Ford Galaxy (2006 – 2015) – fuse box diagram

Posted on by admin

Ford Galaxy (2006 – 2015) – fuse box diagram

Year of production: 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015

Engine compartment fuse box

Ford Focus mk2 (2006) - fuse box - engine compartment - (EU version)
Ford Focus mk2 (2006) – fuse box – engine compartment – (EU version)
No. A Circuits Protected
F1 10 Transmission control module (AWF21)
15 Transmission control module (MPS6)
F2 5 Glow plug monitoring (diesel engines)
5 Vaporizer glow plug monitoring (2.0L Duratorq-TDCi Stage V and 2.2L Duratorq-TDCi Stage V)
F3 70 Engine cooling fan – twin fan (2.3L Duratec-HE and 2.2L Duratorq-TDCi automatic)
80 Electric hydraulic power steering (EHPAS) (1.6L EcoBoost SCTi, 2.0L EcoBoost SCTi, 1.6L Duratorq-TDCi Stage V and 2.0L Duratorq-TDCi)
F4 60 Glow plugs
F5 60 Engine cooling fan (1.6L Duratorq-TDCi, 2.0L Duratorq-TDCi, 2.0L Duratorq-TDCi Stage V, 2.2L Duratorq-TDCi manual, 2.0L Duratec-HE, 2.3L Duratec-HE and 2.0L EcoBoost SCTi)
70 Engine cooling fan – twin fan (1.6L EcoBoost SCTi)
F6 7.5 HEGO sensor (1.6L Duratorq-TDCi)
10 HEGO sensor, CMS Sensor, Oxygen Sensor (engine management)
20 Vaporizer glow plug (2.0L Duratorq-TDCi Stage V and 2.2L Duratorq-TDCi Stage V)
F7 5 Relay coils
F8 10 Powertrain control module, fuel metering unit, MAF sensor, fuel rail pressure control valve (engine management)
20 Powertrain control module (2.0L EcoBoost SCTi and 2.0L Duratorq-TDCi Stage V)
15 Powertrain control module (1.6L EcoBoost SCTi, 1.6L Duratorq-TDCi and 2.2L Duratorq-TDCi Stage V)
F9 10 MAF Sensor, Fuel Injectors (engine management)
5 Fuel pump Vaporizer (2.0L Duratorq-TDCi Stage V)
7.5 MAF Sensor, EGR bypass Valve, Fuel pump Vaporizer (2.2L Duratorq-TDCi Stage V) (engine management)
7.5 Degas valve, TMAF sensor, active grille shutter, bypass valve, relay coil, auxiliary run on water pump (1.6L EcoBoost SCTi)
F10 10 Engine control module (2.0L Duratorq-TDCi)
7.5 Auxiliary run on, water pump (1.6L EcoBoost SCTi)
F11 10 PCV Valve, VCV Valve, Water in Fuel Sensor, Sonic Purge Valve, Swirl Control Valve, Variable Intake Valve, EGR Valve, IVVT Oil Control Valve (engine management). T.MAF sensor, variable exhaust timing valve, active grille shutter, cannister purge valve, turbo control valve, wastegate valve (engine management).
10 Turbo control valve, MAF sensor, active grille shutter, EGR valve, VCV valve (1.6L Duratorq-TDCi)
5 MAF sensor, water in fuel sensor, active grille shutter, inlet metering valve (2.0L Duratorq-TDCi Stage V)
7.5 Fuel rail pressure, fuel metering unit, active grille shutter (2.2L Duratorq-TDCi Stage V)
10 Turbo control valve, variable intake timing valve, variable exhaust timing valve, cannister purge valve, electrical bypass valve (1.6L EcoBoost SCTi)
F12 10 Coil on Plug; Canister Purge Valve, Power Steering Pressure Switch (engine management)
10 EGR throttle, variable turbo control (2.0L Duratorq-TDCi)
5 Relay coils (2.0L Duratorq-TDCi Stage V, 2.2L Duratorq-TDCi Stage V and 1.5L Duratorq-TDCi)
15 Ignition coils (1.6L EcoBoost SCTi and 2.0L EcoBoost SCTi)
F13 15 Air conditioning
F14 15 Diesel filter heater (2.0L Duratorq-TDCi, 2.0L Duratorq-TDCi Stage V and 1.6L Duratorq-TDCi)
10 F1EGO sensors (2.2L Duratorq-TDCi Stage V)
F15 40 Starter relay
F16 80 Diesel auxiliary heater (PTC)
F17 60 Central fuse box supply A
F18 60 Central fuse box supply B
F19 60 Rear fuse box supply C
F20 60 Rear fuse box supply D
F21 30 VQM/non VQM: Cluster/Audio/AC/FLR
F22 30 Windscreen wiper module
F23 30 2006-2008: Heated rear window
25 2009-2015: Heated rear window
F24 30 Headlamp washer
F25 30 ABS valves
F26 40 ABS pump
F27 30 2006-2010: Fuel fired heater
25 2011-2015: Fuel fired heater
F28 40 Heater blower
F29 – Not used
F30 5 2011-2015: ABS 30 feed
F31 15 Horn
F32 5 2009-2015: Fuel fired heater – remote control
F33 5 Light switch module, engine compartment fuse box coils
F34 40 Heated windscreen (left-hand side)
F35 40 Heated windscreen (right-hand side)
F36 5 2006-2010: ABS
15 2011-2015: Rear wiper 15 feed
F37 10 2006-2010: Heated front washer jets
7.5 2011-2015: Heated front washer jets/FLR + FSM KL15
F38 5 2006-2010: Adaptive Cruise Control (ACC)
10 2011-2015: PCM/TCM/EHPAS15 feed
F39 15 Adaptive front lighting system (AFS)
F40 5 2011-2015: Headlamp leveling/AFS module
F41 20 Instrument panel
F42 10 2006-2010: Engine control module, transmission control module, electric hydraulic power steering (EHPAS)
5 2011-2015: Cluster IP
F43 5 2006-2010: Headlamp levelling, adaptive front lighting system (AFS)
15 2011-2015: Audio/BVC module/DAB module
F44 20 Electric hydraulic power steering module (2.0L Duratorq-TDCi), vacuum pump (2.5L Duratec-ST)
5 2011-2015: Automatic AC/Manual AC
F45 5 2006-2010: Rear window wiper
15 2011-2015: FLR (Start Stop)

Passenger Compartment Fuse Panel (2006-2009)

Ford Galaxy - fuse box diagram - passenger compartment
Ford Galaxy – fuse box diagram – passenger compartment
No. A Circuits Protected
F1 5 Rain sensor
F2 10 SRS (airbag) supply
F3 5 ABS, yaw rate sensor (ESP), electric parking brake (EPB), accelerator pedal supply
F4 7.5 Electronic feed, accelerator pedal supply, electronic fuse
F5 15 2006-2007: Rear wiper
F6 15 Audio system (incl. voice control)
F7 7.5 Steering wheel module
F8 5 Cluster
F9 15 Main beam
F10 20 Power sunroof
F11 7.5 Reversing lamps
F12 – Not used
F13 15 Front fog lamp
F14 15 Front screen washer
F15 10 Adaptive Cruise Control (ACC)
F16 – Not used
F17 10 Interior lamps
F18 5 Engine immobiliser
F19 15 Cigar lighter
F20 – Not used
F21 5 2006-2007: Radio unit, rain sensor
2008-2009: Remote frequency receiver, Interior motion sensor
F22 20 Fuel pump
7.5 Fuel pump (2.2L Duratorq)
F23 – Not used
F24 5 Ignition switch
F25 10 Fuel filler flap
F26 5 Battery backup sounder (alarm system), OBD II (board computer diagnostics)
F27 5 Steering column unit, climate control module
F28 5 Brake lamp switch

Passenger Compartment Fuse Panel (2010-2015)

Ford Galaxy - fuse box diagram - passenger compartment
Ford Galaxy – fuse box diagram – passenger compartment
No. A Circuits Protected
F1 7.5 Steering wheel module
F2 5 Cluster
F3 10 Interior lamps
F4 5 Engine immobilizer
F5 7.5 Adaptive cruise control (ACC)
F6 5 Rain sensor
F7 20 Cigar lighter
F8 10 Fuel filler flap unlock supply
F9 15 Windscreen washers – rear
F10 15 Windscreen washers – front
F11 10 Luggage compartment release supply
F12 10 Fuel filler flap lock supply
F13 20 Fuel pump
7.5 Fuel pump (2.2L Duratorq-TDCi Stage V)
F14 5 Remote frequency receiver, Interior motion sensor
F15 5 Ignition switch
F16 5 Battery backup sounder (alarm system), OBD II (board computer diagnostics)
F17 5 Steering wheel vibration actuator
F18 10 SRS (airbag) supply
F19 7.5 ABS, yaw rate sensor (ESC), electric parking brake (EPB), accelerator pedal supply
F20 7.5 Electronic feed, electronic fuse, Auto-dimming mirror, lane departure warning
F21 15 Radio supply
F22 5 Brake lamp switch
F23 20 Sunroof
F24 5 Climate Control Module and Steering Column Unit supply

Rear Fuse Box

Ford Galaxy - fuse box diagram - rear fuse box
Ford Galaxy – fuse box diagram – rear fuse box
No. A Circuits Protected
FA1 25 Door module (left-hand front) (window up/down, central locking, electric folding mirror, heated mirror)
FA2 25 Door module (right-hand front) (window up/down, central locking, electric folding mirror, heated mirror)
FA3 25 Door module (left-hand rear) (window up/down)
FA4 25 Door module (right-hand rear) (window up/down)
FA5 10 Rear locking (without rear door modules)
FA6 15 Auxiliary power socket
FA7 5 Relay coils
FA8 20 2010-2015: Keyless vehicle module
FA9 5 2011-2015: Relay coils
FA10 30 2006-2010: Electric driver’s seat
FA11 20 Accessories, trailer module
FA12 30 2011-2015: Electric driver’s seat
FB1 5 2006-2010: Parking aid module/Blind spot detection system
15 2011-2015: Sunblind system
FB2 15 Suspension module
FB3 15 Heated driver’s seat
FB4 15 Heated front passenger seat
FB5 – Not used
FB6 10 Rear climate control
FB7 – Not used
FB8 10 2010: Sun blind system
5 2011-2015: Parking aid, BLIS
FB9 30 Electric front passenger seat
FB10 10 Anti-theft alarm horn
FB11 – Not used
FB12 – Not used
FC1 7.5 Electric rear quarter windows
FC2 30 Electric parking brake (EPB)
FC3 30 Electric parking brake (EPB)
FC4 10 Rear air conditioning
FC5 7.5 2006-2010: CD changer, rear seat entertainment system
20 2011-2015: Keyless vehicle
FC6 20 Rear air conditioning blower
FC7 5 Seat memory function module
FC8 20 2010: Keyless vehicle module
7.5 2011-2015: Rear seat entertainment/CD Changer
FC9 20 2010-2015: Audio amplifier
FC10 10 2010-2015: Sony audiophile
FC11 – Not used

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Ford B-MAX – fuse box diagram

Posted on by admin

Ford B-MAX – fuse box diagram

Year of production: 2012, 2013, 2014, 2015, 2016

Engine compartment fuse box

Ford B-MAX (2015) - bezpieczniki - komora silnika
Ford B-MAX – fuse box- engine compartment



№ A Circuits protected
1 40 Anti-lock braking system module
1 30 Anti-lock braking system, electronic stability program module
2 60 Cooling system fan high speed
3 40 Cooling system fan
3 30 Cooling system fan low speed
4 30 Heater blower
5 60 Passenger’s compartment fuse box supply (battery)
6 30 Body control module
7 60 Passenger’s compartment fuse box supply (ignition)
8 60 Glow plugs
8 50 DPS6 module
9 40 Heated windshield
10 40 Heated windshield
11 30 Starter relay
12 10 High beam left-hand relay
13 10 High beam right-hand relay
14 15 Run on pump
15 20 Ignition coil
16 15 Powertrain control module, high and low cooling fan
17 15 Heated oxygen sensors (gasoline engines)
17 20 Power supply module (diesel engines)
18 – Not used
19 7.5 Air condition controller
20 – Not used
21 – Not used
22 15 Lighting control battery supply
23 15 Front fog lamps
24 15 Direction indicators
25 15 Exterior lighting left-hand side
26 15 Exterior lighting right-hand side
27 7.5 Powertrain control module
28 20 Anti-lock braking system, electronic stability program
29 10 Air conditioning clutch
30 – Not used
31 – Not used
32 20 Horn, battery saver, keyless vehicle module
33 20 Heated rear window
34 20 Fuel pump relay, diesel fuel heater
35 15 Cat1 alarm system
36 7.5 Automatic transmission controller
37 25 Front door module left-hand side
38 25 Front door module right-hand side
39 25 Rear door module left-hand side
40 25 Rear door module right-hand side
Relay Circuits switched
R1 Cooling system fan
R2 Not used
R3 Powertrain control module
R4 High beam
R5 Not used
R6 Not used
R7 Engine cooling fan
R8 Starter
R9 Air conditioning clutch
R10 Front fog lamps
R11 Fuel pump, diesel fuel heater
R12 Reversing lamp
R13 Heater blower

Passenger’s Compartment Fuse Box – Type 1

Ford B-MQX - fuse box diagram - Passenger's Compartment Fuse Box - Type 1
Ford B-MQX – fuse box diagram – Passenger’s Compartment Fuse Box – Type 1
№ A Circuits protected
1 7.5 Ignition, rain sensor, heated windshield
2 10 Stop lamps
3 7.5 Reversing lamp, rear view camera
4 7.5 Headlamp leveling
5 – Not used
6 15 Rear window wiper
7 15 Washer pump
8 – Not used
9 15 Passenger’s heated seat
10 15 Driver’s heated seat
11 – Not used
12 10 Airbag module
13 10 Ignition, electric power assisted steering, instrument cluster, passive anti-theft system, anti-lock braking system
14 7.5 Powertrain control module, transmission selector lever, fuel pump
15 7.5 Audio system, instrument cluster
16 7.5 Heated windshield
17 – Not used
18 – Not used
19 15 Data link connector
20 20 Multi function display, clock, internal scanner, heating vents, air conditioning panel
21 15 Audio system, navigation, bluetooth
22 7.5 Instrument cluster
23 7.5 Trailer module
24 7.5 Sync module antenna
25 – Not used
26 30 Front wiper, left-hand side
27 30 Front wiper, right-hand side
Relay Circuits switched
R1 Ignition

Passenger’s Compartment Fuse Box – Type 2

Ford B-MAX (2015) - bezpieczniki - przedział pasażerski
Ford B-MAX – fuse box- passenger compartment



№ A Circuits protected
1 7.5 Ignition, rain sensor, heated windshield, dome lamp, interior mirror
2 10 Stop lamps
3 7.5 Reversing lamp
4 7.5 Headlamp leveling
5 – Not used
6 15 Rear window wiper
7 15 Washer pump
8 – Not used
9 15 Passenger’s heated seat
10 15 Driver’s heated seat
11 – Not used
12 10 Airbag module
13 10 Ignition, electric power assisted steering, instrument cluster, passive anti-theft system, anti-lock braking system
14 7.5 Powertrain control module, gear selector lever, fuel pump
15 7.5 Audio system, instrument cluster
16 7.5 Heated windshield right-hand side
17 – Not used
18 – Not used
19 10 Data link connector
20 20 Trailer module
21 15 Audio system, navigation
22 7.5 Instrument cluster
23 7.5 Multi functional display, clock, internal scanner, heating vents, air conditioning panel
24 10 Sync module
25 – Not used
26 30 Front wiper, left-hand side
27 30 Front wiper, right-hand side
28 30 Voltage quality module
29 20 Rear power point
30 20 Cigar lighter, front power point
31 – Not used
32 – Not used
33 – Not used
34 20 Keyless entry
35 20 Keyless entry
36 10 Data link connector
37 15 Ignition switch
38 – Not used
39 – Not used
40 – Not used
41 – Not used
42 7.5 Rear view camera
43 10 Active city stop module
44 7.5 Passenger airbag deactivation indicator
45 – Not used
46 – Not used
47 – Not used
48 – Not used
49 – Not used
Relay Circuits switched
R1 Ignition
R2 Cigar lighter
R3 Not used
R4 Active city stop relay
R5 Not used
R6 Keyless entry (accessory)
R7 Keyless entry (ignition)
R8 Battery saver relay
R9 Heated front screen left-hand side
R10 Heated front screen right-hand side
R11 Not used
R12 Not used

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Crafter – fuse box diagram

Posted on by admin

Volkswagen Crafter – fuse box diagram

Year of production:

Fitting locations overview

Volkswagen Crafter - fuse box diagram - location
Volkswagen Crafter – fuse box diagram – location
  1. Terminal 30 voltage supply fuse -S190-
  2. Fuse holder A -SA- Fuses
  3. Fuse holder B -SB- Fuses
  4. Fuse holder C -SC- Fuses
  5. Fuse holder D -SD- Fuses
  6. Single fuses under driver seat

