control unit 2
60-pin electrical connector Pin 23
Ignition coil 1~4 with output stage (Petrol)
4×4 relay coil
Turbocharger surge valve (Petrol)
Oil pump solenoid (Petrol)
Engine coolant bypass valve (Petrol)
SB10
20A
Fuel pressure regulating valve (Diesel 3.0L)
Fuel metering valve (Diesel 3.0L)
Automatic gearbox control unit
SB13
40A
Fresh air blower control unit
SB18
30A
Starter
SB21
10A
Automatic headlamp levelling
Front left headlight
Front right headlight
SB23
10A
ABS control unit
SB24
10A
Automatic glow period control unit (Diesel 2.0L, 3.0L)
Power steering control unit
Engine/motor control unit
SB25
20A
All-wheel drive control unit
Reversing camera
Driveline control module
SB26
15A
Automatic gearbox control unit
Auxiliary hydraulic pump 1 for gearbox oil
SB28
60A
ABS control unit
SB29
60A
ABS control unit
SB30
40A
Operating unit for front left seat adjustment (LHD)
Operating unit for front right seat adjustment (RHD)
SB31
40A
Operating unit for front right seat adjustment (LHD)
Operating unit for front left seat adjustment (RHD)
SB32
20A
12V socket (first row)
SB33
20A
12V socket 2 (rear console)
SB34
20A
Rear cargo power outlet – bedliner power point
SB36
60A
DC/AC converter without socket, 12V – 230V
SB38
30A
Heater and air conditioning system control unit
SB42
30A
Trailer detector control unit
SB44
10A
Brake light switch
SB48
30A
Rear heated seat module – right
SB50
40A
Heated rear window
SB53
15A
Differential lock valve 1
SB54
40A
Driveline control module
SB55
30A
Trailer tow park lamp
SB58
15A
Trailer tow backup lamp
SB64
40A
All-wheel drive control unit
SB68
20A
Control unit for electronic steering column lock
SB69
30A
Windscreen wiper
SB78
50A
Heated windscreen: Right heating circuit
SB79
50A
Heated windscreen: Left heating circuit
SB83
50A
Auxiliary heater (Diesel 3.0L)
SB84
50A
Auxiliary heater (Diesel 3.0L)
SB85
50A
Auxiliary heater (Diesel 3.0L)
SB86
15A
Control unit for reducing agent metering system
Automatic glow period control unit
Selective catalytic reduction system heater 2 (Diesel 2.0L, 3.0L)
SB91
40A
Trailer detector control unit
SB92
10A
Accessory
SB93
5A
Remote control receiver for auxiliary heater
SB94
20A
Auxiliary heater control unit
SB100
20A
Front left headlight
SB101
20A
Front right headlight
SB107
30A
Trailer detector control unit
SB109
20A
Digital sound package control unit
Amplifier
SB110
30A
Trailer socket
SB112
5A
Remote control receiver for auxiliary heater
SB113
20A
Auxiliary heater control unit
SB115
30A
Control unit fa|r HD ad area roller blind
SB120
10A
Onboard supply control unit 2
60-pin connector Pin 20
Fuse 121 on fuse holder B
Fuel filter heater relay
Water in fuel heater relay coils (Diesel)
SB121
40A
Fuel filter heater module (Diesel 2.0L, 3.0L)
SB122
30A
Onboard supply control unit 2
Transfer box control motor
SB124
5A
Rain sensor
SB136
30A
Rear heated seat module – left
SB137
20A
Driver assist systems control unit
SB140
5A
USB connection 2 (rear console)
SB141
5A
USB charging socket in headlining
SB179
15A
Control unit for reducing agent metering system (Diesel)
SB180
10A
Control unit for reducing agent metering system (Diesel)
SB182
60A
Front passenger door control unit (LHD)
Driver door control unit (RHD)
SB183
60A
Driver door control unit (LHD)
Front passenger door control unit (RHD)
SB202
60A
Onboard supply control unit (Body control module B+)
SB210
30A
Onboard supply control unit (Body control module start-stop)
Audi Q4 e-tron (2022 – 2024) – fuse and relay box diagram
Year of production: 2022, 2023, 2024
The Audi Q4 e-tron, a battery-electric compact luxury crossover, has been available since 2022. In this article, you will find fuse box diagrams for the 2022, 2023 and 2024 Audi Q4 e-tron, along with information on the locations of the fuse panels within the vehicle and details about the function of each fuse (fuse layout) and relay.
