MG MG3 (2013 – 2018) – fuse and relay box diagram

Posted on by admin

MG MG3 (2013 – 2018) – fuse and relay box diagram

Year of production: 2013, 2014, 2015, 2016, 2917, 2018



This article covers the second-generation MG MG3, following its first facelift, produced from 2013 to 2018. It includes fuse box diagrams for the 2013 to 2018 models, provides information on the locations of the fuse panels inside the vehicle, and details the function of each fuse (fuse layout).



Location

MG MG3 (2013 - 2018) - fuse and relay box location
MG MG3 (2013 – 2018) – fuse and relay box location



  1. Passenger Compartment Fuse Box （below the glove box at the front passenger side）.
  2. Engine Compartment Fuse Box （at the left side of the Engine Compartment

Passenger Compartment Fuse Box

Fuse Box Location

The fuses are located below the glove box at the front passenger side.



Fuse Box Diagram

MG MG3 (2013 - 2018) - fuse and relay box diagram - passenger compartment fuse box
MG MG3 (2013 – 2018) – fuse and relay box diagram – passenger compartment fuse box



Assignment of the fuses in the passenger compartment

No.
 А
 Function
F1 20 Rear Wiper Relay, Rear Washer Relay (LHD)
F2 15 Centre Console Power Socket
F3 5 Diagnostic Socket
F4 5 ABS, IPK, DC/DC, ECM, BCM, SAS, Yaw Rate Sensor
F5 10 Rear Washer Relay (RHD)
F6 5 Air Condition, Blower Relay, Centre Console Power Socket Relay, Heated Rear Window Relay, Headlamp Levelling Switch , Passenger Side Airbag Disabled Indicator
F7 15 Super Lock Relay
F8 10 SRS DCU
F9 10 Inertia Switch
F10 5 Left Position Lamp, Switch Illumination, Left Tail Lamp
F11 5 Front Interior/Map Lamp
FI2 5 Rear License Plate Lamp, Right Tail Lamp, Switch Illumination, Right Position Lamp
F13 20 Brake Pedal Switch, Reverse Lamp Switch
F14 15 CDL Motor (Lock), Tailgate Motor (Lock)
FI5 10 Reserve Fuse
FI6 15 CDL Motor (Unlock), Tailgate Motor (Unlock)
F17 10 Horn
FI8 10 BCM, Rear Washer Relay, Driver Door Combination Switch, IPK , In Car Entertainment
FI9 5 Left Brake Lamp, High Mounted Brake Lamp
F20 20 Left Rear Window Lift Switch
F2I 5 Right Brake Lamp
F22 20 Right Rear Window Lift Switch
F23 5 ECM, BCM
F24 25 Passenger Window Lift Switch
F2S 20 Rear Screen ideating
F26 25 Driver Door Combination Switch
F27 10 Exterior Rear View Mirror Heating
F28 15 In Car Entertainment
F29 – –
F30 10 Air Condition
F3I – –
F32 10 IPK
F33 – –
F34 5 DAB
F35 5 Reserve Fuse
F36 10 Reserve Fuse
F37 15 Reserve Fuse
F38 20 Reserve Fuse

Engine Compartment Fuse Box

Fuse Box Diagram

MG MG3 (2013 - 2018) - fuse and relay box diagram - engine compartment fuse box
MG MG3 (2013 – 2018) – fuse and relay box diagram – engine compartment fuse box



Assignment of the fuses in the engine compartment

No.
 А
 Function
F1 10 Right Front Low Beam Lamp
F2 5 Post-Oxygen Sensor, Inlet Cam Solenoid, Exhaust Cam Solenoid
F3 10 Left Front Low Beam Lamp
F4 10 Air Condition Compressor Clutch
F5 5 ECM
F6 5 Cooling Fan Relay, Purge Control Valve, Air Condition Compressor Clutch Relay, Fuel Pump Relay, Stop Start Switch
F7 30 Front Wiper Enable Relay, Front Wiper Speed Control Relay
F8 5 Pre-Oxygen Sensor
F9 15 Day Time Running Lamp, IPK Illumination
F10 10 Right Front High Beam Lamp, IPK Illumination
F11 10 Left Front High Beam Lamp
F12 30 Ignition Coils, Injectors, ECM
F13 30 –
FL1 20 Alternator, Passenger Compartment Fuse Box Fuse F4, FLI 1
FL2 50 SCS ECU (Pump)
FL3 40 Cooling Fan
FL4 60 Passenger Compartment Fuse Box Fuse F20, F22, F24, F26
FL5 80 Passenger Compartment Fuse Box Fuse FI, F3, F4, F5, F7, F9, F25, F27, Rear Screen Heating Relay
FL6 25 SCS ECU (Valve)
FL7 50 Ignition Switch
FL8 25 Common Unlock and Lock Relays
FL9 30 DC/DC Converter
FL10 25 Horn Relay, Washer Pump Relay
FL11 30 Blower Motor, Air Conditioning
FL12 25 Dipped Beam Relay
FL13 30 Starter Relay
FL14 25 BCM Indicators & Rear Fog Lamp
FL15 30 Position Lamp Relay, Day Time Running Lamp Relay, Engine Compartment Fuse Box Fuse F9, FIO, FI 1, Passenger Compartment Fuse Box Fuse FI0, FI2
FL16 – –