Fuses (SA) on fuse holder, on the battery (2)

Volkswagen Crafter - fuse box diagram -Fuses (SA) on fuse holder, on the battery (2)
Volkswagen Crafter – fuse box diagram -Fuses (SA) on fuse holder, on the battery (2)

Fuses on the battery

№ A Function/component
1 80 Automatic glow period control unit -J179-
2 40
60 / 80		 Radiator fan control unit -J293- (only on models with A/C system)
radiator fan -V7- (only on models with A/C system)
right radiator fan -V35- (only on models with air conditioning system)
3 80 Onboard supply control unit -J519-
Engine component current supply relay -J757-
Fuse holder C -SC- SC2, SC3, SC8 – SC10, SC16
4 150 Auxiliary battery -A1-
Tipping mechanism fuse -S186- (before August 2006)
Fuse 1 (30) -S204- (after July 2006)
Fuse 2 (30) -S205- (after September 2006)
Main fuse for multiple equipment configurations -S245- (before August 2006)
Fuse holder D -SD- SD23 – SD25, SD28 (after September 2006 on models with second battery)
5 150 Terminal 15 voltage supply relay -J329-
Horn relay -J413-
Onboard supply control unit -J519-
Terminal 15 voltage supply relay 2 -J681-
Start/Stop operation fuse -S349- (after November 2011)
Fuse holder B -SB- SB1 – SB18
Fuse holder C -SC- SC4 – SC7, SC11 – SC15, SC17 – SC25
6 – Terminal 15 relief relay -J404-
Voltage supply relay 1 -J701- (after November 2013)
Relief relay 2 for terminal 15 -J817- (only for models in the 3.8 t weight class)
Relief relay 3 for terminal 15 -J896- (after November 2011)
Fuse for heated front windscreen -S127-
Fuse 1 -S131- (after November 2011)
Fuse 1 (30) -S204- (before June 2006)
Fuse holder D -SD- SD10 – SD33, SD42
7 150 Auxiliary air heater element -Z35-

Fuses (SB) on fuse carrier B, left A-pillar (3)

Volkswagen Crafter - fuse box diagram -Fuses (SB) on fuse carrier B, left A-pillar
Volkswagen Crafter – fuse box diagram -Fuses (SB) on fuse carrier B, left A-pillar

Fuse on left A-pillar

№ A Function/component
1 25 Driver door control unit -J386-
2 10 Diagnostic connection -U31-
3 25 ABS control unit -J104-
4 40 ABS control unit -J104-
5 – -Not used-
6 7.5 Evaluation unit for reducing agent level -G698- (from November 2008 to May 2009)
Reverse flow valve for reducing agent -N473- (from November 2008 to May 2009)
Pump for reducing agents -V437- (from November 2008 to May 2009)
-Not used- (from May 2009)
Supply unit for reducing agent metering system -GX19- (from November 2013)
NOx sensor control unit -J583- (from November 2013)
Relay 1 for voltage supply -J701- (from November 2013)
NOx sensor 2 control unit -J881- (from November 2013)
Relay for reducing agent metering system -J963- (from November 2013)
Pump for reducing agent -V437- (from November 2013)
7 30 Headlight washer system pump -V11-
8 15 Rotating light and siren system switch -E11- (from July 2006)
Switch for rotating light -E162- (from July 2006)
Alarm horn -H12-
Alarm system relay 1 -J460-
Siren system relay 2 -J645- (From July 2006)
9 10 Turn signal relay for roof mounted turn signals -J436- (from May 2007)
10 15 Radio -R-
Control unit with display for radio and navigation -J503-
11 7.5 Mobile telephone operating electronics control unit -J412-
Tachograph control unit -J621-
12 30 Heater/heat output switch -E16-
Fresh air blower relay -J13-
Fresh air blower control unit -J126-
Fresh air blower -V2-
13 7.5 Pre-selection clock -E111-
Remote control receiver for auxiliary coolant heater -R149-
14 30 Operating unit for centre dash panel -J819-
15 10 Load area illumination switch -E481- (to October 2008)
Not used
16 10 Heater/heat output switch -E16-
A/C control module -J301-
CD changer -R41-
17 10 Interior illumination switch -E599-
Rear interior lamp switch -E6- (from November 2012 to May 2013)
18 – Not used

Fuses (SC) in fuse holder C, on left A-pillar (4)

Volkswagen Crafter - fuse box diagram -Fuses (SC) in fuse holder C, on left A-pillar
Volkswagen Crafter – fuse box diagram -Fuses (SC) in fuse holder C, on left A-pillar

Fuse on left A-pillar

№ A Function/component
1 15 Treble horn -H2-
2 25 Electronic ignition lock -D9-
El. steer. col. lock CU -J764-
3 10 Electronic ignition lock -D9-
Control unit in dash panel insert -J285-
Engine control unit -J623- (from May 2012)
4 5 Light switch -E1-
Operating unit for centre dash panel -J819-
5 30 Windscreen wiper motor -V-
6 15 Fuel system pressurisation pump -G6-
7 5 Steering column electronics control unit -J527-
8 20 Engine control unit -J623-
9 20
25		 Fuse 6 on fuse holder B -SB6- (from November 2008 to May 2009)
Fuse holder D -SD- SD34 – SD36 (from May 2009 to November 2013)
10 10 Air mass meter -G70- (from May 2012)
Evaluation unit for reducing agent level -G698- (from May 2012)
Heater element for crankcase breather -N79- (from May 2012)
Fuel pressure regulating valve -N276-
Exhaust gas recirculation cooler changeover valve -N345- (from May 2012)
Reverse flow valve for reducing agent -N473- (from May 2012)
Exhaust gas recirculation cooler pump -V400- (from May 2012)
Pump for reducing agent -V437- (from May 2012)
11 15 Relief relay 2 for terminal 15 -J817- (only for models in the 3.8 t weight class)
Fuse 1 on fuse holder D -SD1-
Fuse 2 on fuse holder D -SD2-
12 10 Airbag control unit -J234-
13 15 Glove compartment light switch -E26-
Cigarette lighter -U1-
14 5 Light switch -E1-
Control unit in dash panel insert -J285-
Diagnostic connection -U31-
15 5 Heater/heat output switch -E16-
Headlight range control regulator -E102-
Left headlight range control motor -V48-
Right headlight range control motor -V49-
16 10 Main switch for stop/start system -E101-
Gearbox neutral position switch -F365-
Oil level and oil temperature sender -G266-
Fuel pump relay -J17-
Continued coolant circulation relay -J151-
Automatic glow period control unit -J179-
Terminal 50 voltage supply relay -J682-
Starter relay 1 -J906- (after November 2013)
Starter relay 2 -J907- (after November 2013)
Charge pressure control solenoid valve -N75-
Coolant circuit valve -N214-
Exhaust flap valve -N220- (after November 2013)
Fuel metering valve -N290-
Exhaust gas recirculation cooler changeover valve -N345-
Lambda probe heater -Z19-
17 10 Airbag control unit -J234-
18 7.5 Brake light switch -F- (from July 2006 to November 2011)
Brake pedal switch -F63- (from July 2006 to November 2011)
Relief relay for terminal 15 -J404-
Voltage stabiliser -J532- (after November 2011)
Relay for special constructions, terminal 15 -J821- (after November 2011)
Relief relay 3 for terminal 15 -J896- (from November 2011)
19 7.5 Onboard supply control unit -J519- (Interior light)
20 25 Onboard supply control unit -J519-
21 5 Air mass meter -G70-
Engine control unit -J623-
22 5 Brake light switch -F- (before June 2006)
Brake pedal switch -F63- (before June 2006)
Lateral acceleration sensor -G200- (from July 2006)
Longitudinal acceleration sensor -G251- (from July 2006)
ABS control unit -J104- (From July 2006)
23 25 Starter -B-
Onboard supply control unit -J519-
24 10 -Reserve Kl. 15-
Battery regulation control unit -J840- (from May 2013)
25 30 -12-V socket -U5-

Fuses (SD) on fuse holder D, under driver seat, until May 2011 (5)

Volkswagen Crafter - fuse box diagram Fuses (SD) on fuse holder D, under driver seat,
Volkswagen Crafter – fuse box diagram Fuses (SD) on fuse holder D, under driver seat,

Fuse under driver seat

№ A Function/component
1 5 Operating unit for window regulator in driver door -E512-
Heated rear window relay -J9- (before June 2006)
Relay 2 for heated rear window -J868- (From July 2006)
2 30 Rear left wing door window wiper motor -V92-
Rear window wiper motor in right wing door -V93-
3 5 Pre-selection clock -E111-
Gearbox neutral position switch -F365-
Display unit control unit -J146-
Mobile telephone operating electronics control unit -J412- (until May 2011)
Reversing camera -R189-
4 7.5 Working speed control switch -E261- (from July 2006)
Power take-off warning switch -F247- (from July 2006)
Relay for heated rear window -J9- (until June 2006)
Trailer detector control unit -J345-
Tachograph control unit -J621- (From July 2006)
5 5 / 10 Selector lever -E313-
Automated manual gearbox control unit -J514-
6 5 Battery regulation control unit -J840- (until May 2013)
Heater element for crankcase breather -N79-
7 10 Fuel filter heater -Z57-
8 5 / 10 Tilting mechanism button -E223-
Relay for special constructions, terminal 15 -J821-
6-pin connector -T6ah- (from May 2007)
7-pin connector -T7f- (Tail lift coupling point)
9 15 Switch for roof ventilator to ventilate loading area -E534-
Siren system relay -J408-
10 25 -Interface for external use-
11 15 Relay for special constructions, terminal 15 -J821-
12 10 Relay for special constructions, terminal 61 -J822-
13 30 / 10 Evaporator blower control unit -J349- (from May 2007 to May 2011)
Turn signal relay for roof mounted turn signals -J436- (To May 2007)
14 20 Trailer detector control unit -J345- (Before August 2006)
9-pin connector -T9b- (Preliminary set-up for trailer attachment from September 2006)
Trailer socket -U10- (From September 2006)
15 25 Trailer detector control unit -J345-
16 7.5 Parking aid control unit -J446-
Tyre Pressure Monitoring System control unit -J502-
17 25 Control unit for programmable special functions -J820-
18 25 Control unit for programmable special functions -J820-
19 5 / 25 Roof electronics control unit -J528-
20 7.5 / 10 Continued coolant circulation relay -J151-
Entry and footwell light relay -J348- (from May 2009)
21 15 / 30 Heated rear window relay -J9-
22 15 Heated rear window relay -J9- (before June 2006)
Relay 2 for heated rear window -J868-
23 10 / 15 Load area illumination switch -E481- (after November 2008)
12 V socket 2 -U18-
24 15 12 V socket 4 -U20-
25 15 12 V socket 3 -U19-
26 25 Auxiliary heater control module -J364-
27 20 / 25 Auxiliary heater control module -J364-
Control unit 2 for supplementary heating -J824-
28 30 / 40 Evaporator blower control unit -J349- (before April 2007)
Gearbox hydraulic pump relay -J510- (from May 2007)
29 15 Automated manual gearbox control unit -J514-
30 40 Gearbox hydraulic pump relay -J510- (before April 2007)
Battery regulation control unit -J840-
31 30 / 15 Rear fresh air blower control unit -J391-
Left sliding door control unit -J558-
Rear fresh air blower -V80-
32 5 Battery monitoring control unit -J367-
33 15 Right sliding door control unit -J731-
34 15 Control unit for reducing-agent heater -J891- (from April 2009)
35 15 / 3 Control unit for reducing-agent heater -J891- (from April 2009)
36 – Not used

Fuses (SD) on fuse holder D, under driver seat, after May 2011 (5)

Volkswagen Crafter - fuse box diagram Fuses (SD) on fuse holder D, under driver seat,
Volkswagen Crafter – fuse box diagram Fuses (SD) on fuse holder D, under driver seat,

Fuse under driver seat

№ A Function/component
1 5 Operating unit for window regulator in driver door -E512-
Heated rear window relay 2 -J868-
2 30 Rear left wing door window wiper motor -V92-
Rear window wiper motor in right wing door -V93-
3 5 Pre-selection clock -E111-
Gearbox neutral position switch -F365-
Display unit -J145-
Reversing camera -R189-
4 7.5 Working speed control switch -E261-
Power take-off warning switch -F247-
Trailer detector control unit -J345-
Tachograph control unit -J621-
5 5 / 10 Selector lever -E313-
Automated manual gearbox control unit -J514-
Bonnet contact switch -F266- (from November 2011)
6 5 / 10 Heater element for crankcase breather -N79-
Battery regulation control unit -J840- (from May 2011 to May 2013)
7 10 Fuel filter heater -Z57-
8 5 / 10 Tilting mechanism button -E223-
Parking aid control unit -J446- (after May 2013)
Relay for special constructions, terminal 15 -J821- (until November 2011)
6-pin connector -T6ah-
7-pin connector -T7f- (Tail lift coupling point)
9 15 Switch for roof ventilator to ventilate loading area -E534- (before November 2011)
Siren system relay -J408- (before November 2011)
-nicht belegt (ab November 2011)-
10 25 -Schnittstelle für externe Nutzung-
11 15 Relay for special constructions, terminal 15 -J821-
12 10 Relay for special constructions, terminal 61 -J822-
13 – Not used
14 20 9-pin connector -T9b- (Preliminary set-up for trailer attachment)
Trailer socket -U10-
15 25 Trailer detector control unit -J345-
16 7.5 Parking aid control unit -J446-
Tyre Pressure Monitoring System control unit -J502-
17 25 Control unit for programmable special functions -J820-
18 25 Control unit for programmable special functions -J820-
19 5 / 25 Roof electronics control unit -J528-
20 7.5 / 10 Continued coolant circulation relay -J151-
Entry and footwell light relay -J348-
21 30 Heated rear window relay -J9-
22 15 Heated rear window relay 2 -J868-
23 10 / 15 Load area illumination switch -E481-
12 V socket 2 -U18-
24 15 12 V socket 4 -U20-
25 15 12 V socket 3 -U19-
26 25 Auxiliary heater control module -J364-
27 20 / 25 Auxiliary heater control module -J364-
Control unit 2 for supplementary heating -J824-
28 40 / 30 Gearbox hydraulic pump relay -J510-
Starter relay 1 -J906-
29 15 Automated manual gearbox control unit -J514-
30 5 Battery regulation control unit -J840-
31 30 / 15 Left sliding door control unit -J558- (from May 2012)
Rear fresh air blower control unit -J391-
Rear fresh air blower -V80-
32 5 Battery monitoring control unit -J367-
33 15/30/7,5 Not used
Right sliding door control unit -J731- (from May 2012)
Lockout relay 1 for transfer box -J1010- (from January 2012)
Lockout relay 2 for transfer box -J1011- (from January 2012)
Lockout relay 3 for transfer box -J1012- (from January 2012)
Compressed air compressor -V534 – (From January 2012)
34 15 / 7.5 Control unit for reducing-agent heater -J891-
Transfer box differential lock switch -F99- (from January 2012)
Rear axle drive unit differential lock switch -F100- (from January 2012)
Front axle drive unit differential lock switch -F101- (From January 2012)
35 15 / 3 Control unit for reducing-agent heater -J891-
Compressed air compressor protection control unit -J1013- (From January 2012)
36 5 Not used (to January 2012)
Compressed air compressor pressure switch -F503- (From January 2012)
37 – Not used
38 – Not used
39 7.5 / 15 Switch for roof ventilator to ventilate loading area -E534- (after November 2011)
Siren system relay -J408- (from November 2011)
40 – Not used
41 – Not used
42 30 Evaporator blower control unit -J349-
43 – Not used
44 – Not used
45 – Not used
46 – Not used
47 – Not used
48 – Not used
49 – Not used
50 – Not used
51 – Not used
52 – Not used
53 – Not used
54 – Not used
55 – Not used
56 – Not used

Single fuses under driver seat (fuses for special vehicles until May 2013)

Volkswagen Crafter - fuse box diagram-Single fuses under driver seat (fuses for special vehicles until May 2013)
Volkswagen Crafter – fuse box diagram-Single fuses under driver seat (fuses for special vehicles until May 2013)

A – Tipping mechanism fuse -S186- Up to August 2006
A – Fuse 1 (30) -S204- (Retarder/Second battery)
A – Fuse 2 (30) -S205- after September 2006 (Tail lift/three-way tipper/Retarder)
A – Main fuse for multiple equipment configurations -S245- Up to August 2006

Single fuses under driver seat (fuses for special vehicles after May 2013 )

Volkswagen Crafter - fuse box diagram-Single fuses under driver seat (fuses for special vehicles after May 2013)
Volkswagen Crafter – fuse box diagram-Single fuses under driver seat (fuses for special vehicles after May 2013)