Passenger compartment
Fuse Box Location
The fuses are located on the left side of the cockpit, behind a cover.(1- LHD, 2-RHD)
Audi Q4 e-tron (2022 – 2024) – fuse and relay location – passenger compartment
Fuse Box Diagram (-SC-)
Audi Q4 e-tron (2022 – 2024) – fuse and relay diagram – passenger compartment
Assignment of the fuses and relays in the instrument panel (holder C)
№
Amps
Function/Component
SC1
–
SC2
7.5A
Airbag Control Module
SC3
25A
Towing Recognition Control Module
SC4
7.5A
Driver assistance systems front camera
SC5
25A
Vehicle Electrical System Control Module
Left Taillight
SC6
30A
Vehicle Electrical System Control Module
Interior Lighting
SC7
30A
Heating and Air Conditioning Control Module
Seat Heating
SC8
30A
Roof System Control Module
SC9
30A
Driver’s Door Control Module (LHD)
Front Passenger’s Door Control Module (RHD)
Rear Door Control Module, Driver’s Side (LHD)
Rear Front Passenger’s Door Control Module (RHD)
SC10
Left/center Tail Light
SC11
15A
Towing Recognition Control Module
SC12
–
–
SC13
40A
Vehicle Electrical System Control Module
Central Locking
Windshield Washer System
SC14
40A
Digital Sound System Control Module
SC15
–
–
SC16
Power Supply for Measuring Lead Set
SC17
5A
Parking Aid Control Module
Lane Change Assistance Control Module
Lane Change Assistance Control Module 2
Toll registration sensor (from 07.2022)
Exterior Mirrors
SC18
5A
Power rear lid opener sensor
Access/start authorization control module
Electronic Steering Column Lock Control Module
Rear lid opener control module
Burglary Protection Control Module 2
Burglary Protection Control Module 3
Burglary Protection Control Module 4
Burglary Protection Control Module 5
Engine Sound Generator Module 2
SC19
5A
Control module for emergency call module and communication unit
Instrument Cluster
SC20
7.5A
TV Tuner (from 11.2021)
Amplifier for Telephone
USB Connection 1
Chip Card Reader Control Module (from 11.2021, Japan)
Mobile Device Charger 1
Android Operating System Control Module (through 07.2022)
SC21
7.5A
Rear Peripheral Camera
Peripheral Camera Control Module
Luggage Compartment Lid Release
SC22
15A
Engine Control Module (ECM)
SC23
5A
Internet access control module (through 07.2022)
SC24
Right/center Tail Light
SC25
25A
Left Front Seat Belt
SC26
30A
Driver’s Door Control Module (RHD)
Front Passenger’s Door Control Module (LHD)
Rear Door Control Module, Driver’s Side (RHD)
Rear Front Passenger’s Door Control Module (LHD)
SC27
25A
Right Front Seat Belt
SC28
10A
High voltage battery 1
High Voltage System Maintenance Connector
SC29
15A
Towing Recognition Control Module
SC30
20A
Control Module for Information Electronics 1
Infotainment System
SC31
25A
Towing Recognition Control Module
SC32
25A
Vehicle Electrical System Control Module
Right Tail Light
SC33
–
–
SC34
15A
Heating and Air Conditioning Control Module
SC35
–
–
SC36
40A
Fresh Air Blower Control Module
SC37
30A
Rear Lid Control Module
SC38
–
–
SC39
10A
Steering Column Electronic Systems Control Module
SC40
10A
Alarm Horn
SC41
5A
Data Bus On Board Diagnostic Interface
SC42
7.5A
Garage Door Opener Control Module
Selector Lever
SC43
7.5A
Front A/C display control head
Vehicle Interior Carbon Dioxide Concentration Sensor
Vehicle Interior Temperature Sensor
Rear window defogger relay
SC44
7.5A
Control unit 1 for driving and convenience functions
lllumination Control Head
Rain/Light Recognition Sensor
Anti-Theft Alarm System Sensor
Diagnostic connection
Rear Interior Lamp
Front roof module
SC45
5A
Steering Column Electronic Systems Control Module
SC46
7.5A
Front Information Display Control Head
Driver Volume Control
Windshield Projection Head Up Display Control Module
Electric Drive Power and Control Electronics
Electric Drive Power and Control Electronics 2
SC62
–
–
SC63
–
–
SC64
–
–
SC65
–
–
SC66
15A
Rear Window Wiper Motor
SC67
10A
Rear Window Defogger
A
30A
US: Electric trailer brake position sensor
A
15A
Revolving roof lamp and siren control module
Driving School Operation Relay
Driving Assistance Control Unit Control Module
Mobile two-way radio charging socket
Mobile two-way radio charging socket 2
B
10A
Special Signals Control Head
Driving Assistance Control Unit Control Module
C
15A
LHD:
Driver’s Seat Adjustment Control Head
Memory Seat/Steering Column Adjustment Control Module
Driver seat switch module
RHD:
Driver’s Seat Adjustment Control Head
Memory Seat/Steering Column Adjustment Control Module
Driver seat switch module
D
15A
LHD:
Front Passenger’s Seat Adjustment Control Head
Front passenger seat switch module
RHD:
Driver’s Seat Adjustment Control Head
Memory Seat/Steering Column Adjustment Control Module
Driver seat switch module
R1
Sockets Relay
R2