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

MG ZR (2001 – 2005) – fuse and relay box diagram

Posted on by admin

MG ZR (2001 – 2005) – fuse and relay box diagram

Year of production: 2001, 2002, 2003, 2004, 2005



The MG ZR hatchback was produced from 2001 to 2005. This article provides fuse box diagrams for the 2001 through 2005 models, details the locations of the fuse panels within the vehicle, and explains the function of each fuse (fuse layout).

Passenger Compartment Fuse Box

Fuse Box Location

MG ZR (2001 - 2005) - fuse and relay box location - passenger compartment fuse box
MG ZR (2001 – 2005) – fuse and relay box location – passenger compartment fuse box



Fuse Box Diagram

MG ZR (2001 - 2005) - fuse and relay box diagram - passenger compartment fuse box
MG ZR (2001 – 2005) – fuse and relay box diagram – passenger compartment fuse box



Assignment of the fuses in the passenger compartment

No
 A
 Description
1 15 Horn
2 20 Window – RH rear
3 10 Rear fog guard lights
4 20 Window – LH rear
5 10 Interior & luggage compartment lights, Seat belt buckle – RH, Audio unit. Door mirrors, Clock
6 20 Window – LH front
7 30 Sunroof
8 20 Window – RH front
9 20 Screen washers, Headlight washers
10 10 Headlight – RH main beam
11 10 Daylight running lights, Interior illumination (Scandinavia)
12 10 Headlight – LH main beam
13 10 Side & tail lights – LH, Headlight levelling – LH, Glovebox light. Clock, Interior lights
14 10 Headlight – RH dipped beam
15 10 Side & tail lights – RH, Headlight levelling – RH, Number plate light
16 10 Headlight – LH dipped beam
17 20 Blower motor
18 20 Seat heaters
19 10 Audio system
20 10 Engine starting
21 15 Windscreen wipers – front
22 10 Door mirrors
23 10 Anti-lock braking system
24 10 Brake lights. Reversing lights
25 10 Anti-theft alarm. Blower motor, Direction indicators, Clock, Instrument pack
26 15 Rear screen wiper. Headlight washers. Air conditioning illumination. Seat heaters
27 5 Airbag SRS

Engine compartment fuse box

Fuse Box Location

The fuse box is located on the left hand side of the engine compartment.



Fuse Box Diagram

MG ZR (2001 - 2005) - fuse and relay box diagram - engine compartment fuse box
MG ZR (2001 – 2005) – fuse and relay box diagram – engine compartment fuse box



Assignment of the fuses in the engine compartment

No
 A
 Description
1 10 Engine management system. Automatic transmission selector, Speedometer
2 20 Engine management system. Fuel pump
3 10 Engine management system. Glow plug relay
4 10 Air conditioning relay, Cooling fan relay
5 25 Anti-theft alarm. Central door locking
6 15 Front fog lights
7 15 Hazard warning lights
8 15 Engine management system
9 10 Air conditioning
10 20 Fuel cut-off switch

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Caddy (III; 2003 – 2004) – fuse and relay box diagram

Posted on by admin

 Volkswagen Caddy (III; 2003 – 2004) – fuse and relay box diagram

Year of production: 2003, 2004



In this article, we take a look at the third-generation Volkswagen Caddy (2K) before its first facelift, produced between 2003 and 2010. You will find fuse box diagrams for the 2003–2004 models, along with details on the location of the fuse panels inside the vehicle and the assignment of each fuse (fuse layout).

Location

Volkswagen Caddy (III; 2003 - 2004) - fuse box location
Volkswagen Caddy (III; 2003 – 2004) – fuse box location



  1. Fuses on fuse holder A -SA- (On the electronics box, on left in engine compartment)
  2. Fuses on fuse holder B -SB- (On left in engine compartment)
  3. Fuses on fuse holder C -SC- (Under left dash panel)

Engine Compartment

Fitting location of fuse holder A (A -SA-)

Fuse box diagram

Volkswagen Caddy (III; 2003 - 2004) - fuse box diagram - engine compartment (holderA)
Volkswagen Caddy (III; 2003 – 2004) – fuse box diagram – engine compartment (holderA)


Assignment of the fuses in the engine compartment (pre-fuse box)