A – Fuse 1 (30) -S204- (Retarder/Second battery)
A – Fuse 2 (30) -S205- (Tail lift/three-way tipper/Retarder)

Fuse 1 -S131-

Volkswagen Crafter - fuse box diagram - Fuse 1 -S131-
Volkswagen Crafter – fuse box diagram – Fuse 1 -S131-

A – Daytime running lights fuse -S220- (Achleitner only)
B – Fuse 1 -S131- (Compressed air compressor)

Terminal 30 voltage supply fuse -S190- (1)

Volkswagen Crafter - fuse box diagram - Terminal 30 voltage supply fuse -S190- (1)
Volkswagen Crafter – fuse box diagram – Terminal 30 voltage supply fuse -S190- (1)

A –  Terminal 30 voltage supply fuse -S190- (in the line section between the alternator and the starter)WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Passat (B7; 2010 – 2015) – fuse box diagram

Posted on by admin

Volkswagen Passat (B7; 2010 – 2015) – fuse box diagram

Year of production: 2010, 2011, 2012, 2013, 2014, 2015

The location of the fuse block

Volkswagen Passat B7 - fuse box diagram - location
Volkswagen Passat B7 – fuse box diagram – location
  1. Fuse holder D -SD-
  2. Fuse holder F -SF-
  3. Fuse 2 (30) -S205- (60 A)
  4. Fuse holder C -SC-
  5. Safety cutout under dash panel, driver side
  6. Fuse holder B -SB-
  7. Fuse holder A -SA-

Fuse holder C -SC- , on left of dash panel

Volkswagen Passat B7 - fuse box diagram - Fuse holder C -SC- , on left of dash panel
Volkswagen Passat B7 – fuse box diagram – Fuse holder C -SC- , on left of dash panel
№
 A
 Function/component
1 10 High-pressure sender -G65-
Air quality sensor -G238-
Oil level and oil temperature sender -G266-
Fresh air blower relay -J13-
DC/AC converter with socket, 12 V – 230 V -U13-
Automatic anti-dazzle interior mirror -Y7-
Heated rear left seat switch with regulator -E128-
Heated rear right seat switch with regulator -E129-
2 5 Light switch -E1-
TCS and ESP button -E256-
Auto-hold button -E540-
ABS control unit -J104-
Power steering control unit -J500-
Control unit for electromechanical parking brake -J540-
3 10 Current supply relay -J16-
Heater element for crankcase breather -N79-
Gas injection valve 1 -N366-
Gas injection valve 2 -N367-
Gas injection valve 3 -N368-
Gas injection valve 4 -N369-
4 10 Rear roller blind switch -E149-
Start/Stop operation button -E693-
Electronically controlled damping control unit -J250-
Adaptive cruise control unit -J428-
Parking aid control unit -J446-
Trailer detector control unit -J345-
Park assist steering control unit -J791-
Front camera for driver assist systems -R242-
Diagnostic connection -U31-
5 10 Headlight range control regulator -E102-
Left headlight range control motor -V48-
Right headlight range control motor -V49-
Front left headlight -MX1-4)
6 10 All-wheel drive control unit -J492-
7 5 Control unit in dash panel insert -J285-
Data bus diagnostic interface -J533-
8 10 Front right headlight -MX2-4)
9 10 Airbag control unit -J234-
Front passenger side airbag deactivated warning lamp -K145-
10 10 Air mass meter -G70-
Voltage stabiliser -J532-
Fuel pump control unit -J538-Engine control unit -J623-
Terminal 50 voltage supply relay -J682-
Voltage supply relay 2 -J710-
Starter relay 1 -J906-
Starter relay 2 -J907-
11 5 6) Warning buzzer pedal switch on front passenger side -F349-6)
12 20 Convenience system central control unit -J393-
Front passenger door control unit -J387-17)
Rear passenger side door control unit -J927-17)
13 10 Light switch -E1-
Selector lever -E313-
ABS control unit -J104-
Handbrake warning lamp -K139-
Diagnostic connection -U31-
ABS control unit -J104- T38/15
14 10 Interior monitor send and receive module 1 -G303-
Alarm horn -H12-
15 10 Rain and light sensor -G397-
Heated rear window relay -J9-
Heated windscreen relay -J47-
Climatronic control unit -J255-
Air conditioning system control unit -J301-
Reversing camera system control unit -J772-
Control unit for terminal control and engine start -J942-
Remote control receiver for auxiliary coolant heater -R149-
Tyre Pressure Monitoring System control unit -J502-
16 10 Electronic ignition lock -D9-
Electronic steering column lock control unit -J764-
Control unit for terminal control and engine start -J942-
17 15 Driver door control unit -J386-17)
Rear driver side door control unit -J926-17)
Not used (from May 2012)
18 3A Onboard supply control unit -J519-
Voltage stabiliser -J532-
Engine control unit -J623-
Voltage supply relay 2 -J710-
19 – Not used
20 – Not used
21 10 Rear roller blind control unit -J262-
22 20 Control unit for electromechanical parking brake -J540-
23 15 Trailer detector control unit -J345-
Electronically controlled damping control unit -J250-4)
24 20 Control unit for electromechanical parking brake -J540-
25 5 8)
15 7)
30 4)		 Emergency assistance call button -E276-
Trailer detector control unit -J345-
Sunroof roller blind control unit -J394-4)
26 20 Onboard supply control unit -J519-
27 15 1)
20 2)		 Fuel pump control unit -J538-1)
Fuel pump relay -J17-2)
Electric fuel pump 2 relay -J49-2)
28 30 Driver door control unit -J386-9)
Rear driver side door control unit -J926-9)
Front passenger door control unit -J387-4)
Rear passenger side door control unit -J927-4)
29 20 Heated rear seats control unit -J786-
30 20 10)
30 11)		 Sliding sunroof adjustment control unit -J245-
31 30 DC/AC converter with socket, 12 V-230 V -U13-
32 30 Heated rear window relay -J9-
33 30 Headlight washer system relay -J39-
34 25 Heated front seats control unit -J774-
35 15 4) Rear lid control unit -J605-4)
Driver seat lumbar support adjustment switch -E176-9)(from May 2012)
36 15 Driver seat lumbar support adjustment switch -E176-
Trailer voltage supply relay -J941- (from May 2012)
37 20 9)
30 4)		 Trailer detector control unit -J345-9)
Rear lid control unit 2 -J756-4)
38 40 12) Fresh air blower relay -J13-14)
Fresh air blower control unit -J126-13)
39 5 Selector lever -E313-
Reversing light switch -F4-
Mechatronic unit for dual clutch gearbox -J743-
40 20 Onboard supply control unit -J519-
Rear window wiper motor -V12-
Windscreen and rear window washer pump -V59-
41 20 Onboard supply control unit -J519-
Cigarette lighter -U1-
Rear cigarette lighter -U9-
42 15 12 V socket -U5-
43 20 15) Auxiliary heater control unit -J364-15)
44 30 Driver door control unit -J386-4)
Rear driver side door control unit -J926-4)
Front passenger door control unit -J387-9)
Rear passenger side door control unit -J927-9)
45 20 15) Auxiliary heater operation relay -J485-15)
46 – Not used
47 5 3) Analogue clock -Y-3)
TV tuner -R78-3)
Mobile telephone operating electronics control unit -J412-3)
Control unit for navigation system -J856-3.16)
48 5 3) Control unit in dash panel insert -J285-3)
49 – Not used
1) Only models with a petrol engine
2) Only models with a diesel engine
3) Only models with start/stop system
4) Only right-hand drive models
5) Only models with xenon headlights
6) Only applicable to special vehicles
7) Only models with trailer socket
8) Only models with emergency call module
9) Only left-hand drive models
10) Only saloon
11) Only estate
12) Only models with auxiliary heating
13) Only models with Climatronic
14) Only models with Climatic
15) Only models with second battery
16) Only models with equipment for Korea
17) Only CC

Safety cutout under dash panel, driver side

Volkswagen Passat B7 - fuse box diagram - Safety cutout under dash panel, driver side
Volkswagen Passat B7 – fuse box diagram – Safety cutout under dash panel, driver side
№
 A
 Function/component
А – Not assigned
В – Driver seat adjustment thermal fuse 1 -S44-
Relays
1 Fresh air blower relay -J13- (Climatic with auxiliary heater)
2 Auxiliary heater operation relay -J485- (Climatic with auxiliary heater)
3 Auxiliary heater operation relay -J485- (Diesel engine with auxiliary heater)
4 Not used
5 Continued coolant circulation relay -J151- (only 1.8l / 2.0l TFSI)
Current supply relay -J17-
6 Terminal 50 voltage supply relay -J682- (not for models with start/stop system)
7 Voltage supply relay 2 -J710- (not for models with start/stop system)
8 Voltage supply relay 2 -J710- (not for models with start/stop system)

Fuse holder B -SB- on E-box low

Volkswagen Passat B7 - fuse box diagram - Fuse holder B -SB- on E-box low
Volkswagen Passat B7 – fuse box diagram – Fuse holder B -SB- on E-box low
№
 A
 Function/component
SB1 15 12,15) Mechatronic unit for dual clutch gearbox -J743-12), 15)(from May 2012)
SB2 30 ABS control unit -J104-
SB3 20 Treble horn -H2-
Bass horn -H7-
Dual tone horn relay -J4-
SB4 20
15 from 2012		 Trailer detector control unit -J345-
SB5 5 Battery monitoring control unit -J367-
Onboard supply control unit -J519-
SB6 15 2,16)
40 12,17)		 Mechatronic unit for dual clutch gearbox -J743-2) 16)
Low heat output relay -J359-12), 17)
SB7 15 6,7)
20 5,7)
30 1)		 Radio -R-
Control unit with display for radio and navigation -J503-
Voltage stabiliser -J532-(1
SB8 30 Mechatronic unit for dual clutch gearbox -J743-
SB9 5 Steering column electronics control unit -J527-
SB10 20 Ignition coil 1 with output stage -N70-
Ignition coil 2 with output stage -N127-
Ignition coil 3 with output stage -N291-
Ignition coil 4 with output stage -N292-
Fuel pressure regulating valve -N276-
Fuel metering valve -N290-
SB11 5 Control unit in dash panel insert -J285-
SB12 5 TV tuner -R78-
Mobile telephone operating electronics control unit -J412-
Analogue clock -Y-
Control unit for navigation system -J856-14)
SB13 10 Motronic current supply relay -J271-
Terminal 30 voltage supply relay -J317-
Engine control unit -J623-
SB14 25 3)
30 2)		 Engine control unit -J623-
Engine control unit -J623-
SB15 5 Data bus diagnostic interface -J533-
SB16 10 9)
15 8)		 Charge pressure control solenoid valve -N75-2)
Exhaust gas recirculation cooler changeover valve -N345-
Magnetic clutch for supercharger -N421-3)
Continued coolant circulation relay -J151-3)
Continued coolant circulation pump -V51-3)
Coolant circulation pump 2 -V178-
SB17 10
40 10)		 Fuel pressure regulating valve -N276-
Fuel tank shut-off valve 1 -N361-
Fuel tank shut-off valve 2 -N362-
Fuel tank shut-off valve 3 -N363-
Coolant circulation pump -V50-
Low heat output relay -J359-10)
SB18 10 9)
30 8)		 Fuel quality sender -G446-
High-pressure valve for gas mode -N372-
SB19 30 Amplifier -R12-
Special vehicle control unit -J608-11)
SB20 5
15 12), 15)		 Brake light switch -F-
Clutch position sender -G476-
Low heat output relay -J359-
High heat output relay -J360-
Engine component current supply relay -J757-
Fuel pressure regulating valve -N276-
SB21 20 Auxiliary heater control unit -J364-
SB22 30 Wiper motor control unit -J400-
SB23 10 Brake light switch -F-
Air mass meter -G70-
Clutch position sender -G476-
Fuel pump relay -J17-
Automatic glow period control unit -J179-
Radiator fan control unit -J293-
Additional coolant pump relay -J496-
Charge pressure control solenoid valve -N75-
Activated charcoal filter solenoid valve 1 -N80-
Camshaft control valve 1 -N205-
Turbocharger air recirculation valve -N249-
Intake manifold flap valve -N316-
Valve for oil pressure control -N428-
SB24 10 2.9
15		 Lambda probe heater -Z19-
Lambda probe 1 heater after catalytic converter -Z29-
NOx sender 2 control unit -J881-8)
SB25 40 Onboard supply control unit -J519-
SB26 40 Onboard supply control unit -J519-
SB27 60 Heated windscreen relay -J47-
SB28 50 Automatic glow period control unit -J179-2)
SB29 50 Fuse 38 on fuse holder C -SC38-13)
Fuse 40 on fuse holder C -SC40- to fuse 42 on fuse holder C -SC42-
X-contact relief relay -J59-
SB30 40 Terminal 15 voltage supply relay -J329-
Fuse 1 on fuse holder C -SC1- to fuse 11 on fuse holder C -SC11-
Fuse 20 on fuse holder C -SC20-
Fuse 21 on fuse holder C -SC21-
Fuse 39 on fuse holder C -SC39-
Fuse 18 on fuse holder C -SC18-1)
Relays
A1 Engine component current supply relay -J757-
A2 Terminal 30 voltage supply relay -J317- (Diesel engine)
Motronic current supply relay -J271- (Petrol engine)
1) Only models with start/stop system
2) Only models with diesel engines
3) Only models with a petrol engine
4) Depends on equipment
5) Only models with navigation system
6) Only models with radio
7) Only models with start/stop system
8) Only models with reducing agent metering system
9) Only models without reducing agent metering system
10) Only models with auxiliary air heater
11) Only applicable to special vehicles
12) for CNG models only
13) Only models with air conditioning system/Climatronic
14) Only models with equipment for Korea
15) Only ethanol vehicles
16) Only for petrol engine with forced induction
17) Only for petrol engine without forced induction

Fuse holder B -SB- on E-box high

Volkswagen Passat B7 - fuse box diagram - Fuse holder B -SB- on E-box high
Volkswagen Passat B7 – fuse box diagram – Fuse holder B -SB- on E-box high
№
 A
 Function/component
SB1 5 1)
10 2)		 Automatic gearbox control unit -J217-
Mechatronic unit for dual clutch gearbox -J743-
SB2 30 ABS control unit -J104-
SB3 15 Trailer detector control unit -J345-
SB4 – Not used
SB5 20 Treble horn -H2-
Bass horn -H7-
Dual tone horn relay -J4-
SB6 20 Ignition coil 1 with output stage -N70-
Ignition coil 2 with output stage -N127-
Ignition coil 3 with output stage -N291-
Ignition coil 4 with output stage -N292-
Ignition coil 5 with output stage -N323-
Ignition coil 6 with output stage -N324-
SB7 15 Fuel pressure regulating valve -N276-
SB8 5 3)
10		 Brake light switch -F-
Continued coolant circulation relay -J151-
Radiator fan control unit -J293-
Activated charcoal filter solenoid valve 1 -N80-
Camshaft control valve 1 -N205-
Exhaust camshaft control valve 1 -N318-
SB9 5 Circulation pump relay -J160-
SB10 10 Lambda probe 1 heater after catalytic converter -Z29-
Lambda probe 2 heater after catalytic converter -Z30-
SB11 25
30 3)		 Engine control unit -J623-
SB12 10 3)
20		 Lambda probe heater -Z19-
Lambda probe 2 heater -Z28-
SB13 – Not used
SB14 – Not used
SB15 10 Continued coolant circulation pump -V51-
SB16 5 Steering column electronics control unit -J527-
SB17 5 Control unit in dash panel insert -J285-
SB18 30 Amplifier -R12-
SB19 15 6.7)
20 5.7)
30 4)		 Radio -R-
Control unit with display for radio and navigation -J503-
Voltage stabiliser -J532-(4
SB20 5 Analogue clock -Y-
TV tuner -R78-
Mobile telephone operating electronics control unit -J412-
Control unit for navigation system -J856-8)
SB21 – Not used
SB22 – Not used
SB23 – Not used
SB24 5 Data bus diagnostic interface -J533-
SB25 – Not used
SB26 10 Motronic current supply relay -J271-
Engine control unit -J623-
SB27 – Not used
SB28 – Not used
SB29 – Not used
SB30 20 Auxiliary heater control unit -J364-
SB31 30 Wiper motor control unit -J400-
SB32 – Not used
SB33 – Not used
SB34 – Not used
SB35 20
40 3)		 Auxiliary heater operation relay -J485-
Low heat output relay -J359-3)
SB36 – Not used
SB37 – Not used
SB38 – Not used
SB39 – Not used
SB40 – Not used
SB41 – Not used
SB42 – Not used
SB43 – Not used
SB44 – Not used
SB45 – Not used
SB46 – Not used
SB47 40 Onboard supply control unit -J519-
SB48 40 Onboard supply control unit -J519-
SB49 50 Terminal 15 voltage supply relay -J329-
Fuse 6 on fuse holder C -SC6- to fuse 11 on fuse holder C -SC11-
Fuse 20 on fuse holder C -SC20-
Fuse 21 on fuse holder C -SC21-
Fuse 39 on fuse holder C -SC39-
Fuse 18 on fuse holder C -SC18-4)
SB50 – Not used
SB51 60 3) High heat output relay -J360-3)
SB52 60 Heated windscreen relay -J47-
SB53 50 X-contact relief relay -J59-
SB54 50 Automatic glow period control unit -J179-3)
Relays
A1 Current bridge
Relay for gas shut-off valves -J908-
A2 Continued coolant circulation relay -J151- (100)
A3 Vacant
A4 Main relay -J271- (100)
1) Only models with automatic gearbox
2) Only models with dual clutch gearbox
3) Only for countries with hot climate
4) Only models with start/stop system
5) Only models with navigation system
6) Only models with radio
7) Only models with start/stop system
8) Only models with equipment for Korea