Terminal 15 power supply relay
R3
Rear window defogger relay
Engine Compartment Fuse Box
Fuse Box Location
Audi Q4 e-tron (2022 – 2024) – fuse and relay location – engine compartment
Fuse Box Diagram (-SB-)
Audi Q4 e-tron (2022 – 2024) – fuse and relay diagram – engine compartment (holder B)
Assignment of the fuses in the engine compartment (holder B)
№
Amps
Function/Component
SB1
–
–
SB2
7.5A
ABS Control Module
ESC Control Module
Electromechanical Steering
Main Relay
SB3
10A
Voltage Converter
High voltage battery charger 1
Electric Drive Power and Control Electronics
Electric Drive Power and Control Electronics 2
SB4
30A
Front Left Headlamp
SB5
30A
Front Right Headlamp
SB6
7.5A
Distance Regulation Control Module
SB7
–
–
SB8
–
–
SB9
15A
Horn Relay
SB10
30A
Wiper Motor Control Module
SB11
7.5A
A/C Relay
Air Quality Sensor
Ionizer
SB12
7.5A
Engine Sound Generator Module 1
SB13
25A
ABS Control Module
ESC Control Module
SB14
–
–
SB15
40A
ABS Control Module
ESC Control Module
SB16
50A
Radiator Fan
SB17
30A/40A
Through 11.2021; from 07.2022: Windshield Defogger
SB18
30A
11.2021-07.2022: Windshield Defogger
SB19
–
–
SB20
–
–
SB21
–
–
SB22
–
–
SB23
10A
Engine Control Module (ECM)
SB24
5A
Radiator Fan
SB25
10A/15A
High voltage battery coolant pump
Heating Element (PTC) 3
SB26
10A/15A
Low Temperature Circuit Coolant Pump
Radiator Blind Adjustment Motor
SB27
–
–
SB28
–
–
SB29
–
–
SB30
–
–
SB31
–
–
SB32
50A
Brake booster
R1
Main Relay
R2
Windshield Heater Relay
R3
Horn Relay
R4
–
R5
–
R6
A/C Relay
Fuse Panel A (-SA-)
Audi Q4 e-tron (2022 – 2024) – fuse and relay diagram – engine compartment (holder A)
Assignment of the fuses in the engine compartment (holder A)
№
Amps
Function/Component
508
Battery
SA1
350A
Voltage Converter
SA2
80A
Battery Monitoring Control Module
Power Steering Control Module
SA3
100A
Fuse Panel C -SC-
SA4
100A
Fuse Panel C -SC-
SA5
–
–
SA6
125A
Fuse Panel B -SB-
WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
Year of production: 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999
The Volkswagen Vento A3, (the third generation of the Volkswagen Vento), was a compact family car produced from 1992 to 1999. In this article, you will find fuse box diagrams for Volkswagen Vento models from 1992 to 1999, along with details on the fuse panel locations inside the vehicle and the specific functions of each fuse (fuse layout) and relay.
Passenger compartment
Fuse Box Location
It is located under the dashboard on the driver’s side. Press down on the latches and remove the cover to access the fuses.
Year of production: 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999
The Volkswagen Jetta A3, (the third generation of the Volkswagen Jetta), was a compact family car produced from 1992 to 1999. In this article, you will find fuse box diagrams for Volkswagen Jetta models from 1992 to 1999, along with details on the fuse panel locations inside the vehicle and the specific functions of each fuse (fuse layout) and relay.
Passenger compartment
Fuse Box Location
It is located under the dashboard on the driver’s side. Press down on the latches and remove the cover to access the fuses.
This article focuses on the seventh-generation Volkswagen Jetta (A7), produced from 2019 to the present. It includes fuse box diagrams for the facelifted 2022, 2023 and 2024 Volkswagen Jetta A7 models, details on the location of the fuse panels inside the vehicle, and an overview of the fuse assignments (fuse layout) and relay functions.
Steering Column Electronics Control Module
Ignition/Starter Switch
SC10
7.5A
Front Information Display Control Head
SC11
40A
Vehicle Electrical System Control Module (exterior lighting on the left side)
SC12
20A
Information Electronics Control Module 1
SC13
–
–
SC14
40A
Fresh Air Blower Control Module
SC15
10A
Electronic Steering Column Lock Control Module
SC16
7.5A/10A
Storage Compartment with Cell Phone Interface
USB Charging Socket 1 (from 2023)
USB Connection 1
SC17
7.5A
Instrument Cluster
Control Module for Emergency Call Module and Communication Unit
SC18
7.5A
Rearview Camera
SC19
7.5A
Access/Start System Interface
SC20
15A
Vacuum Pump Relay
SC21
–
–
SC22
–
–
SC23
20A
Sunroof Control Module
SC24
40A
Vehicle Electrical System Control Module (exterior lighting on the right side)
SC25
30A
Driver Door Control Module
Left rear window regulator motor
SC26
30A
Vehicle Electrical System Control Module (seat heating)
SC27
30A
Vehicle Electrical System Control Module (interior lighting)
SC28
–
–
SC29
5A
Refrigerant Circuit Pressure Sensor
SC30
10A
Remote Start System Relay
SC31
–
–
SC32
7.5A
Blind Spot Detection Control Module
Blind Spot Detection Control Module 2
Parking Aid Control Module