Fuse holder A -SA- , on E-box low

Volkswagen Passat B7 - fuse box diagram - Fuse holder A -SA- on E-box low
Volkswagen Passat B7 – fuse box diagram – Fuse holder A -SA- on E-box low
№
 A
 Function/component
SA1 150/180 1) Alternator -C-
SA2 80 Electromechanical power steering motor -V187-
SA3 50 Radiator fan control unit -J293-
SA4 60 Fuse 12 on fuse holder C -SC12- to fuse 17 on fuse holder C -SC17- ,
Fuse 22 on fuse holder C -SC22- to fuse 27 on fuse holder C -SC27- ,
Fuse 28 on fuse holder C -SC28- ,
Fuse 44 on fuse holder C -SC44- ,
Fuse 46 on fuse holder C -SC46-
SA5 80 Fuse 29 on fuse holder C -SC29- to fuse 31 on fuse holder C -SC31-
SA6 70 Fuse 32 on fuse holder C -SC32- to fuse 37 on fuse holder C -SC37-
SA7 60 Second battery charging circuit relay -J713-
High heat output relay -J360-
Fuse 38 on fuse holder C -SC38-
Fuse 43 on fuse holder C -SC43-
Fuse 45 on fuse holder C -SC45-
SA8 40 ABS control unit -J104-
1) Only vehicles with 180 A alternator, fitted in alternator wire

Fuse holder A -SA- , on E-box high

Volkswagen Passat B7 - fuse box diagram - Fuse holder A -SA- on E-box high
Volkswagen Passat B7 – fuse box diagram – Fuse holder A -SA- on E-box high
№
 A
 Function/component
SA1 150/180 1) Alternator -C-
SA2 80 Electromechanical power steering motor -V187-
SA3 60 Fuse 32 on fuse holder C -SC32- to fuse 37 on fuse holder C -SC37-
SA4 50 Radiator fan control unit -J293-
SA5 – Not used
SA6 80 Fuse 29 on fuse holder C -SC29- to fuse 31 on fuse holder C -SC31-
SA7 40 ABS control unit -J104-
1) Only vehicles with 180 A alternator, fitted in alternator wire

Fuse holder D -SD- on right in dash panel

Volkswagen Passat B7 - fuse box diagram - Fuse holder D -SD- , on right of dash panel
Volkswagen Passat B7 – fuse box diagram – Fuse holder D -SD- , on right of dash panel
№
 A
 Function/component
1
30
15 2)
Rear lid control unit -J605-1)
Trailer detector control unit -J345-2)
2
30
20 2)
Rear lid control unit 2 -J756-1)
Trailer detector control unit -J345-2)
3
30
15 2)
Sunroof roller blind control unit -J394-1)
Trailer detector control unit -J345-2)
4
15
–
Electronically controlled damping control unit -J250-
Not used2)
5 – Not used
6 – Not used
7 – Not used
8 – Not used
9 – Not used
10 – Not used
11 – Not used
12 – Not used
13 Special vehicles
14 Special vehicles
15 Special vehicles
16 Charging station for hand-held 2-way radio -U24-
Charging station 2 for hand-held 2-way radio -U28-
Charging station 2 for torch -U29-
17 Special vehicles
18 Special vehicles
19 Special vehicles
20 Special vehicles
21 Special vehicles
22 Special vehicles
23 Special vehicles
24 Special vehicles
1) Only estate (left-hand drive models)
2) Only right-hand drive models

Fuse holder F -SF- , luggage compartment, left rear (BWS)

Volkswagen Passat B7 - fuse box diagram - Fuse holder F -SF- , luggage compartment, left rear (BWS)
Volkswagen Passat B7 – fuse box diagram – Fuse holder F -SF- , luggage compartment, left rear (BWS)
№
 A
 Function/component
1 30 Left fuse holder (SC12 – SC17, SC27, SC29 – SC31, SC44)
2 80 Fuses in E-box (SB16 – SB26, SB49, SB50)
3 125 Power supply E-box
4 5 Onboard supply control unit -J519-
Battery monitor control unit -J367-

Heated windscreen relay -J47-

In plenum chamber next to engine control unit -arrow-

Volkswagen Passat B7 - fuse box diagram - Heated windscreen relay -J47-
Volkswagen Passat B7 – fuse box diagram – Heated windscreen relay -J47-

Relay carrier on left under dash panel

Volkswagen Passat B7 - fuse box diagram -Relay carrier on left under dash panel
Volkswagen Passat B7 – fuse box diagram -Relay carrier on left under dash panel
№ Function/component
1 Vacant
2 Vacant
3 Vacant
4 Vacant
5 Vacant
6 Vacant
7 Second battery charging circuit relay -J713- (100)
8 Vacant

Relay carrier on left under dash panel

Volkswagen Passat B7 - fuse box diagram -Relay carrier on left under dash panel
Volkswagen Passat B7 – fuse box diagram -Relay carrier on left under dash panel
№ Function/component
1 Heated rear window relay -J9- (645)
2 Terminal 15 voltage supply relay -J329- (645)
3 Dual tone horn relay -J4- (646)
Headlight washer system relay -J39- (646)
4 Trailer voltage supply relay -J941- (from May 2012)
Vacant
5 X-contact relief relay -J59- (644)

Relay carrier under electronics box in engine compartment, left

Volkswagen Passat B7 - fuse box diagram -Relay carrier under electronics box in engine compartment, left
Volkswagen Passat B7 – fuse box diagram -Relay carrier under electronics box in engine compartment, left
№
 Function/component
1 Starter relay 1 -J906- (643) – For models with start/stop system only
2 Automatic glow period control unit -J179- (457)
3 Vacant
4 Low heat output relay -J359- (53)
5 High heat output relay -J360- (100)
6 Starter relay 2 -J907- (489) – For models with start/stop system only

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Bora (1999 – 2006) – fuse box diagram

Posted on by admin

Volkswagen Bora (1999 – 2006) – fuse box diagram

Year of production: 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006

Instrument Panel Fuse Block

Volkswagen Bora - fuse box diagram - instrument panel
Volkswagen Bora – fuse box diagram – instrument panel
№
 A
 Function/component
1 5 Z4 – Driver side heated exterior mirror (models without ohne electric window regulator)
Z5 – Front passenger side heated exterior mirror (models without ohne electric window regulator)
Z20 – Left washer jet heater element
Z21 – Right washer jet heater element
2 5 E3 – Hazard warning light switch
J1 – Turn signal relay
M5 – Front left turn signal bulb
M6 – Rear left turn signal bulb
M7 – Front right turn signal bulb
M8 – Rear right turn signal bulb
J567 – Left gas discharge light control unit
J568 – gas discharge light control unit with headlight range control right
3 5 J5 – Fog light relay
E20 – Switches and instruments illumination regulator
4 5 X – Number plate lights
5 7.5 E45 – Cruise control system switch
E221 – Operating unit in steering wheel
E227 – Cruise control system button (CCS) SET button
G65 – High pressure sender (air conditioning system)
J131 – Heated driver seat control unit
J132 – Heated front passenger seat control unit
J245 – Sliding sunroof adjustment control unit (models without central locking)
J255 – Climatronic
G266 – Oil level and oil temperature sender
J293 – Radiator fan control unit, multifunction steering wheel
J393 – Convenience system (E231 – Exterior mirror heater button),
J453 – Multifunction steering wheel control unit
J446 – Parking aid control unit
J503 – Control unit with display for radio and navigation system
N147 – 2-way valve for coolant shut-off valve (above F269 – temperature flap position switch)
V154 – Fresh air/recirculated air flap control motor
6 55 Up to April 2001:
J379 – Central locking and anti-theft alarm system control unit
from September 2002:
J651 – Shut-off valve relay 1 (engine code BEH)
7 10 K142 – Selector lever position P/N warning lamp
M16 – Left reversing light bulb
M17 – Right reversing light bulb
8 5 J412 – Mobile telephone operating electronics control unit
9 5 E256 – TCS and ESP button
G85 -Steering angle sender
J104 – ABS/ABS control unit with EDL/ ASR/ ESP
10 15
510		 up to October 2001:
Engine management: Petrol
Engine management: Diesel
from November 2001:
R – Radio (S-contact)
J285 – Display in dash panel insert
J503 – Control unit with display for radio and navigation
11 5 J285 – Control unit with display in dash panel insert
N110 – Selector lever lock solenoid
12 7.5 J412 – Mobile telephone operating electronics control unit
G273 – Interior monitoring sensor
G274 – Interior monitoring sender
T16 – 16-pin connector, (in centre dash panel, self-diagnosis connection)
W11 – Rear left reading light (models with interior monitor)
W12 – Rear right reading light (models with interior monitor)
13 10 F – Brake light switch
M9 – Left brake light bulb (only Golf/Bora)
J…..-.Engine control units
J104 – ABS/ABS control unit with EDL/ ASR/ ESP
M9 – Left brake light bulb (only Golf/Bora)
M10 – Right brake light bulb (only Golf/Bora)
M21 – Left brake and tail light bulb (only Golf Variant/Bora Variant)
M25 – High level brake light bulb
14 10 J393 – Convenience system central control unit (models without central lock)
J546 – Rear lid remote release control unit
models without central lock:
M27 – Left door warning lamp
M28 – Right door warning lamp
W – Front interior light
W3 – Luggage compartment light
W11 – Rear left reading light
W12- Rear right reading light
W14 – Illuminated vanity mirror (front passenger side)
W18 – Luggage compartment light on left
W19 – Reading light/driver side
W20 – Illuminated vanity mirror (driver side)
15 5 G85 – Steering angle sender
J217 – Automatic gearbox control unit
J285 – Control unit with display in dash panel insert
16 10 J255 – Climatronic
J293 – Radiator fan control unit
17 – –
18 10 J285 – Control unit with display in dash panel insert
L2 – Right twin filament bulb (only Bora)
M32 – Right main beam bulb (only Golf)
19 10 L1 – Left twin filament bulb (only Bora)
M30 – Left headlight main beam bulb (only Golf)
20 15 E102 – Headlight range control regulator
J427 – Right headlight starter for gaseous discharge light
J568 – Gas discharge light control unit with headlight range control right
L2 – Right twin filament bulb (only Bora)
M31 – Right headlight dipped beam bulb (only Golf)
V48 – Left headlight range control motor
V49 – Right headlight range control motor
21 15 L1 – Left twin filament bulb (only Bora),
M29 – Left headlight dipped beam bulb (only Golf)
J426 – Left headlight starter for gaseous discharge light,
J567 – Gas discharge light control unit with headlight range control left
22 5 J285 – Control unit with display in dash panel insert
M3 – Right side light bulb
23 5 J285 – Control unit with display in dash panel insert
M1 – Left side light bulb
24 20 E22 – Intermittent wiper switch, windscreen wiper motor
J31 – Automatic intermittent wash and wipe relay
V – Windscreen wiper motor
V59 – Windscreen and rear window washer pump
25 20 E9 – Fresh air blower switch
E35 – Air conditioning system switch
N24 – Fresh air blower series resistor with overheating fuse
V2 – Fresh air blower
J293 – Radiator fan control unit
J255 – Climatronic
J… -Engine control units
26 25 Z1 – Heated rear window
27 15 up to November 2005:
V12 – Rear window wiper motor
from December 2005:
U1 – Cigarette lighter
U5 – 12 V socket, on left in luggage compartment
28 15 G6 – Fuel pump (pre-supply pump)
29 15
2010		 Petrol (not for engine code BDE)
Engine management: Engine code BDEEngine management: Diesel
30 20 J245 – Sliding sunroof adjustment control unit
V1 – Sliding sunroof motor
31 20

5

 J217 – Automatic gearbox control unit
F125 – Multifunction switch
J542 – Brake servo control unitJ492 – Four-wheel drive control unit (4 Motion)
32 10
30		 Injectors: Petrol
Engine management: Diesel
33 20 J31 – Automatic intermittent wash and wipe relay
V11 – Headlight washer system pump
34 10 Engine management
35 30 U10 – Trailer socket
up to November 2005:
U5-12 V socket, on left in luggage compartment
36 15 J5 – Fog light relay
L22 – Left fog light bulb
L23 – Right fog light bulb
L46 – Rear left fog light bulb
J285 – Control unit with display in dash panel insert
37 15
510		 up to October 2001:
J285 – Control unit with display in dash panel insert
J503 – Control unit with display for radio and navigation system
R – Radio, S-contact
from November 2001:
Engine management: Petrol
Engine management: Diesel
38 15 E204 – Tank filler flap remote release switch
J379 – Central locking and anti-theft alarm system control unit
J386 – Driver door control unit
J387 – Front passenger door control unit
J388 – Rear left door control unit
J389 – Rear right door control unit
J398 – Rear lid remote release relay
V155- Tank filler flap locking motor
39 15 E3 – Hazard warning light switch
J1 – Turn signal relay
J567 – Gas discharge light control unit with headlight range control right
J568 – Gas discharge light control unit with headlight range control right
M5 – Front left turn signal bulb
M6 – Rear left turn signal bulb
M7 – Front right turn signal bulb
M8 – Rear right turn signal bulb
40 20 H1 – Dual tone horn
41 15 U1-Cigarette lighter (up to November 2005)
42 25 R – Radio
R12 – Amplifier
J503 – Control unit with display for radio and navigation system
J415 – Navigation system tuner for TV
J559 – Traffic information control unit
43 10 Engine management
44 15 J131 -Heated driver seat control unit
J132 -Heated front passenger seat control unit

Position of fuses in fuse holder/battery

Up to August 2000

Volkswagen Bora - fuse box diagram - position of fuses in fuse holder/battery
Volkswagen Bora – fuse box diagram – position of fuses in fuse holder/battery

From September 2000

Volkswagen Bora - fuse box diagram - position of fuses in fuse holder/battery
Volkswagen Bora – fuse box diagram – position of fuses in fuse holder/battery
№
 A
 Function/component
S162 50 Heated pin heating
S163 50 Engine management
S164 40 Radiator fan
S176 110 Interior
S177 110
150		 Alternator (90 A)
Alternator (120 A)
S178 30 ABS (pump)
S179 30 ABS
S180 30 Radiator fan

Position of relays and fuses

Volkswagen Bora- fuse box diagram - position of relays and fuses
Volkswagen Bora- fuse box diagram – position of relays and fuses
Fuse locations on relay plate
A – Seat adjustment fuse
B – Fuses for V192 – Vacuum pump for brakes (from May 2002)
C – Window regulator fuse, central locking and heated exterior mirror (only models with convenience system and window regulator)
Relay positions on relay plate
1 J4 – Dual tone horn relay (53)
2 J59 – X-contact relief relay (18) J59 – X-contact relief relay (100)
3 Vacant
4 J17 – Fuel pump relay (409) J52 – Glow plug relay (103)
V/VI J31 – Automatic intermittent wash and wipe relay, without headlight washer system (377), -with headlight washer system (389), -with rain sensor (192)
Relay locations on the 13 position additional relay carrier above the relay plate, left-handdrive vehicles
1 Vacant
2 J398 – Rear lid remote release relay (79)
J546 – Rear lid remote release control unit (407)
3 Vacant
4 J5 – Fog light relay (53)
5 J453 – Multifunction steering wheel control unit (450)
6 J453 – Multifunction steering wheel control unit (450)
7 J508 – Brake light suppression relay (206)
8 J99 – Heated exterior mirror relay (53)
J541 – Coolant shut-off valve relay (53)
9 J17 – Fuel pump relay, four-wheel-diesel, (53)
10 J17 – Fuel pump relay (pre-supply pump) (167)
11 J226 – Starter inhibitor and reversing light relay (175)
12 J317 – Terminal 30 voltage supply relay (109)
13 J151 – Continued coolant circulation relay (53)
Fuse locations on 13 position additional relay carrier, left-handdrive vehicles:
D – Vacant
E – Vacant
F 15A S30 – Rear window wiper single fuse (from December 2005),
S144 – Anti-theft alarm system central locking fuse (ATA turn signal)
G 15A S111 – Anti-theft alarm system fuse (ATA horn)
1 J453 – Multifunction steering wheel control unit (450)
2 J453 – Multifunction steering wheel control unit (450)
3 J5 – Fog light relay (53)
4 Vacant
5 J398 – Rear lid remote release relay (79)
J546 – Rear lid remote release control unit (407)
6 Vacant
7 J151 – Continued coolant circulation relay (53)
8 J317 – Terminal 30 voltage supply relay (109)
9 J226 – Starter inhibitor and reversing light relay (175)
10 J17 – Fuel pump relay (pre-supply pump) (167)
11 J17 – Fuel pump relay, four-wheel-diesel, (53)
12 J99 – Heated exterior mirror relay (53)
J541 – Coolant shut-off valve relay (53)
J193 – Cigarette lighter relay (53)
13 J508 – Brake light suppression relay (206)
D 15A S144 – Anti-theft alarm system central locking fuse (ATA turn signal)
E 15A S111 – Anti-theft alarm system fuse (ATA horn)
S30 – Rear window wiper single fuse (from December 2005)
F – Vacant
G – Vacant