Driver Assistance Systems Front Camera
Control Module for Adaptive Cruise Control
SC33
7.5A
Airbag Control Module
Front Passenger Airbag “Disabled” Indicator Lamp
Passenger Occupant Detection System Control Module
SC34
7.5A
Refrigerant Circuit Pressure Sensor
Center console switch module 1
Interior Rearview Mirror
Rotary Light Switch
Back-up lamp switch
Structure borne sound control module
Air Quality Sensor
Rear Seat Heating Control Module
Center Console Switch Module 2
Sockets Relay
Refrigerant Circuit Pressure Sensor
Parking Brake Button
SC35
7.5A
Diagnostic Connection
SC36
–
–
SC37
–
–
SC38
–
–
SC39
30A
Front Passenger Door Control Module
Right Rear Window Regulator Motor
SC40
20A
12V Socket
Sockets Relay
SC41
–
–
SC42
40A
Vehicle Electrical System Control Module (central locking system)
SC43
30A
Digital Sound System Control Module
SC44
–
–
SC45
15A
Left Front Seat Adjustment Control Head
Driver Seat Lumbar Support Adjustment Switch
Left Front Seat Cushion Fan 1
Left Front Seat Backrest Fan 1
Driver Seat Adjustment Control Module
SC46
7.5A
USB Charging Socket 1 (2022)
SC47
–
–
SC48
–
–
SC49
7.5A
Starter Relay 1
Starter Relay 2
Clutch Position Sensor Remote Start System Relay
Remote Start System Relay (2022)
SC50
–
–
SC51
25A
Rear Seat Heating Control Module
Driver Power Seat Adjustment Circuit Breaker 1
SC52
15A
Electronic Damping Control Module
SC53
30A
Rear Window Defogger Relay
R1
Vacuum Pump Relay
R2
A/C Clutch Relay
R3
Windshield Defogger Relay
R4
Terminal 15 Power Supply Relay
R5
Rear Window Defogger Relay
R6
Sockets Relay
F59
15A/30A
2010-2012:
Amplifier
2013-2017:
Fan activation relay (Engine code CNLA)
Battery fan 1 (Engine code CNLA)
F60
30A
Auxiliary heater control module
–
20A
Driver power seat adjustment circuit breaker 1 (it is located above relay carrier)
Individuals fuses
Volkswagen Jetta (A7; 2022 – 2024) – fuse and relay diagram – passenger compartment (Individual fuses)Assignment of the fuses in the Individual fuses
№
Amps
Function / Component
A
–
–
B
15A
Right Front Seat Backrest Fan 1
Right Front Seat Cushion Fan 1
C
7.5A
Passenger Occupant Detection System Control Module
Year of production: 2000, 2001, 2002, 2003, 2004, 2005
This article covers the fourth-generation Volkswagen Jetta (A4, Typ 1J), manufactured from 1999 to 2005. It includes fuse box diagrams for the 2000, 2001, 2002, 2003, 2004, and 2005 models, provides details on the locations of the fuse panels within the vehicle, and explains the function of each fuse (fuse layout) and relay.
Passenger compartment fuse box
Fuse Box Location
The fuse panel is located behind an access panel on left edge of the instrument panel.
Comfort system, cruise control, Climatronic, A/C, heated seat control modules, day/night dimming mirror, control module and control unit for multi-function steering wheel
6
5A
Central locking system
7
10A
Back-up lights, speedometer vehicle speed sensor
8
–
–
9
5A
Anti-lock brakes (ABS)
10
5A/10A
Engine control module (ECM)
11
5A
Instrument cluster, shift lock solenoid
12
7.5A
B+ (battery positive voltage) for Data Link Connector (DLC)
13
10A
Brake lights
14
10A
Interior lights, central locking system
15
5A
Instrument cluster, automatic transmission control module (TCM)
16
10A
A/C clutch, after-run coolant pump
17
–
–
18
10A
High beam right
19
10A
High beam left
20
15A
Low beam right
21
15A
Low beam left
22
5A
Parking and side marker lights, right
23
5A
Parking and side marker lights, left
24
20A
Front wiper motor, washer pump
25
25A
Fresh air blower, Climatronic, A/C
26
25A
Rear window defogger
27
15A
Rear wiper motor
28
15A
Fuel pump, gasoline
29
10A/15A
Engine control module (ECM)
30
20A
Sunroof control module
31
20A
Automatic transmission control module
32
10A/15A
Fuel Injectors (gasoline)
ECM (diesel)
33
20A
Headlight washer system
34
10A
Engine control elements
35
30A
12V power outlet (in luggage comp.)
36
15A
Fog lights
37
10A
Radio terminal 86S, instrument cluster
38
15A
Central locking system (with power windows) luggage compartment light, remote fuel tank door, rear lid unlock
39
15A
Emergency flashers
40
20A
Dual tone horn
41
15A
Cigarette lighter
42
25A
Radio system
43
10A
Engine control elements
44
15A
Heated seats
Relays
Relay Box Location
The relay panel is located under the left side of the instrument panel.
Power windows, central locking, heated power mirrors
D
–
E
–
F
15A
Central locking, anti-theft warning
G
15A
Central locking, anti-theft warning
Engine compartment fuse box
Fuse Box Location
The main fuse box located on top of the battery in the engine compartment. It contains special fuses for high current applications and prevents the main wiring harness in the event of a short circuit.
This article covers the pre-facelift second-generation Volkswagen Tiguan (AD/BW), manufactured from 2016 to 2020. It includes fuse box diagrams for the 2017, 2018, 2019, and 2020 models, details the locations of the fuse panels inside the vehicle, and explains the function of each fuse (fuse layout).
Instrument panel fuse box
Fuse Box Location
Volkswagen Tiguan – fuse and relay location – passenger compartment
Fuse Box Diagram (-SC-)
Volkswagen Tiguan – fuse and relay diagram – passenger compartment (holder C)
Assignment of the fuses in the instrument panel fuse box (fuse holder C-SC-)
№
Amps
Function / Component
SC1
20A
Reducing Agent Heater Control Module
SC2
10A
Steering Column Electronics Control Module
SC3
–
–
SC4
7.5A
Alarm Horn
SC5
7.5A
Remote Start System Relay
Data Bus on Board Diagnostic Interface
SC6
7.5A
AT Selector Mechanism
Ignition Switch Key Lock Solenoid
SC7
10A
Rear A/C Display Control Head
Tire Pressure Monitoring Control Module
Auxiliary Coolant Heater Radio Frequency Receiver
A/C Clutch Relay
Rear Window Defogger Relay
SC8
7.5A
Driving Profile Selection Control Head
Parking brake button
Rain/Light Recognition Sensor
Anti-Theft Alarm System Sensor
Cornering Lamp and Headlamp Range Control Module
Left Rear Door Ambient Lighting Bulb 1
Right Rear Door Ambient Lighting Bulb 1
Left Front Door Ambient Lighting Bulb 1
Right Front Door Ambient Lighting Bulb 1
Diagnostic Connection
SC9
7.5A
Steering Column Electronics Control Module
Ignition/Starter Switch
SC10
7.5A
Front Information Display Control Head
Windshield Projection Head Up Display Control Module
SC11
40A
Vehicle Electrical System Control Module (exterior lighting on the left side)
SC12
20A
Information Electronics Control Module 1
SC13
25A
Left Front Seat Belt Tensioner Control Module
SC14
40A
Fresh Air Blower Control Module
SC15
10A
Electronic Steering Column Lock Control Module
SC16
7.5A/10A
Mobile communication 2-way signal amplifier
USB Connection 1
USB Charging Socket 1 (2023)
Storage Compartment with Cell Phone Interface
SC17
7.5A
Control Module for Emergency Call Module and Communication Unit
Instrument Cluster
SC18
7.5A
Rear Lid Handle
Peripheral Camera Control Module
SC19
7.5A
Access/Start System Interface
SC20
15A/10A
Vacuum Pump Relay
Reducing Agent Metering System Relay
SC21
15A
All Wheel Drive Control Module
SC22
15A
Towing Recognition Control Module
SC23
20A
Sunroof Control Module
SC24
40A
Vehicle Electrical System Control Module (exterior lighting on the right side)
SC25
30A
Driver Door Control Module
SC26
30A
Vehicle Electrical System Control Module (seat heating)
SC27
30A
Vehicle Electrical System Control Module (interior lighting)
SC28
25A
Towing Recognition Control Module (left)
SC29
7.5A
Remote Start System Relay
Refrigerant Circuit Pressure Sensor
SC30
10A
Remote Start System Relay
SC31
30A
Rear Lid Control Module
SC32
7.5A
Parking Aid Control Module
Lane Change Assistance Control Module 2
Driver Assistance Systems Front Camera
Lane Change Assistance Control Module
Control Module for Adaptive Cruise Control
SC33
7.5A
Airbag Control Module
Front Passenger Airbag -Disabled- Indicator Lamp
Engine Component Power Supply Relay (2.0L gasoline)
SB17
7.5A
ABS Control Module
Windshield Defogger Relay
Engine/Motor Control Module
Motronic Engine Control Module Power Supply Relay
Terminal 30 Power Supply Relay
SB18
7.5A
Data Bus on Board Diagnostic Interface (vehicles without parking heater)
Battery Monitoring Control Module (vehicles with parking heater)
SB19
30A
Windshield Wiper Motor
SB20
–
–
SB21
15A
Transmission Control Module
Dual-Clutch Transmission Mechatronic
SB22
7.5A
Engine/Motor Control Module
SB23
30A
Starter
SB24
40A
Auxiliary Heater Heating Element
SB25
–
–
SB26
–
–
SB27
–
–
SB28
–
–
SB29
–
–
SB30
–
–
SB31
–
–
SB32
–
–
SB33
–
–
SB34
10A
Windshield Defogger Relay (4GT)
SB35
–
–
SB36
15A
Left Front Headlamp
SB37
20A
Auxiliary Heater Control Module (vehicles with parking heater)
SB38
15A
Right Front Headlamp
SA1
125A
Supply for Fuses (Passenger Compartment):
Fuse 1 (on fuse panel C)
Fuse 2 (On Fuse Panel C)
Fuse 5 (On Fuse Panel C)
Fuse 14 (On Fuse Panel C)
Fuse 22 (On Fuse Panel C)
Fuse 32 (On Fuse Panel C)
Fuse 42 (On Fuse Panel C)
Fuse 46 (On Fuse Panel C)
Fuse 47 (On Fuse Panel C)
Fuse 49 (On Fuse Panel C)
Fuse 51 (On Fuse Panel C)
Fuse 53 (On Fuse Panel C)
SA2
400A
Generator with Voltage Regulator
508
Battery
SA3
80A
Power Steering Control Module
SA4
80A
Supply for Fuses (Passenger Compartment):
Fuse 3 (On Fuse Panel C)
Fuse 15 (On Fuse Panel C)
Fuse 20 (On Fuse Panel C)
Fuse 23 (On Fuse Panel C)
Fuse 28 (On Fuse Panel C)
Fuse 43 (On Fuse Panel C)
Fuse 45 (On Fuse Panel C)
Fuse 50 (On Fuse Panel C)
SA5
50A
Radiator Fan
R1
Starter Relay 1
R2
Starter Relay 2
R3
Horn Relay
R4
Secondary air injection pump relay (2.0L gasoline)
R5
Motronic Engine Control Module Power Supply Relay (gasoline)
R6
–
R7
–
R8
Engine Component Power Supply Relay
R9
Windshield Defogger Relay
R10
Windshield Defogger Relay
WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
Year of production: 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020
This article covers the second-generation SEAT Alhambra (7N), produced from 2010 to 2020. It includes fuse box diagrams for the 2010–2020 models, provides details on the locations of the fuse panels within the vehicle, and explains the function of each fuse (fuse layout) and relay.