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Golf (1999 – 2006) – fuse box diagram

Posted on by admin

Volkswagen Golf (1999 – 2006) – fuse box diagram

Year of production: 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006

Instrument Panel Fuse Block

Volkswagen Golf - fuse box diagram - instrument panel
Volkswagen Golf – fuse box diagram – instrument panel
№
 A
 Function/component
1 5 Z4 – Driver side heated exterior mirror (models without ohne electric window regulator)
Z5 – Front passenger side heated exterior mirror (models without ohne electric window regulator)
Z20 – Left washer jet heater element
Z21 – Right washer jet heater element
2 5 E3 – Hazard warning light switch
J1 – Turn signal relay
M5 – Front left turn signal bulb
M6 – Rear left turn signal bulb
M7 – Front right turn signal bulb
M8 – Rear right turn signal bulb
J567 – Left gas discharge light control unit
J568 – gas discharge light control unit with headlight range control right
3 5 J5 – Fog light relay
E20 – Switches and instruments illumination regulator
4 5 X – Number plate lights
5 7.5 E45 – Cruise control system switch
E221 – Operating unit in steering wheel
E227 – Cruise control system button (CCS) SET button
G65 – High pressure sender (air conditioning system)
J131 – Heated driver seat control unit
J132 – Heated front passenger seat control unit
J245 – Sliding sunroof adjustment control unit (models without central locking)
J255 – Climatronic
G266 – Oil level and oil temperature sender
J293 – Radiator fan control unit, multifunction steering wheel
J393 – Convenience system (E231 – Exterior mirror heater button),
J453 – Multifunction steering wheel control unit
J446 – Parking aid control unit
J503 – Control unit with display for radio and navigation system
N147 – 2-way valve for coolant shut-off valve (above F269 – temperature flap position switch)
V154 – Fresh air/recirculated air flap control motor
6 5

5

 Up to April 2001:
J379 – Central locking and anti-theft alarm system control unit
from September 2002:
J651 – Shut-off valve relay 1 (engine code BEH)
7 10 K142 – Selector lever position P/N warning lamp
M16 – Left reversing light bulb
M17 – Right reversing light bulb
8 5 J412 – Mobile telephone operating electronics control unit
9 5 E256 – TCS and ESP button
G85 -Steering angle sender
J104 – ABS/ABS control unit with EDL/ ASR/ ESP
10 15
5

10

 up to October 2001:
Engine management: Petrol
Engine management: Diesel
from November 2001:
R – Radio (S-contact)
J285 – Display in dash panel insert
J503 – Control unit with display for radio and navigation
11 5 J285 – Control unit with display in dash panel insert
N110 – Selector lever lock solenoid
12 7.5 J412 – Mobile telephone operating electronics control unit
G273 – Interior monitoring sensor
G274 – Interior monitoring sender
T16 – 16-pin connector, (in centre dash panel, self-diagnosis connection)
W11 – Rear left reading light (models with interior monitor)
W12 – Rear right reading light (models with interior monitor)
13 10 F – Brake light switch
M9 – Left brake light bulb (only Golf/Bora)
J…..-.Engine control units
J104 – ABS/ABS control unit with EDL/ ASR/ ESP
M9 – Left brake light bulb (only Golf/Bora)
M10 – Right brake light bulb (only Golf/Bora)
M21 – Left brake and tail light bulb (only Golf Variant/Bora Variant)
M25 – High level brake light bulb
14 10 J393 – Convenience system central control unit (models without central lock)
J546 – Rear lid remote release control unit
models without central lock:
M27 – Left door warning lamp
M28 – Right door warning lamp
W – Front interior light
W3 – Luggage compartment light
W11 – Rear left reading light
W12- Rear right reading light
W14 – Illuminated vanity mirror (front passenger side)
W18 – Luggage compartment light on left
W19 – Reading light/driver side
W20 – Illuminated vanity mirror (driver side)
15 5 G85 – Steering angle sender
J217 – Automatic gearbox control unit
J285 – Control unit with display in dash panel insert
16 10 J255 – Climatronic
J293 – Radiator fan control unit
17 – –
18 10 J285 – Control unit with display in dash panel insert
L2 – Right twin filament bulb (only Bora)
M32 – Right main beam bulb (only Golf)
19 10 L1 – Left twin filament bulb (only Bora)
M30 – Left headlight main beam bulb (only Golf)
20 15 E102 – Headlight range control regulator
J427 – Right headlight starter for gaseous discharge light
J568 – Gas discharge light control unit with headlight range control right
L2 – Right twin filament bulb (only Bora)
M31 – Right headlight dipped beam bulb (only Golf)
V48 – Left headlight range control motor
V49 – Right headlight range control motor
21 15 L1 – Left twin filament bulb (only Bora),
M29 – Left headlight dipped beam bulb (only Golf)
J426 – Left headlight starter for gaseous discharge light,
J567 – Gas discharge light control unit with headlight range control left
22 5 J285 – Control unit with display in dash panel insert
M3 – Right side light bulb
23 5 J285 – Control unit with display in dash panel insert
M1 – Left side light bulb
24 20 E22 – Intermittent wiper switch, windscreen wiper motor
J31 – Automatic intermittent wash and wipe relay
V – Windscreen wiper motor
V59 – Windscreen and rear window washer pump
25 20 E9 – Fresh air blower switch
E35 – Air conditioning system switch
N24 – Fresh air blower series resistor with overheating fuse
V2 – Fresh air blower
J293 – Radiator fan control unit
J255 – Climatronic
J… -Engine control units
26 25 Z1 – Heated rear window
27 15 up to November 2005:
V12 – Rear window wiper motor
from December 2005:
U1 – Cigarette lighter
U5 – 12 V socket, on left in luggage compartment
28 15 G6 – Fuel pump (pre-supply pump)
29 15
20

10

 Petrol (not for engine code BDE)
Engine management: Engine code BDE

Engine management: Diesel
30 20 J245 – Sliding sunroof adjustment control unit
V1 – Sliding sunroof motor
31 20

5

 J217 – Automatic gearbox control unit
F125 – Multifunction switch
J542 – Brake servo control unit

J492 – Four-wheel drive control unit (4 Motion)
32 10
30		 Injectors: Petrol
Engine management: Diesel
33 20 J31 – Automatic intermittent wash and wipe relay
V11 – Headlight washer system pump
34 10 Engine management
35 30 U10 – Trailer socket
up to November 2005:
U5-12 V socket, on left in luggage compartment
36 15 J5 – Fog light relay
L22 – Left fog light bulb
L23 – Right fog light bulb
L46 – Rear left fog light bulb
J285 – Control unit with display in dash panel insert
37 15
5

10

 up to October 2001:
J285 – Control unit with display in dash panel insert
J503 – Control unit with display for radio and navigation system
R – Radio, S-contact
from November 2001:
Engine management: Petrol
Engine management: Diesel
38 15 E204 – Tank filler flap remote release switch
J379 – Central locking and anti-theft alarm system control unit
J386 – Driver door control unit
J387 – Front passenger door control unit
J388 – Rear left door control unit
J389 – Rear right door control unit
J398 – Rear lid remote release relay
V155- Tank filler flap locking motor
39 15 E3 – Hazard warning light switch
J1 – Turn signal relay
J567 – Gas discharge light control unit with headlight range control right
J568 – Gas discharge light control unit with headlight range control right
M5 – Front left turn signal bulb
M6 – Rear left turn signal bulb
M7 – Front right turn signal bulb
M8 – Rear right turn signal bulb
40 20 H1 – Dual tone horn
41 15 U1-Cigarette lighter (up to November 2005)
42 25 R – Radio
R12 – Amplifier
J503 – Control unit with display for radio and navigation system
J415 – Navigation system tuner for TV
J559 – Traffic information control unit
43 10 Engine management
44 15 J131 -Heated driver seat control unit
J132 -Heated front passenger seat control unit

Position of fuses in fuse holder/battery

Up to August 2000

Volkswagen Golf - fuse box diagram - position of fuses in fuse holder/battery
Volkswagen Golf – fuse box diagram – position of fuses in fuse holder/battery

From September 2000

Volkswagen Golf - fuse box diagram - position of fuses in fuse holder/battery
Volkswagen Golf – fuse box diagram – position of fuses in fuse holder/battery
№
 A
 Function/component
S162 50 Heated pin heating
S163 50 Engine management
S164 40 Radiator fan
S176 110 Interior
S177 110
150		 Alternator (90 A)
Alternator (120 A)
S178 30 ABS (pump)
S179 30 ABS
S180 30 Radiator fan

Position of relays and fuses

Volkswagen Golf - fuse box diagram - position of relays and fuses
Volkswagen Golf – fuse box diagram – position of relays and fuses
Fuse locations on relay plate
A – Seat adjustment fuse
B – Fuses for V192 – Vacuum pump for brakes (from May 2002)
C – Window regulator fuse, central locking and heated exterior mirror (only models with convenience system and window regulator)
Relay positions on relay plate
1 J4 – Dual tone horn relay (53)
2 J59 – X-contact relief relay (18) J59 – X-contact relief relay (100)
3 Vacant
4 J17 – Fuel pump relay (409) J52 – Glow plug relay (103)
V/VI J31 – Automatic intermittent wash and wipe relay, without headlight washer system (377), -with headlight washer system (389), -with rain sensor (192)
Relay locations on the 13 position additional relay carrier above the relay plate, left-handdrive vehicles
1 Vacant
2 J398 – Rear lid remote release relay (79)
J546 – Rear lid remote release control unit (407)
3 Vacant
4 J5 – Fog light relay (53)
5 J453 – Multifunction steering wheel control unit (450)
6 J453 – Multifunction steering wheel control unit (450)
7 J508 – Brake light suppression relay (206)
8 J99 – Heated exterior mirror relay (53)
J541 – Coolant shut-off valve relay (53)
9 J17 – Fuel pump relay, four-wheel-diesel, (53)
10 J17 – Fuel pump relay (pre-supply pump) (167)
11 J226 – Starter inhibitor and reversing light relay (175)
12 J317 – Terminal 30 voltage supply relay (109)
13 J151 – Continued coolant circulation relay (53)
Fuse locations on 13 position additional relay carrier, left-handdrive vehicles:
D – Vacant
E – Vacant
F 15A S30 – Rear window wiper single fuse (from December 2005),
S144 – Anti-theft alarm system central locking fuse (ATA turn signal)
G 15A S111 – Anti-theft alarm system fuse (ATA horn)
1 J453 – Multifunction steering wheel control unit (450)
2 J453 – Multifunction steering wheel control unit (450)
3 J5 – Fog light relay (53)
4 Vacant
5 J398 – Rear lid remote release relay (79)
J546 – Rear lid remote release control unit (407)
6 Vacant
7 J151 – Continued coolant circulation relay (53)
8 J317 – Terminal 30 voltage supply relay (109)
9 J226 – Starter inhibitor and reversing light relay (175)
10 J17 – Fuel pump relay (pre-supply pump) (167)
11 J17 – Fuel pump relay, four-wheel-diesel, (53)
12 J99 – Heated exterior mirror relay (53)
J541 – Coolant shut-off valve relay (53)
J193 – Cigarette lighter relay (53)
13 J508 – Brake light suppression relay (206)
D 15A S144 – Anti-theft alarm system central locking fuse (ATA turn signal)
E 15A S111 – Anti-theft alarm system fuse (ATA horn)
S30 – Rear window wiper single fuse (from December 2005)
F – Vacant
G – Vacant

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Audi S3 (8L; 1996 – 2003) – fuse box diagram

Posted on by admin

Audi S3 (8L; 1996 – 2003) – fuse box diagram

Year of production: 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003

Fitting locations

Audi S3 8L - fuse box diagram - location
Audi S3 8L – fuse box diagram – location

1 –  Relay carrier (3-pin) / fuse carrier
2 –  Micro-central electrics
2 –  Relay carrier (13-pin)
3 –  Fuse holder
4 –  Main fuse box / battery