Passenger compartment fuse box
Fuse Box Location
To remove the cover, move the activation lever in the lower part to the right. For right-hand drive vehicles, move the lever to the left.
Seat Alhambra (MK2/7N; 2010 – 2020) – fuse and relay box location – passenger compartment (holder C)
Assignment of the fuses in the instrument panel (Fuse holder C)
№
Amps
Function/component
1
–
not assigned
2
7.5A
2018-2020:
USB connection 1
3
7.5A
2016-2020:
Left washer jet heater element
Right washer jet heater element
4
10A
DC/AC converter with socket, 12V – 230V
Voltage stabiliser
Starter relay 1 (with start-stop)
Starter relay 2 (with start-stop)
5
10A
Electronically controlled damping control unit
6
10A
2015-2020:
Blind Spot Monitor control unit
Blind Spot Monitor control unit 2
7
–
not assigned
8
–
not assigned
9
7.5A
Warning lamp for airbag deactivated on front passenger side
Airbag control unit
10
5A
2013-2020 (taxi):
Taximeter
Mirror taximeter
Voltage stabiliser
Taxi alarm remote control, control unit
11
10A
All-wheel drive control unit
12
10A
Left gas discharge (xenon) bulb
13
5A
2010-2015:
Electromechanical parking brake button
Oil level and oil temperature sender
Reversing light switch
Operating unit in front of centre console
High-pressure sender
Parking aid control unit
Interior mirror
Front camera for driver assist systems
13
5A
2015-2020:
Operating unit in front of centre console
Reversing light switch
High-pressure sender
Trailer detector control unit
Air quality sensor
Adaptive cruise control unit
Parking aid control unit
Park assist steering control unit
Front camera for driver assist systems
Automatic anti-dazzle interior mirror
14
7.5A
2010-2015:
Light switch
Trailer detector control unit
Control unit for electromechanical parking brake
ABS control unit
Brake light switch
Power steering control unit
Engine/motor control unit
Data bus diagnostic interface
Control unit in dash panel insert
14
7.5A
2015-2016:
Light switch
ABS control unit
Control unit in dash panel insert
Trailer detector control unit
Power steering control unit
Data bus diagnostic interface
Engine/motor control unit
14
7.5A
2016-2020:
Light switch
ABS control unit
Control unit in dash panel insert
Operating unit in front of centre console
Power steering control unit
Switch module 2 in centre console
Data bus diagnostic interface
Engine/motor control unit
Electromechanical parking brake button
Oil level and oil temperature sender
15
10A
2010-2015:
Auxiliary heater operation relay
Diagnostic connection
Front left headlight, not xenon
Front right headlight, not xenon
Control unit for cornering light and headlight range control
Switch and instrument illumination regulator
Ar mass meter
15
10A
2015-2020:
Switch and instrument illumination regulator
Control unit for cornering light and headlight range control
Front left headlight, not xenon
Front right headlight, not xenon
Diagnostic connection
16
10A
Right gas discharge (xenon) bulb
17
5A
2010-2015:
Mobile telephone operating electronics control unit
Emergency call module control unit and communication unit
17
5A
2015-2020:
Emergency call module control unit and communication unit (LHD)
18
7.5A
2010-2015:
Taxi alarm remote control, control unit
Data transmission control unit
19
–
not assigned
20
5A
ABS control unit
21
5A
2010-2016:
2nd heat exchanger switch-off valve
21
5A
2016-2020:
Electromechanical parking brake button
Selector lever
22
7.5A
Light switch
Rain and light sensor
Reversing camera system control unit
Diagnostic connection
23
7.5A
2010-2015:
Selector lever sensors control unit
Electromechanical parking brake button
Climatronic control unit
Air conditioning system control unit
Operating and display unit for rear air conditioning system
Rear blower regulation sender
Remote control receiver for auxiliary coolant heater
23
7.5A
2015-2020:
Operating and display unit for rear air conditioning system
Rear blower regulation sender
Climatronic control unit
Remote control receiver for auxiliary coolant heater
2nd heat exchanger switch-off valve (2016-2020)
24
7.5A
Entry and start authorisation control unit
25
7.5A
Selector lever
Mechatronic unit for dual clutch gearbox
2010-2015:
Cigarette lighter
12V socket 2
Onboard supply control unit (T52c/21)
Terminal 75 diagnosis feedback
30
20A
2015:
Cigarette lighter