Fuse box driver side dash panel

Audi S3 8L - fuse box diagram - driver side dash panel
Audi S3 8L – fuse box diagram – driver side dash panel
№
 A
 Function/component
1 10 S1 – Fuse in relay plate fuse holder
Z20 – Left washer jet heater element 75x
Z21 – Right washer jet heater element
Z4 – Driver side heated exterior mirror
Z5 – Front passenger side heated exterior mirror
2 10 M5 – Front left turn signal bulb
M7 – Front right turn signal bulb
M18 – Left side mounted turn signal bulb
M19 – Right side repeater turn signal bulb
3 5 Illuminations:
W6 – Glove compartment light
E87 – Operating and display unit for Climatronic air conditioning system
4 5 X-number plate light
5 7.5 E87 – Operating and display unit for Climatronic air conditioning system
E45 – Cruise control system switch
E94 – Heated driver seat regulator
E95 – Heated front passenger seat regulator
E159 – Fresh air and air recirculation flap switch
E221 – Operating unit in steering wheel1)
F269 – Temperature flap position switch
G65 – High pressure sender
J293 – Radiator fan control unit
J401 – Navigation system with CD drive control unit
J402 – Navigation operating electronics control unit
J446 – Parking aid control unit
J453 – Multifunction steering wheel control unit
R – Radio
Y7 – Automatic anti-dazzle interior mirror
6 5 E150 – Driver side interior locking switch
V94 – Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system
7 10 F189 – Tiptronic switch
G22 – Speedometer sender
G266 – Oil level and oil temperature sender
J226 – Starter inhibitor and reversing light relay
M16 – Left reversing light bulb
M17 – Right reversing light bulb
8 5 J526 – Telephone and telematics control unit
J412 – Mobile telephone operating electronics control unit
R36 – Telephone transmitter and receiver unit
9 5 E132 – Traction control system switch
G85 – Steering angle sender
J104 – ABS control unit
10 15 Engine management petrol engine:
J220 – Motronic control unit2)
J271 – Motronic current supply relay2)
J363 – Current supply relay for Simos control unit2)
10 5 Engine management diesel engine:
J248 – Diesel direct injection system control unit2)
10 10 J285 – Control unit in dash panel insert3)
J402 – Navigation operating electronics control unit3)
R – Radio3)
V94 – Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system3)
11 5 G266 – Oil level and oil temperature sender
J17 – Fuel pump relay
J285 – Control unit in dash panel insert
K2 – Alternator warning lamp
K14 – Handbrake warning lamp
K29 – Glow period warning lamp
K132 – Electronic power control fault lamp
K149 – Engine electronics warning lamp
N110 – Selector lever lock solenoid
V48 – Left headlight range control motor
V49 – Right headlight range control motor
12 7.5 J401 – Navigation system with CD drive control unit
J412 – Mobile telephone operating electronics control unit
J526 – Telephone and telematics control unit
R36 – Telephone transmitter and receiver unit
R86 – Aerial amplifier for mobile telephone
T16 – 16-pin connector, black, shelf centre console (diagnostic connector)
13 10 M9 – Left brake light bulb
M10 – Right brake light bulb
M25 – High-level brake light bulb
14 10 J452 – Door warning lamps control unit
V94 – Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system
W – Front interior light
W14 – Front passenger side illuminated vanity mirror
W20 – Driver side illuminated vanity mirror
15 5 E87 – Operating and display unit for Climatronic air conditioning system
G85 – Steering angle sender
J217 – Automatic gearbox control unit
J285 – Control unit in dash panel insert
16 10 J293-Radiator fan control unit
17 7.5 Z22 – Left lock cylinder heater element
Z23 – Right lock cylinder heater element
18 10 L2 – Right headlight twin filament bulb (main beam)
K1 – Main beam warning lamp
19 10 L1 – Left headlight twin filament bulb (main beam)
20 15 E102 – Headlight range control regulator
J124 – Rear bulb monitoring device
J344 – Right gas discharge light control unit
L2 – Right headlight twin filament bulb (dipped beam)
V48 – Left headlight range control motor
V49 – Right headlight range control motor
21 15 J124 – Rear bulb monitoring device
J343 – Left gas discharge light control unit
L1 – Left headlight twin filament bulb (dipped beam)
22 5 J285 – Control unit in dash panel insert
M2 – Right tail light bulb
M3 – Right side light bulb
23 5 J285 – Control unit in dash panel insert
M1 – Left side light bulb
M4 – Left tail light bulb
24 20 J31 – Automatic intermittent wash and wipe relay
25 25 E87 – Operating and display unit for air conditioning system/Climatronic
V2 – Fresh air blower
26 25 Z1 -Heated rear window
27 15 J30-Rear window wiper and washer relay
V12 -Rear window wiper motor
28 15
204)		 J17-Fuel pump relay
29 15 Engine management petrol engine:
J220 – Motronic control unit
J271 – Motronic current supply relay
J361 – Simos control unit
J363 – Current supply relay for Simos control unit
N122 – Output stage
29 5 Engine management diesel engine:
J248 – Diesel direct injection system control unit 5)
29 10 Engine management diesel engine:
J248 – Diesel direct injection system control unit 6)
30 20 J245-Sliding sunroof adjustment control unit
31 20 J217 – Automatic gearbox control unit
J539 – Brake servo control unit
31 5 J492-Four-wheel drive control unit
32 10 Engine management petrol engine:
N30-Injector, cylinder 1
N31-Injector, cylinder 2
N32-Injector, cylinder 3
N33-Injector, cylinder 4
32 30 Engine management diesel engine:
J248-Diesel direct injection system control unit
33 20 J31 – Automatic intermittent wash and wipe relay
34 10 Engine management petrol engine:
N75 – Charge pressure control solenoid valve
N79 – Heater element for crankcase breather
N112 – Secondary air inlet valve
N156 – Variable intake manifold change-over valve
N249 – Turbocharger air recirculation valve
N205 – Inlet camshaft control valve 1
34 10 Engine management diesel engine:
G70 – Air mass meter
G80 – Needle lift sender
N18 – Exhaust gas recirculation valve
N75 – Charge pressure control solenoid valve
N239 – Variable intake manifold flap change-over valve
35 30 U10 -Trailer socket
36 15 L46 – Rear left fog light bulb
L22 – Left fog light bulb
L23 – Right fog light bulb
37 10 J285 – Control unit in dash panel insert2)
J402 – Navigation operating electronics control unit2)
R – Radio2)
V94 – Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system²)
37 20 Engine management petrol engine:
J220 – Motronic control unit3)
J271 – Motronic current supply relay3)
J363 – Current supply relay for Simos control unit3)
37 5 Engine management diesel engine:
J248 – Diesel direct injection system control unit3)
38 10 E150 – Driver side interior locking switch
F248 – Release button for rear lid lock cylinder
J347 – Ultrasonic sensor control unit
V94 – Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system
39 15 Hazard warning lights system :
M5 – Front left turn signal bulb
M7 – Front right turn signal bulb
M6 – Rear left turn signal bulb
M8 – Rear right turn signal bulb
M18 – Left side mounted turn signal bulb
M19 – Right side mounted turn signal bulb
K65 – Left turn signal warning lamp
K94 – Right turn signal warning lamp
40 20 H2 -Treble tone horn
H7 -Bass tone horn
41 15 U1-Cigarette lighter
42 15 J415 – Navigation system tuner for TV
J515 – Aerial selection control unit
R – Radio
R12 – Amplifier
R44 – Amplifier with bass loudspeaker, on left in luggage compartment
R94 – Navigation system interface
43 10 Engine management petrol engine:
G70 – Air mass meter
N80 – Active charcoal filter system solenoid valve 1
Z19 – Lambda probe heater
Z29 – Lambda probe 1 heater after catalytic converter
43 10 Engine management diesel engine:
F36 – Clutch pedal switch
F47 – Brake pedal switch
N79 – Heater element for crankcase breather
J359 – Low heat output relay
J360 – High heat output relay
44 15 Z6 – Heated cushion for driver seat
Z7 – Heated backrest for driver seat
1) is dropped from July 2002
2) is dropped from November 2001
3) applicable from November 2001
4) for models with S3 equipment only
5) is dropped from model year 2002
6) applicable from model year 2002

Relay carrier (3-pin) / fuse carrier

Audi S3 8L - fuse box diagram - relay carrier (3-pin)/fuse carrier
Audi S3 8L – fuse box diagram – relay carrier (3-pin)/fuse carrier
Relays
1 Secondary air pump relay (J299) (petrol engine)
High heat output relay (J360) (diesel engine)
2 Motronic current supply relay (J271) (petrol engine)
Current supply relay for Simos control unit (J363) (petrol engine)
Low heat output relay (J359) (diesel engine)
№
 A
 Function/component
31) 20 Brake vacuum pump fuse S283 (petrol engine)
42) 40 Special vehicle fuse 20 S310 (petrol engine)
1) is dropped from model year 2003
2) is dropped from model year 200

Micro-central electrics

Audi S3 8L - fuse box diagram - micro-central electronics
Audi S3 8L – fuse box diagram – micro-central electronics
Relays
1 J4 – Dual tone horn relay
2 J59 – X-contact relief relay
3 Vacant
4 J17 – Fuel pump relay1)
J52 – Glow plug relay2)
5 J31 – Automatic intermittent wash and wipe relay
6 J31 – Automatic intermittent wash and wipe relay
Fuses
A S44 – Driver seat adjustment thermal fuse 1
S45 – Driver seat adjustment thermal fuse 2
B S283 – Brake vacuum pump fuse3)
C S37 – Window regulator single fuse
1) for models with petrol engines only
2) for models with diesel engines only
3) applicable from model year 2003

Relay carrier (13-pin)

Audi S3 8L - fuse box diagram -relay carrier (13-pin)
Audi S3 8L – fuse box diagram -relay carrier (13-pin)
Relays
1 Vacant
2 J124 – Rear bulb monitoring device
3 J124 – Rear bulb monitoring device
4 J552 – Open window regulator relay, front passenger side
5 J351 – Folding exterior mirror control unit
6 J351 – Folding exterior mirror control unit
7 J508 – Brake light suppression relay
8 J9 – Heated rear window relay
9 J17 – Fuel pump relay1)
10 J17 – Fuel pump relay2)
11 J226 – Starter inhibitor and reversing light relay
12 J322 – Diesel direct injection system relay
13 J397 – Radiator fan run-on relay
J155 – Coolant pump control unit
Fuses
14 Vacant
15 Vacant
16 Vacant
17 S43 – Window regulator thermal fuse
18 S326 – Multifunction steering wheel fuse3)
1) for models with four-wheel only
2) for models with front-wheel drive only
3) applicable from July 2002

Main fuse box

Audi S3 8L - fuse box diagram - main fuse box
Audi S3 8L – fuse box diagram – main fuse box
№
 A
 Function/component
S131 50 Heater glow plugs (diesel engine)
S132 50 Engine management
S133 30 Radiator fan
S134 110 Interior
S138 150 Alternator
S162 30 Fuse 1 (30) in fuse holder on battery

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Audi A3 (8L; 1996 – 2003) – fuse box diagram

Posted on by admin

Audi A3 (8L; 1996 – 2003) – fuse box diagram

Year of production: 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003

Fitting locations

Audi A3 8L - fuse box diagram - location
Audi A3 8L – fuse box diagram – location

1 –  Relay carrier (3-pin) / fuse carrier
2 –  Micro-central electrics
2 –  Relay carrier (13-pin)
3 –  Fuse holder
4 –  Main fuse box / battery

Fuse box driver side dash panel

Audi A3 8L - fuse box diagram - driver side dash panel
Audi A3 8L – fuse box diagram – driver side dash panel
№
 A
 Function/component
1 10 S1 – Fuse in relay plate fuse holder
Z20 – Left washer jet heater element 75x
Z21 – Right washer jet heater element
Z4 – Driver side heated exterior mirror
Z5 – Front passenger side heated exterior mirror
2 10 M5 – Front left turn signal bulb
M7 – Front right turn signal bulb
M18 – Left side mounted turn signal bulb
M19 – Right side repeater turn signal bulb
3 5 Illuminations:
W6 – Glove compartment light
E87 – Operating and display unit for Climatronic air conditioning system
4 5 X-number plate light
5 7.5 E87 – Operating and display unit for Climatronic air conditioning system
E45 – Cruise control system switch
E94 – Heated driver seat regulator
E95 – Heated front passenger seat regulator
E159 – Fresh air and air recirculation flap switch
E221 – Operating unit in steering wheel1)
F269 – Temperature flap position switch
G65 – High pressure sender
J293 – Radiator fan control unit
J401 – Navigation system with CD drive control unit
J402 – Navigation operating electronics control unit
J446 – Parking aid control unit
J453 – Multifunction steering wheel control unit
R – Radio
Y7 – Automatic anti-dazzle interior mirror
6 5 E150 – Driver side interior locking switch
V94 – Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system
7 10 F189 – Tiptronic switch
G22 – Speedometer sender
G266 – Oil level and oil temperature sender
J226 – Starter inhibitor and reversing light relay
M16 – Left reversing light bulb
M17 – Right reversing light bulb
8 5 J526 – Telephone and telematics control unit
J412 – Mobile telephone operating electronics control unit
R36 – Telephone transmitter and receiver unit
9 5 E132 – Traction control system switch
G85 – Steering angle sender
J104 – ABS control unit
10 15 Engine management petrol engine:
J220 – Motronic control unit2)
J271 – Motronic current supply relay2)
J363 – Current supply relay for Simos control unit2)
10 5 Engine management diesel engine:
J248 – Diesel direct injection system control unit2)
10 10 J285 – Control unit in dash panel insert3)
J402 – Navigation operating electronics control unit3)
R – Radio3)
V94 – Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system3)
11 5 G266 – Oil level and oil temperature sender
J17 – Fuel pump relay
J285 – Control unit in dash panel insert
K2 – Alternator warning lamp
K14 – Handbrake warning lamp
K29 – Glow period warning lamp
K132 – Electronic power control fault lamp
K149 – Engine electronics warning lamp
N110 – Selector lever lock solenoid
V48 – Left headlight range control motor
V49 – Right headlight range control motor
12 7.5 J401 – Navigation system with CD drive control unit
J412 – Mobile telephone operating electronics control unit
J526 – Telephone and telematics control unit
R36 – Telephone transmitter and receiver unit
R86 – Aerial amplifier for mobile telephone
T16 – 16-pin connector, black, shelf centre console (diagnostic connector)
13 10 M9 – Left brake light bulb
M10 – Right brake light bulb
M25 – High-level brake light bulb
14 10 J452 – Door warning lamps control unit
V94 – Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system
W – Front interior light
W14 – Front passenger side illuminated vanity mirror
W20 – Driver side illuminated vanity mirror
15 5 E87 – Operating and display unit for Climatronic air conditioning system
G85 – Steering angle sender
J217 – Automatic gearbox control unit
J285 – Control unit in dash panel insert
16 10 J293-Radiator fan control unit
17 7.5 Z22 – Left lock cylinder heater element
Z23 – Right lock cylinder heater element
18 10 L2 – Right headlight twin filament bulb (main beam)
K1 – Main beam warning lamp
19 10 L1 – Left headlight twin filament bulb (main beam)
20 15 E102 – Headlight range control regulator
J124 – Rear bulb monitoring device
J344 – Right gas discharge light control unit
L2 – Right headlight twin filament bulb (dipped beam)
V48 – Left headlight range control motor
V49 – Right headlight range control motor
21 15 J124 – Rear bulb monitoring device
J343 – Left gas discharge light control unit
L1 – Left headlight twin filament bulb (dipped beam)
22 5 J285 – Control unit in dash panel insert
M2 – Right tail light bulb
M3 – Right side light bulb
23 5 J285 – Control unit in dash panel insert
M1 – Left side light bulb
M4 – Left tail light bulb
24 20 J31 – Automatic intermittent wash and wipe relay
25 25 E87 – Operating and display unit for air conditioning system/Climatronic
V2 – Fresh air blower
26 25 Z1 -Heated rear window
27 15 J30-Rear window wiper and washer relay
V12 -Rear window wiper motor
28 15
204)		 J17-Fuel pump relay
29 15 Engine management petrol engine:
J220 – Motronic control unit
J271 – Motronic current supply relay
J361 – Simos control unit
J363 – Current supply relay for Simos control unit
N122 – Output stage
29 5 Engine management diesel engine:
J248 – Diesel direct injection system control unit 5)
29 10 Engine management diesel engine:
J248 – Diesel direct injection system control unit 6)
30 20 J245-Sliding sunroof adjustment control unit
31 20 J217 – Automatic gearbox control unit
J539 – Brake servo control unit
31 5 J492-Four-wheel drive control unit
32 10 Engine management petrol engine:
N30-Injector, cylinder 1
N31-Injector, cylinder 2
N32-Injector, cylinder 3
N33-Injector, cylinder 4
32 30 Engine management diesel engine:
J248-Diesel direct injection system control unit
33 20 J31 – Automatic intermittent wash and wipe relay
34 10 Engine management petrol engine:
N75 – Charge pressure control solenoid valve
N79 – Heater element for crankcase breather
N112 – Secondary air inlet valve
N156 – Variable intake manifold change-over valve
N249 – Turbocharger air recirculation valve
N205 – Inlet camshaft control valve 1
34 10 Engine management diesel engine:
G70 – Air mass meter
G80 – Needle lift sender
N18 – Exhaust gas recirculation valve
N75 – Charge pressure control solenoid valve
N239 – Variable intake manifold flap change-over valve
35 30 U10 -Trailer socket
36 15 L46 – Rear left fog light bulb
L22 – Left fog light bulb
L23 – Right fog light bulb
37 10 J285 – Control unit in dash panel insert2)
J402 – Navigation operating electronics control unit2)
R – Radio2)
V94 – Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system²)
37 20 Engine management petrol engine:
J220 – Motronic control unit3)
J271 – Motronic current supply relay3)
J363 – Current supply relay for Simos control unit3)
37 5 Engine management diesel engine:
J248 – Diesel direct injection system control unit3)
38 10 E150 – Driver side interior locking switch
F248 – Release button for rear lid lock cylinder
J347 – Ultrasonic sensor control unit
V94 – Central locking motor with control unit for interior lights switch-off delay and anti-theft alarm system
39 15 Hazard warning lights system :
M5 – Front left turn signal bulb
M7 – Front right turn signal bulb
M6 – Rear left turn signal bulb
M8 – Rear right turn signal bulb
M18 – Left side mounted turn signal bulb
M19 – Right side mounted turn signal bulb
K65 – Left turn signal warning lamp
K94 – Right turn signal warning lamp
40 20 H2 -Treble tone horn
H7 -Bass tone horn
41 15 U1-Cigarette lighter
42 15 J415 – Navigation system tuner for TV
J515 – Aerial selection control unit
R – Radio
R12 – Amplifier
R44 – Amplifier with bass loudspeaker, on left in luggage compartment
R94 – Navigation system interface
43 10 Engine management petrol engine:
G70 – Air mass meter
N80 – Active charcoal filter system solenoid valve 1
Z19 – Lambda probe heater
Z29 – Lambda probe 1 heater after catalytic converter
43 10 Engine management diesel engine:
F36 – Clutch pedal switch
F47 – Brake pedal switch
N79 – Heater element for crankcase breather
J359 – Low heat output relay
J360 – High heat output relay
44 15 Z6 – Heated cushion for driver seat
Z7 – Heated backrest for driver seat
1) is dropped from July 2002
2) is dropped from November 2001
3) applicable from November 2001
4) for models with S3 equipment only
5) is dropped from model year 2002
6) applicable from model year 2002

Relay carrier (3-pin) / fuse carrier

Audi A3 8L - fuse box diagram - relay carrier (3-pin)/fuse carrier
Audi A3 8L – fuse box diagram – relay carrier (3-pin)/fuse carrier
Relays
1 Secondary air pump relay (J299) (petrol engine)
High heat output relay (J360) (diesel engine)
2 Motronic current supply relay (J271) (petrol engine)
Current supply relay for Simos control unit (J363) (petrol engine)
Low heat output relay (J359) (diesel engine)
№
 A
 Function/component
31) 20 Brake vacuum pump fuse S283 (petrol engine)
42) 40 Special vehicle fuse 20 S310 (petrol engine)
1) is dropped from model year 2003
2) is dropped from model year 200

Micro-central electrics

Audi A3 8L - fuse box diagram - micro-central electronics
Audi A3 8L – fuse box diagram – micro-central electronics
Relays
1 J4 – Dual tone horn relay
2 J59 – X-contact relief relay
3 Vacant
4 J17 – Fuel pump relay1)
J52 – Glow plug relay2)
5 J31 – Automatic intermittent wash and wipe relay
6 J31 – Automatic intermittent wash and wipe relay
Fuses
A S44 – Driver seat adjustment thermal fuse 1
S45 – Driver seat adjustment thermal fuse 2
B S283 – Brake vacuum pump fuse3)
C S37 – Window regulator single fuse
1) for models with petrol engines only
2) for models with diesel engines only
3) applicable from model year 2003

Relay carrier (13-pin)

Audi A3 8L - fuse box diagram -relay carrier (13-pin)
Audi A3 8L – fuse box diagram -relay carrier (13-pin)
Relays
1 Vacant
2 J124 – Rear bulb monitoring device
3 J124 – Rear bulb monitoring device
4 J552 – Open window regulator relay, front passenger side
5 J351 – Folding exterior mirror control unit
6 J351 – Folding exterior mirror control unit
7 J508 – Brake light suppression relay
8 J9 – Heated rear window relay
9 J17 – Fuel pump relay1)
10 J17 – Fuel pump relay2)
11 J226 – Starter inhibitor and reversing light relay
12 J322 – Diesel direct injection system relay
13 J397 – Radiator fan run-on relay
J155 – Coolant pump control unit
Fuses
14 Vacant
15 Vacant
16 Vacant
17 S43 – Window regulator thermal fuse
18 S326 – Multifunction steering wheel fuse3)
1) for models with four-wheel only
2) for models with front-wheel drive only
3) applicable from July 2002

Main fuse box

Audi A3 8L - fuse box diagram - main fuse box
Audi A3 8L – fuse box diagram – main fuse box
№
 A
 Function/component
S131 50 Heater glow plugs (diesel engine)
S132 50 Engine management
S133 30 Radiator fan
S134 110 Interior
S138 150 Alternator
S162 30 Fuse 1 (30) in fuse holder on battery

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Ford Focus (2004 – 2010) – fuse box diagram

Posted on by admin

Ford Focus (2004 – 2010) – fuse box diagram

Year of production: 2004, 2005, 2006, 2007, 2008, 2009, 2010

Passenger Compartment Fuse Box (2004-2007)

Ford Focus - fuse box diagram - passenger compartment
Ford Focus – fuse box diagram – passenger compartment
No. A Protected components
37 10 Left-hand headlight (high beam)
38 10 Right-hand headlight (high beam)
39 20 Cigar lighter, rear auxiliary power socket
40 20 Sliding roof
41 20 Door module (passenger door)
42 7.5 Outside rear view mirror defoggers
43 10 Electronic modules (battery supply)
44 10 OBD II (board computer diagnostics)
45 10 Daytime running lights
46 10 Instrument cluster, GEM module
47 15 Washer pump, heated washer nozzles
48 20 Low beam headlights, daytime running lights
49 15 Headlight switch
50 20 Windshield wiper
51 15 Fuel pump
52 25 Rear window defroster
53 7.5 Parking lamps, side lamps, tail lamps (left-hand side)
54 7.5 Parking lamps, side lamps, tail lamps (right-hand side)
55 20 Door module (driver door), central locking system
56 20 Keyless entry system
57 10 Alarm horn
58 15 Audio modules (battery supply)
59 25 Luggage compartment auxiliary power socket, trailer tow module
60 15 Right-hand headlight (low beam)
61 15 Left-hand headlight (low beam)
62 20 Power seat (driver side)
63 25 Power windows
64 – Not used
65 10 Airbag module
66 7.5 Headlight adjustment switch, low beam headlights, xenon module
67 10 Immobilizer module (WFS), instrument cluster (ignition supply)
68 7.5 Radio, instrument cluster
69 20 Fog light
70 10 Electronic modules (ignition supply)
71 10 Daytime running lights
72 25 GEM
73 7.5 Number plate lights
74 15 Stop light
75 10 Transmission control module, accelerator pedal
76 7.5 Electric parking brake (EPB)
77 25 Central locking relays
78 15 Rear window wiper
79 15 Folding mirror
80 10 Interior lights, outside rear view mirrors
81 20 Door module (right-hand rear)
82 20 Door module (left-hand rear)
83 10 CD-changer, rear seat entertainment (RSE)
84 10 Back-up light, trailer tow module
85 10 Cooling system
86 20 Seat heater
Relay
K1 Rear window defroster
K4 Fuel pump
K5 Daytime running lights

Passenger Compartment Fuse Box (2007-2010)

Ford Focus - fuse box diagram - passenger compartment
Ford Focus – fuse box diagram – passenger compartment
No. A Protected components
100 10 Electronic modules ignition supply
101 20 Electric sunroof control module, driver’s electric seat,
102 10 Heater control, steering column, diesel particulate filter, remote control receiver
103 10 Lighting control battery supply
104 10 Battery saver, interior lamps
105 25 Heated rear window
106 20 Keyless system
107 10 Instrument cluster battery supply, on-board diagnostics
108 7.5 Accessory to cluster (audio and navigation unit)
109 20 Cigar lighter, rear auxiliary power socket
110 10 Daytime running lights ignition supply to lighting control switch
111 15 Fuel pump (petrol engine only)
112 15 Audio modules battery supply
113 10 Daytime running lights (parking lamps)
114 10 Instrument cluster ignition supply, engine immobiliser
115 7.5 Lighting control ignition supply
116 20 Fog lamps
117 7.5 Number plate lamps
118 20 Door module, left-hand rear
119 15 Luggage compartment auxiliary power socket
119 25 Luggage compartment auxiliary power socket (vehicles with trailer tow module)
120 20 Door module, right-hand rear
121 20 Heated front seats
122 10 Airbag module
123 7.5 Heated exterior mirrors
124 7.5 Parking lamps, side lamps, tail lamps (left-hand side)
125 7.5 Parking lamps, side lamps, tail lamps (right-hand side)
126 20 Keyless system
127 25 Electric windows
128 – Not used
129 20 Windscreen wipers
130 – Not used
131 15 Rear window wiper
132 15 Brake lamps
133 25 Central locking relays, passenger door module
134 20 Central locking, driver door module
135 20 Daytime running lights
136 15 Washer pump, heated washer jets
137 10 Battery backup sounder
138 10 Powertrain control module, accelerator pedal, automatic transmission
139 10 Right-hand headlight (high beam)
140 10 Left-hand headlight (high beam)
141 10 Reversing lamp, electric mirrors
142 15 Right-hand headlight (low beam)
143 15 Left-hand headlight (low beam)
Relay
R1 Fuel pump
R2 Not used

Engine Compartment Fuse Box

Ford Focus - fuse box diagram - engine compartment
Ford Focus – fuse box diagram – engine compartment
No. A Protected components
1 60 2004-2007: Cooling fan
40 2007-2010: Cooling fan
2 80 Power steering
3 60 Passenger compartment fuse box supply 1
4 60 Passenger compartment fuse box supply 2
5 80 Auxiliary heater
6 60 Diesel: Glow plug
7 30 ABS, stability control pump
8 20 ABS, stability control valves
9 20 Powertrain control module
10 30 Climate control blower
11 20 Ignition switch
12 40 Ignition relay 15l
13 20 Starter solenoid
14 40 Heated windscreen, right-hand side
15 30 Cooling fan relay (Sigma – non A/C only)
16 40 Heated windscreen, left-hand side
17 30 Electric parking brake
18 30 Power inverter
19 10 ABS module
20 15 Horn
21 20 Diesel: Auxiliary heater
22 10 Power steering module
23 30 Headlamp washer
24 15 Diesel: Pre-heating
25 10 Ignition, relays
26 10 2004-2007: Automatic transmission
15 2007-2010: Automatic transmission
10 ST, RS: PCM continuous supply
27 10 Air conditioning clutch
28 10 Diesel: Glow plug monitoring
29 10 Dual zone climate control
30 3 Powertrain control module, automatic transmission
31 10 Battery sensor smart charging
32 10 2004-2007:
16V+VCT: Ventilation
10 2007-2010: Automatic transmission
10 ST, RS: Fuel injector power supply
33 10 Petrol: Heated oxygen sensors
10 Diesel: Intercooler bypass valve
20 ST, RS: Heated oxygen sensor
34 10 Petrol: Injectors, ignition transformers
10 2004-2007:
Diesel: Fuel pump
35 10 Powertrain control module, valves, solenoids
36 10 Powertrain control module
Relay
R1 Start lock (automatic transmission)
R2 Horn
R3 Back-up light (automatic transmission)
R4  –
R5 Diesel: Pre-heating
16V+VCT: Ventilation
R6 Main
R7 Heated windscreen
R8 Ignition
R9 Headlamp washer
R10 Heater blower
R11 Air conditioning
R12 Cooling fan (without air conditioning)
R13 Starter
R14 Power hold
Cooling fan

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Mercedes M-Class w163 (1997 – 2005) – fuse box diagram

Posted on by admin

Mercedes M-Class w163 (1997 – 2005) – fuse box diagram

Year of production: 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005

Fuse and relay box left rear of engine compartment (Up-To-08/31/01)

Mercedes-Benz M-Class w163 - fuse box diagram - engine compartment
Mercedes-Benz M-Class w163 – fuse box diagram – engine compartment
№
 Fused function A
1 Interior socket (X58/1) 15
2 Instrument cluster (A1):
• Left front indicator lamp (A1e1)
Left front lamp unit (E1):
• Left turn signal lamp (E1e5)
Left left taillamp (E3):
• Left turn signal lamp (E3e1)
Left auxiliary turn signal lamp (E22/1)
Interior connector sleeve, circuit L (Z53/4)
• Trailer hitch connector (X52)		 7,5
3 Right front lamp unit(E2):
• Right high beam (E2e1)		 15
4 Supply of sliding/tilting roof (SHD) circuit 30:
• Sliding/tilting roof motor (SHD) (M12)		 30
5 Left front lamp unit (E1):
• Left high beam (E1e1)
Instrument duster (A1):
• High beam indicator lamp (A1e3)		 7,5
6 Rear-end door wiper motor (M6/4) 7,5
7 Combination switch (S4):
• Hazard flasher switch (S6/1s1)
• Windshield washer system switch (S4s4)
• Wipe switch (S4s5)
Wiper motor (M6/1)
Relay k17: Front wiper interval relay		 15
8 Transfer case control unit (N78) 25
9 Instrument duster (A1)
License plate illumination:
• Left rear-end door license plate lamp (Е19/ 3V right rear-end door license plate lamp (E19/4)
• License plate lamp, left spare wheel carrier (E19/5)/ license plate lamp, right spare wheel carrier (E19/6)
Cockpit connector sleeve, drcuit 58d (Z50/ 1):
• Left vent window switch (S21/13y right vent window switch (S21/14) (light emitting diodes)
• Left front SIH switch (S51/1У right front SIH switch (S51/2) (light emitting diodes)
• Heater/AC switch (S98) (light emitting diodes)
• 2-way switch combination (S97/6) (light emitting diodes)
• ESP OFF switch (S76/6) (light emitting diodes)
• Outside mirror switch, folding in and out (S50/1) (light emitting diode)
• Electric headlamp range adjustment selector (SI/1) (light emitting diode)
• Rear window wipe/wash switch (S78) (light emitting diode)
• Tlltlng/slidlng roof switch (S13/2) (light emitting diode)
• Backup lamp switch (S16/2)
• Illumination (R3e1)
• Center console switch group (S21)		 7,5
10 Radio (A2) Roof connector sleeve, arcuit 15R (Z54/1):
• Left sun visor with Illuminated mirror (Е14/1)
• Right sun visor with illuminated mirror (E14/2)
• Trip computer control unit (N41)
• Automatic dimming Inside rearview mirror (H7)
Front cigar lighter (with ashtray illumination) R3
• Heating element (R3r1)
Glove compartment lamp (E13/1)
Instrument cluster (A1):
• Airbag Indicator and warning light (A1e15)		 10
11 Hot-film mass air flow sensor (B2/5)
Camshaft position sensor (L5/1)
Fuel injection valves (Y62)
In the case of M111:
• HFM control module (N3/4)		 10
12 Interior connector sleeve, circuit 58L (Z53/6):
• Trailer hitch connector (X52)
• Left taillamp (E3):
• Left taillamp and parking lamp (E3e2)
Left front lamp unit (E1):
• Left standing and parking lamp (E1e3)
• Left slde-marker lamp (E1e6)		 7,5
13 Roof connector sleeve, circuit 30 (Z54/2):
• Front dome lamp (with shut-off delay and front reading lamp) (E15/2)
• Rear interior lamp (E15/3)
• Dome lamp in left rear (E15/8)
• Dome lamp In right rear (E15/9)
• Trip computer control unit (N41)
Instrument cluster (A1):
• Seat belt warning lamp (A1E9)
Steering angle sensor (N49)
Datallnk connector (X11/4)		 10
14 With diesel:
Injection timing device
Exhaust gas recirculation valve		 10
15 Interior connector sleeve, circuit 54 (Z52/6):
Left left taillamp (E3):
• Left stop lamp (E3e4) Right taillamp (E4):
• Right stop lamp (E4e4)
• Center-high mounted stop lamp (E21)
• Center high-mounted stop lamp, spare wheel carrier (E35)
• Trailer hitch connector (X52)		 10
16 Diagnostic connector (X11/4)
Reversing lamp switch (S16/2)
Cockpit connector sleeve, circuit 15 (Z50/2):
• Air conditioning control unit (N19)
• Heater/AC switch (S98):
• Blower switch (S98s1)
• Thermostat (S98p1)
• Recirculated air switch Indicator lamp (S98h1)
• llumination (S98e1)
• Switch illumination (S98e2)
• Recirculated air switch (S98s2)
• Air conditioning On indicator lamp (S98h2)
• Switch Illumination (S98e2)
• Air conditioning On switch (S98s3)
• Recirculated air flap actuator motor (M39)
• Air conditioning control unit (N19)		 15
17 Cargo area connector box (X58/4) 15
18 Trailer hitch connector (X52) 25
19 M111:
HFM control module (N3/4)
Adjustable camshaft timing solenoid (Y49)
Activated charcoal filter shutoff valve (Y58)
M112/113:
Terminal 87 M2e connector sleeve (Z7/36)
• Intake manifold switchover valve (Y22/5)
• EGR switchover valve (Y27)
• Air pump vacuum valve (Y32)
• O2-Left oxygen sensor, upstream of catalytic converter. (G3/3)
• O2-Right oxygen sensor, upstream of catalytic converter. (G3/4)
Purge control valve (AKF) (Y58/1)
O2-Left oxygen sensor, downstream of catalytic converter. (G3/5)
O2-Right oxygen sensor, downstream of catalytic converter. (G3/6)
M113:
Cylinder switch-off valve 1Y80
Cylinder switch-off valve 1Y80		 15
20 Left electrically adjustable and heated outside mirror (M21/1), right electrically adjustable and heated outside mirror (M21/2) Mirror heater 15
21 With Sound system:
Sound amplifier (A2/13)
Radio (A2)		 25
22 Interior connector sleeve, circuit 15 (Z51/5)
• ETC [EGS] control module (N15/3)
• Transmission range recognition switch (S16/10)
• Blocking solenoid, backup/park pawl (Y66/1)
• Transfer case control unit (N78)
• Traction systems control unit (N47)
With ESP:
• Steering angle sensor (N49)
Instrument cluster (A1)
(F1k3) Fuel pump relay
Cruise control pushbutton switch (S40)
With M111:
HFM-SFI control unit (N3/4)
With M112/113:
Motor electronics control unit (N3/10)
23 Spare
24 Interior connector sleeve, circuit 58R (Z52/ 4):
• Trailer hitch connector (X52)
Right front lamp unit (E2):
• Right standing and parking lamp (E2e3)
Right taillamp (E4):
• Right taillamp and parking lamp (E4e2)
Right side-marker lamp (E2e6)		 7,5
25 Right front lamp unit (E2):
• Right turn signal lamp (E2e5)
Right taillamp (E4)
• Right turn signal lamp (E4e1)
Right auxiliary turn signal lamp (E22/2)
Traction system control unit (N47)
Interior connector sleeve, circuit R (Z53/5):
• Trailer hitch connector (X52)
Instrument cluster (A1):
• Right turn signal indicator lamp (A1e2)		 7,5
26 Connector sleeve, circuit 15 fused (Z3/29):
• Ignition coils M111 (T1)
• Ignition coils M112 (T1)
• Ignition coils M113 (T1)		 15
27 Traction systems control unit (N47) 40
28 Heated seats interior connector sleeve (Z53/8):
Supply of left/right heated seats:
• Heated seats relay, stage 1 (K59)
• Heated seats relay, stage 2 (K59/1)
• Left front seat heated cushion (R13/1)/ right front seat heated cushion (R13/3)
• Left front backrest heated cushion (R13/ 2) right front backrest heated cushion (R13/4)		 20
29 Center console switch group (S21):
• Right front window switch (S21s2)
• Right front power window motor (M10/4)
• Left rear window switch (S21s3)
Switch combination, power windows, rear center console (S21/15):
• Left rear window switch (S21/15s1)
• Power window motor: rear left (M10/5)
Relay 16:
Right front power window (F1k16)		 30
30 Center console switch group (S21):
• Left front window switch (S21s1)
• Right rear window switch (S21s4)
Switch combination, power windows, rear center console (S21/15):
• Right front window switch (S21/15s2)
Relay 18:
Left front power window (F1k18)		 30
31 Center console switch group (S21):
• Switch, electrical outside mirror adjustment (S50)
Cockpit connector sleeve, vent window (Z50/ 13):
Rear vent window:
• Left vent window switch (S21/13)
• Right vent window switch (S21/14)
Sliding/tilting roof switch (S13/2)		 15
32 Right front seat adjustment switch (S23)
Right front seat adjustment motor group (M26)
• Fore/aft motor (M26/m1)
• Rear up/down motor (M26/m2)
• Front up/down motor (M26/m3)
• Backrest fore/aft motor (M26/m5)		 30
33 Left front seat adjustment switch (S22)
Seat adjustment motor group:
left front (M25)		 30
34 Left front lamp unit (E1):
Left low beam (E1e2) (S1/1 Electric headlamp range adjustment selector)
Left headlamp range adjustment motors (E1m1), right headlamp range adjustment motors (E1m2)		 7,5
35 Right front lamp unit (E2):
Right low beam (E2e2)		 7,5
36 Rear window heater 25
37 Fanfare horns:
• Two-tone signaling system (H1)
• Two-tone signaling system, hom 2 (H1/1)		 20
38 Fuel pump with fuel gauge sensor (M3/3) 20
39 Spare
40 Vacuum pump (M 612.963) 25
41 Circulating pump relay (F1k19)
Right engine compartment connector sleeve, pump (Z57/2):
• Coolant circulation pump (M13)
• Module box blower motor (M2/2)
With diesel:
Healer booster Stationary heater		 25
42 Central locking:
• Left front door central locking motor (M14/6)
• Right front door central locking motor (M14/5)
Connector sleeve, interior central locking (Z53/1):
• Rear-end door central locking motor (M14/7)
• Left rear door CL [ZV] motor (M14/8)
• Right rear door CL [ZV] motor (M14/9)
• Fuel filler flap CL [ZV] motor (M14/10)		 20
43 Heater blower relay (F1 k21)
Blower motor (М2)		 30
44 Engine fan relay, stage 1 (Flk26)
Engine fan relay, stage 1 (F1k26)
Left engine compartment connector sleeve, fan (Z56/2)
• Left additional fan (M4m1)
• Right additional fan (M4m2)		 30
45 Electrical air pump (M33) 40
46 Cockpit connector sleeve, rear fog lamp (Z50/10):
• 2-way switch combination (S96/7) (rear fog lamp diode)
Left taillamp (E3), right taillamp (E4)
• Left rear fog lamp (E3e5), right rear fog lamp (E4e5)
Trailer hitch connector (X52)		 7.5
47 Left engine compartment connector sleeve, additional headlamp (Z56/4)
Left front lamp unit (E1):
• Left fog lamp (E1e4)
• Left additional headlamp high beam (E1e7), right additional headlamp high beam (E2e7)
Right front headlamp unit (E2)		 15
Relays
K1 Heated rear window relay
K2 FAN relay module (K39)
K3 Electric fuel pump relay (except engine 612.963)
K4 Left turn signal relay
K5 Circuit 58 relay, license plate illumination/ instrument cluster
K6 Electronic Stability Program (ESP) / stop lamp suppression relay
K7 Right turn signal relay
K8 Starter relay (solenoid switch, terminal 50)
K9 Circuit 58R relay (right standing lamp)
K10 Spare
K11 Circuit 15 relay delayed (engine 612.963 only)
K12 Circuit 15 relay
K13 Circuit 58L relay (left standing lamp)
K14 Convenience relay
K15 Central locking relay, unlocking tailgate
K16 Right front power window relay
K17 Front wiper relay, intermittent
K18 Left front power window relay
K19 Heater circulation pump relay and box fan fuse and relay box
K20 Central locking relay: Locking all doors
K21 Heater blower relay
K22 Low beam and contact piece relay
K23 Central locking relay: Unlocking front passenger’s door, rear doors and fuel tank flap
K24 Central locking relay: Unlocking driver’s door
K25 ETS / ESP hydraulic unit relay
K26 Engine fan relay, stage 1, with air conditionin
K27 Spare
K28 Secondary air injection pump relay
K29 Rear fog lamp relay