12V socket 2
30
30A
2015-2020:
Blower relay
31
–
not assigned
32
–
not assigned
33
–
not assigned
34
–
not assigned
35
–
not assigned
36
30A
2010-2015:
Control unit for electromechanical parking brake
36
5A
2015-2016:
Two-way signal amplifier for mobile telephone/data services
Storage compartment with interface for mobile telephone
36
20A
2016-2020:
Control unit 1 for information electronics
36
30A
2020:
Right sliding door control unit
37
10A/25A
2010-2011:
Two-way radio
or
Sliding sunroof adjustment control unit
37
25A
2011-2020:
Sliding sunroof adjustment control unit
38
10A/30A
2010-2011:
Taximeter
Interior light switch
Taxi sign switch
Taxi alarm active button
Mirror taximeter
Front interior light button
or
Sunroof roller blind control unit
38
30A
2011-2020:
Sunroof roller blind control unit
39
5A/7.5A
Steering column electronics control unit
40
5A
2010-2015:
Multimedia system control unit
40
5A
2016-2020:
Two-way signal amplifier for mobile telephone/data services
Storage compartment with interface for mobile telephone
41
5A
Dash panel insert
42
15A
Electronically controlled damping control unit
43
30A
2010-2017:
Driver seat lumbar support adjistment switch
Front passenger seat lumbar support adjistment switch
44
25A/30A
Fresh air blower relay (LHD)
Heated rear window relay
45
30A
Front passenger door control unit
Rear right door control unit
46
30A
Driver door control unit
Rear left door control unit
47
10A
2011-2020 (taxi):
Interior light switch
Taxi sign switch
Taxi alarm active button
Mirror taximeter (2011-2015)
Front interior light button (2013-2015)
48
15A
Alarm horn
Interior monitoring sensor
Onboard supply control unit (T52c/1)
Terminal 30, Anti-theft alarm supply
49
30A
2010-2015:
Control unit for electromechanical parking brake
49
7.5A
2015-2020:
Relay for reducing agent metering system (diesel)
Delivery unit for reducing agent metering system (diesel)
50
30A
Onboard supply control unit (T52b/1)
Terminal 30, central locking supply
51
30A
Heated front seats control unit
52
20A
2010-2011:
Headlight washer system relay
Headlight washer system pump
52
30A
2011-2020:
Rear fresh air blower
53
30A
DC/AC converter with socket, 12V – 230V
54
5A/10A
Control unit for electronic steering column lock
55
25A
2010-2013:
Trailer voltage supply control unit
55
20A
2013-2020:
All-wheel drive control unit
56
30A
2010-2013:
Trailer detector control unit
56
30A
2015-2020:
Control unit for reducing agent metering system (diesel)
57
10A
2011-2015:
Two-way radio
58
25A
2010-2015:
Special vehicle control unit
58
30A
2015-2020 (taxi):
Voltage stabiliser
58
20A
2020:
Control unit 1 for information electronics (RHD)
Engine/motor control unit
Main relay
Fuse 10 on fuse holder B
Fuse 14 on fuse holder B
Fuse 16 on fuse holder B
Fuse 18 on fuse holder B
Fuse 20 on fuse holder B
Fuse 23 on fuse holder B
Fuse 24 on fuse holder B
F14
30A/15A/10A
2010-2015:
Pump for reducing agent (diesel)
Ignition coil 1~4 with output stage
F14
15A/30A
2015-2020:
Ignition coil 1~4 with output stage
Coolant shut-off valve
Coolant valve for gearbox
F14
30A
2020:
Ignition coil 1~4 with output stage
F15
–
not assigned
F16
15A/30A
2010-2015:
Control unit for reducing-agent heater (diesel)
Lambda probe
Lambda probe after catalytic converter
Magnetic clutch for supercharger
F16
15A/30A
2015-2016:
Lambda probe 1 after catalytic converter (petrol)
Lambda probe 1 before catalytic converter (petrol)
Activated charcoal filter solenoid valve 1 (petrol)
Camshaft control valve 1 (2016)
2011-2017:
Headlight washer system relay
Headlight washer system pump
F22
20A
2017-2020:
Wiper motor control unit
F23
15A
2010-2015:
Charge pressure control solenoid valve (diesel)
Heater element for crankcase breather (diesel)
Automatic glow period control unit (diesel)
Exhaust gas recirculation cooler changeover valve (diesel)
Fuel metering valve (diesel)
Fuel pressure regulating valve (diesel)
Coolant circulation pump 2 (diesel)
Additional coolant pump relay (petrol)
Clutch position sender
Brake light switch (2011)
F23
10A/15A
2015-2020:
Brake light switch (petrol)
Air mass meter (diesel)
Additional coolant pump relay (petrol)
Coolant circulation pump (petrol)
Charge pressure control solenoid valve (diesel)
Heater element for crankcase breather (diesel)
Turbocharger air recirculation valve (diesel)
Intake manifold flap valve (petrol)
Valve for oil pressure control
Coolant valve for cylinder head (diesel)
Piston cooling jet control valve (petrol)
Charge air cooling pump
Auxiliary pump for heating (diesel)
F23
10A/15A
2020:
Brake light switch (petrol)
Air mass meter (diesel)
Additional coolant pump relay (petrol)
Coolant circulation pump (petrol)
Charge pressure control solenoid valve (diesel)
Heater element for crankcase breather (diesel)
Coolant valve for cylinder head (diesel)
Charge air cooling pump
Auxiliary pump for heating (diesel)
F24
10A
2010-2015:
Engine component current supply relay
Fuse 17 on fuse holder B (petrol)
Fuse 28 on fuse holder B (diesel)
Radiator fan control unit
Turbocharger air recirculation valve
Activated charcoal filter solenoid valve 1
Camshaft control valve 1
Charge pressure control solenoid valve (petrol)
Low heat output relay
High heat output relay
F24
10A/20A
2015-2020:
Engine component current supply relay
Fuse 17 on fuse holder B (petrol)
Fuse 28 on fuse holder B (diesel)
Lambda probe 1 before catalytic converter (diesel)
Radiator fan control unit
Low heat output relay
High heat output relay
Relay for reducing agent metering system (diesel)
Activated charcoal filter solenoid valve 1 (petrol)
Camshaft control valve 1(petrol)
Exhaust camshaft control valve 1 (petrol)
Valve for oil pressure control (petrol)
Injector 2 for cylinder 1~4 (petrol)
Exhaust cam actuator A for cylinder 1~4 (petrol)
Exhaust cam actuator B for cylinder 1~4 (petrol)
Additional coolant pump relay (petrol) (2018-2020)
F24
15A
2020:
Engine component current supply relay
Fuse 17 on fuse holder B (petrol)
Fuse 28 on fuse holder B (diesel)
Lambda probe 1 before catalytic converter (diesel)
Radiator fan control unit
Control unit for NOx sender (diesel)
Relay for reducing agent metering system
Activated charcoal filter solenoid valve 1 (petrol)
Camshaft control valve 1 (petrol)
Exhaust camshaft control valve 1 (petrol)
Valve for oil pressure control (petrol)
Additional coolant pump relay (petrol)
F25
40A
ABS control unit
F26
40A
Fresh air blower control unit
Low heat output relay
F27
50A
Terminal 15 voltage supply relay 2
F28
50A
Automatic glow period control unit (diesel)
F29
40A/50A
Fuse 17 on fuse holder C
Fuse 18 on fuse holder C (2010-2015)
Fuse 36 on fuse holder C
Fuse 37 on fuse holder C
Fuse 38 on fuse holder C
Fuse 39 on fuse holder C
Fuse 40 on fuse holder C
Fuse 41 on fuse holder C
Fuse 58 on fuse holder C
F30
50A
Terminal 75 voltage supply relay 1
R1
CCZA engine: Engine component current supply relay
Diesel: Connection bridge
R2
Petrol: Main relay
Diesel: Terminal 30 voltage supply relay
Relays under E-box low
Seat Alhambra (MK2/7N; 2010 – 2020) – fuse and relay box diagram – engine compartment (relays under E-box low)
Assignment of the fuses in the engine compartment (Relays under E-box low)
№
Relay
1
With start/stop: Starter relay 1
2
Diesel: Automatic glow period control unit
3
2012-2020: Dual tone horn relay
4
2012-2020: Headlight washer system relay
5
With start/stop: Starter relay 2 (with start/stop)
Without start/stop: Terminal 50 voltage supply relay
The SEAT Inca (Typ 9K) was manufactured from 1996 to 2004. This article provides fuse box diagrams for the 2000, 2001, 2002, 2003, and 2004 models, along with details on the locations of the fuse panels within the vehicle and the functions of each fuse (fuse layout) and relay.
Passenger compartment fuse box
Fuse Box Location
Take hold of the ends of the cover with both hands and pull outwards until it is removed from its housings.
Relay positions above relay carrier: The control number is given in the brackets after the component designation.
The relay positions may, depending on model equipment, engine or version, differ.
Lights switched on and radio relay (292)
2-speed radiator fan relay (no air conditioning system) (80)
2-speed radiator fan relay (no air conditioning system) (53)
The Hyundai Trajet was manufactured from 1999 to 2008. This article features fuse box diagrams for the 2000, 2001, 2002, 2003, and 2004 models, provides details on the locations of the fuse panels within the vehicle, and explains the function of each fuse (fuse layout) and relay.
Passenger compartment fuse box
Fuse Box Location
The fuse box is located low on the dashboard on the driver’s side.