Fuse and relay box left rear of engine compartment (As-Of-09/01/01)

Mercedes-Benz M-Class w163 - fuse box diagram - engine compartment
Mercedes-Benz M-Class w163 – fuse box diagram – engine compartment
№
 Fused function A
1 Not assigned –
2 Instrument cluster (A1):
• Left turn signal indicator lamp (A1e1)
Left front lamp unit (E1):
• Left turn signal lamp (E1e5)
Left taillamp (E3):
• Left turn signal lamp (E3e1)
Left auxiliary turn signal lamp (E22/1)
Interior connector sleeve, circuit L (Z53/4)
• Trailer hitch connector (X52)		 7,5
3 Not assigned –
4 Supply of sliding/tilting roof (SHD) circuit 30:
• Sliding/tilting roof motor (SHD) (M12)		 20
5 Not assigned
6 Seat heater 20
7 Combination switch (S4):
• Hazard flasher switch (S6/1s1)
• Windshield washer system switch (S4s4)
• Wipe switch (S4s5) Wiper motor (M6/1)
Windshield washer fluid pump (M5/1)
Relay k17:
Front wiper interval relay		 30
8 Transfer case control unit (N78)/ E-Call control unit (A35/8) 25
9 Instrument cluster (A1)
License plate illumination:
• Left rear-end door license plate lamp (Е19/ 3), right rear-end door license plate lamp (E19/4),
• License plate lamp, left spare wheel carrier (E19/5), license plate lamp, right spare wheel carrier (E19/6)
Cockpit connector sleeve, circuit 58d (Z50/ 1):
• Left vent window switch (S21/13), right vent window switch (S21/14) (light emitting diodes)
• Left front SIH switch (S51/1), right front SIH switch (S51/2) (light emitting diodes)
• 2-way switch combination (S97/6) (light emitting diodes)
• ESP OFF switch (S76/6) (light emitting diodes)
• Outside mirror switch, folding in and out (S50/1) (light emitting diode)
• Electric headlamp range adjustment selector (S1/1) (light emitting diode)
• Rear window wipe/wash switch (S78) (light emitting diode)
• Tilting/sliding roof switch (S13/2) (light emitting diode)
• Backup lamp switch (S16/2)
• Illumination (R3e1)
• Center console switch aroup (S21)		 7,5
10 Radio (A2)
Roof connector sleeve, circuit 15R (Z54/1)
• Lett sun visor with illuminated mirror (Е14/ 1)
• Right sun visor with Illuminated mirror (E14/2)
• Automatic dimming inside rearview mirror (H7)
Front cigar lighter with ashtray illumination (R3)
• Heating element (R3r1)
Glove compartment lamp (E13/1)
Instrument cluster (A1):
• Airbag indicator and warning light (A1e15)		 10
11 Hot-film mass air flow sensor (B2/5)
Camshaft position sensor (L5)
Fuel injection valves (Y62)
In the case of M111:
• HFM control module (N3/4)		 15
12 Interior connector sleeve, circuit 58L (Z53/6)
• Trailer hitch connector (X52)
• Left taillamp (E3):
• Left taillamp and parking lamp (E3e2)
Left front lamp unit (E1):
• Left standing and parking lamp (E1e3)
• Left side-marker lamp (E1e6)		 7,5
13 Roof connector sleeve, circuit 30 (Z54/2)
• Front dome lamp (with shut-off delay and front reading lamp) (E15/2)
• Rear interior lamp (E15/3)
• Dome lamp in left rear (E15/8)
• Dome lamp in right rear (E15/9)
• Left front footwell lamps (E17/16)
• Right front footwell lamps (E17/15)
• Trip computer control unit (TRIP) (N41)
Instrument duster (A1):
Steering angle sensor (N49)
Datalink connector (X11/4)		 10
14 Engine control unit (diesel)
Injection timing device
Exhaust gas redrculation valve		 25
15 Interior connector sleeve, drcuit 54 (Z52/6)
Left left taillamp (E3)
• Left stop lamp (E3e4)
Right taillamp (E4):
• Right stop lamp (E4e4)
• Center high-mounted stop lamp (E21)
• Center high-mounted stop lamp, spare wheel carrier (E35)
• Stop lamp switch		 10
16 Diagnostic connector (X11/4)
Reversing lamp switch (S16/2)
Cockpit connector sleeve, circuit 15 (Z50/2)
• Air conditioning control unit (N19)
• Heater/AC switch (S98)
• Blower switch (S98s1)
• Thermostat (S98p1)
• Illumination (S98el)
• Illumination (S98e2)
• Recirculated air switch (S98s2)
• Air conditioning On switch (S98s3)
• Recirculated air flap actuator motor (M39)
Instrument cluster (A1)		 15
17 Cargo area connector box (X58/4) 20
18 Trailer hitch connector (X52) 25
19 M111:
HFM control module (N3/4)
Adjustable camshaft timing solenoid (Y49)
Activated charcoal filter shutoff valve (Y58)
M112/113:
Terminal 87 M2e connector sleeve (Z7/36)
• EGR switchover valve (Y27)
• Air pump vacuum valve (Y32)
• O2-Left oxygen sensor, upstream of catalytic converter. (G3/3)
• O2-Right oxygen sensor, upstream of catalytic converter. (G3/4)
Purge control valve (Y58/1)
O2-Left oxygen sensor, downstream of catalytic converter. (G3/5)
O2-Right oxygen sensor, downstream of catalytic converter. (G3/6)		 15
20 Not assigned –
21 Radio (A2)
Cellular telephone
Voice control system (VCS)		 15
22 Interior connector sleeve, circuit 15 (Z51/5)
• ETC [EGS] control module (N15/3)
• Transmission range recognition switch (S16/10)
• Blocking solenoid, backup/park pawl (Y66/1)
• Transfer case control unit (N78)
• Traction systems control unit (N47) With ESP:
• Steering angle sensor (N49)
Instrument cluster (A1)
Cruise control pushbutton switch (S40)
With M111:
HFM-SFI control unit (N3/4)
With M112/113:
Motor electronics control unit (N3/10)
Suction fan control unit (N65/2) on models 163.174/175
Rain sensor (B38)		 15
23 Headlamp range adjustment control module (N71) 15
24 Interior connector sleeve, circuit 58R (Z52/4)
• Trailer hitch connector (X52)
Right front headlamp unit (E2)
• Right standing and parking lamp (E2e3)
Right taillamp (E4)
• Right taillamp and parking lamp (E4e2)
Right slde-marker lamp (E2e6)		 7,5
25 Right front headlamp unit (E2)
• Right turn signal lamp (E2e5)
Right taillamp (E4)
• Right turn signal lamp (E4e1)
Right auxiliary turn signal lamp (E22/2)
Traction system control unit (N47)
Interior connector sleeve, circuit R (Z53/5):
• Trailer hitch connector (X52)
Instrument duster (A1)
• Right turn signal Indicator lamp (A1e2)		 7,5
26 Terminal 15 connector sleeve, fused (Z3/29)
• Ignition colls M111 (T1)
• Ignition colls M112 (T1)
• Ignition coils M113(T1)		 15
27 Traction systems control unit (N47) 40
28 Not assigned –
29 Not assigned
30 Not assigned
31 Center console switch group (S21)
Cockpit connector sleeve, vent window (Z50/ 13)
• Left vent window switch (S21/13)
• Right vent window switch (S21/14)
Tilting/sliding roof switch (S13/2)
Mirror lamps		 15
32 Not assigned –
33 Not assigned –
34 Not assigned –
35 Not assigned –
36 Mirror heater 10
37 Two-tone signaling system (H1) 20
38 Fuel pump with fuel level sensor (M3/3) only on model 163.128 15
39 Not assigned –
40 Sound system 25
41 Not assigned –
42 Central locking:
• Left front door central locking motor (M14/6)
• Right front door central locking motor (M14/5)
Interior central locking connector sleeve, motor 1 (Z53/1)
• Rear-end door central locking motor (M14/7)
• Left rear door CL [ZV] motor (M14/8)
• Right rear door CL [ZV] motor (M14/9)
• Fuel filler flap CL [ZV] motor (M14/10)		 20
43 Blower motor (М2), rear 20
44 Rear-end door washer fluid pump (M5/3) 15
44 Type 163.154/157
Engine fan relay, stage 1 (F1k26)
Engine fan relay, stage 1 (F1k26)
Left engine compartment connector sleeve, fan (Z56/2)
• Left additional fan (M4m1)
• Right additional fan (M4m2)		 40
45 Electric air pump (M33) 40
46 Cockpit connector sleeve, rear fog lamp (Z50/10)
• Left rear fog lamp (E3e5), right rear fog lamp (E4e5)
Trailer hitch connector (X52)		 7,5
47 Additional headlamp connector sleeve, right of engine compartment (Z56/4)
Left front headlamp unit (E1)
• Left fog lamp (E1e4)
• Left additional headlamp high beam (E1e7), right additional headlamp high beam (E2e7)
Right front headlamp unit (E2)
• Right fog lamp (E2e4)		 15
48 Alarm horn (H3) 20
Relays
K1 Relay for heated mirrors
K2 FAN relay module (K39)
K3 Electric fuel pump relay (except engine 612.963)
K4 Left turn signal relay
K5 Circuit 58 relay, license plate illumination/ instrument cluster
K6 Stop lamp relay
K7 Right turn signal relay
K8 Starter relay (solenoid switch, terminal 50)
K9 Circuit 58R relay (right standing lamp)
K10 Spare
K11 Relay circuit 15 delayed (engines 612.963 and 628.963 only)
K12 Circuit 15 relay
K13 Circuit 58L relay (left standing lamp)
K14 Convenience relay (windows/roof/mirrors)
K15 Central locking relay, unlocking tailgate
K16 Spare
K17 Front wiper relay, intermittent
K18 Spare
K19 Spare
K20 Central locking relay: Locking all doors
K21 Spare
K22 Spare
K23 Central locking relay: unlock front passenger door, rear doors
K24 Central locking relay: Unlock driver door and fuel filler flap
K25 Spare
K26 Engine fan relay, stage 1, with air conditionin
K27 Rear-end door washer pump relay
K28 Secondary air injection pump relay
K29 Rear fog lamp relay

Fuse and module box right front footwell

Mercedes-Benz M-Class w163 - fuse box diagram - right -front footwell
Mercedes-Benz M-Class w163 – fuse box diagram – right -front footwell
№
 Fused function
 A
1 AIRBAG OFF indicator lamp 7.5
2 Front cigar lighter (with ashtray illumination) Up to VIN A289564, X754619:

20

As of VIN A289565, X754620:

15
3 Tailgate wiper motor 15
4 Up to VIN A289564, X754619: E-Call control unit ((USA) only)
As of VIN A289565, X754620: front blower motor		 7.5
40
5 Instrument duster/air conditioning Up to VIN A289564, X754619:

7.5

As of VIN A289565, X754620:

15
6 Interior socket 20
7 Not assigned –
8 Left front seat heated cushion and right front seat heated cushion
Not assigned		 Up to VIN A289564, X754619:

20

As of VIN A289565, X754620
9 Not assigned –
10 Left front seat adjustment switch Up to VIN A289564, X754619:

30

As of VIN A289565, X754620:

35
11 Right front seat adjustment switch Up to VIN A289564, X754619:

30

As of VIN A289565, X754620:

35
13 Remove existing fuel pump with fuel level sensor (gasoline) 20
17 Heated rear window 25
19 HCS [SRA] pump 30
20 Right high beam As of VIN A289565, X754620:

7,5
21 Left high beam/ high beam indicator As of VIN A289565, X754620:

7,5
24 Rear power window motors and voltage supply for lower control panel control unit As Of VIN A289565, X754620:

25
25 Front power window motors and voltage supply for lower control panel control unit As Of VIN A289565, X754620:

25
Relays
K1 Seats convenience control relay
K2 Fuel pump relay (gasoline)
K4 Rear window defroster relay
K5 HCS [SRA] pump relay
K6 Auxiliary high beam relay (as of VIN A289565, X754620)
K8 Lower control panel/contact bridge switch (as of VIN A289565, X754620)
K9 Relay for voltage supply of term. 15





WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market