No. A Function/component
1 150 Alternator -C- 90A / 110A
1 200 Alternator -C- 140A
2 80 Power steering control module -J500-
Electromechanical power steering motor -V187-
3 80 Radiator fan control unit -J293-
Radiator fan -V7-
Radiator fan on right of radiator -V35-
4 70 Onboard supply control unit -J519-
X-contact relief relay -J59-
Fuse 7 on fuse holder -SC7-
Fuse 8 on fuse holder -SC8-
Fuse 28 on fuse holder -SC28- to -SC35-
5 – Not used
6 100 Fuses on fuse holder C -SC-
Fuse 20 on fuse holder -SC20- to -SC24-
Fuse 42 on fuse holder -SC42- to -SC56-
7 50 Fuses on fuse holder C -SC-
Fuse 39 on fuse holder -SC39- to -SC41-

Fitting location of E-box high fuse holder (B -SB-)

Fuse box diagram

Volkswagen Caddy (III; 2003 - 2004) - fuse box diagram - engine compartment (holder B)
Volkswagen Caddy (III; 2003 – 2004) – fuse box diagram – engine compartment (holder B)



Assignment of the fuses in the engine compartment

No. A Function/component
1 30 ABS Control Module -J104-
2 30 ABS Control Module -J104-
3 – Not used
4 5 Onboard supply control unit -J519-
5 20 Onboard supply control unit -J519-
Double-tone horn relay -J4- , Signal horn relay -J413-
Treble horn -H2-
Bass horn -H7-
6 20 Ignition coil 1 with output stage -N70-
Ignition coil 2 with output stage -N127-
Ignition coil 3 with output stage -N291-
Ignition coil 4 with output stage -N292-
Ignition transformer -N152-
7 5 Brake pedal switch -F47-
J…-Engine Control Modules
Clutch position sender -G476-
8 10 Exhaust gas recirculation valve -N18-
Activated charcoal filter solenoid valve 1 -N80-
Variable intake manifold changeover valve -N156-
Protective resistor -N235-
Radiator fan control unit -J293-
Intake manifold flap motor -V157-
9 10 Fuel pump relay -J17- (BDJ, BJB)
Glow plug relay -J52- (BDJ)
Automatic glow period control module -J79- (BJB)
10 10 Exhaust gas recirculation valve -N18-
Charge pressure control solenoid valve -N75-
Exhaust gas recirculation fan switch-over valve -N345-
11 25 Motronic Control Module -J220- (BCA)
Simos Control Module -J361- (BGU, BSE, BSF)
11 30 Diesel direct injection system control module -J248- (BDJ, BJB)
12 15 Lambda probe -G39- (BCA)
Lambda probe after catalytic converter -G130- (BCA)
13 – Not used
14 – Not used
15 25 Starter -B-
16 15 Steering column electronics control module -J527-
17 10 Control unit in dash panel insert -J285-
18 – Not used
19 15 Control module with display for radio and navigation system -J503-
Radio -R-
20 10 Mobile telephone operating electronics control module -J412-
21 – Not used
22 – Not used
23 – Not used
24 10 Data bus diagnostic interface -J533-
25 – Not used
26 5 Terminal 30 voltage supply relay -J317- (BDJ, BJB )
26 10 Motronic control module -J220- (BCA)
27 10 Heater element for crankcase breather -N79-
28 – Not used
29 20 Cylinder 1 injector -N30- (BCA)
Cylinder 2 injector -N31- (BCA)
Cylinder 3 injector – N32- (BCA)
Cylinder 4 injector -N33- (BCA)
30 20 Auxiliary heater control unit -J364-
31 30 Windscreen wiper motor -V-
32 10 Cylinder 1 injector -N30- (BGU)
Cylinder 2 injector -N31- (BGU)
Cylinder 3 injector -N32- (BGU)
Cylinder 4 injector -N33- (BGU)
32 40 Glow plug 1 -Q10- (BDJ)
Glow plug 2 -Q11-
33 15 Fuel pump -G6- (BCA, BGU)
33 40 Glow plug 3 -Q12- (BDJ)
Glow plug 4 -Q13-
34 – Not used
34 – Not used
35 – Not used
36 – Not used
37 – Not used
38 10 Headlight range control regulator -E102-
Left headlamp levelling actuator -V48-
Right headlamp levelling actuator -V49-
39 5 Oil level and oil temperature sensor -G266-
Control unit in dash panel insert -J285-
40 20 Fuses on fuse holder C -SC-
Fuse 1 on fuse holder -SC1- to -SC6-
Fuse 9 on fuse holder -SC9- to -SC16-
Fuse 25 on fuse holder -SC25- to -SC27-
41 – Not used
42 5 Fuel pump relay -J17- (BCA, BGU)
42 10 Air mass meter -G70- (BJB)
43 – Not used
44 – Not used
45 15 Lambda probe -G39- (BGU)
Lambda probe after catalytic converter -G130- (BGU)
46 – Not used
47 40 Onboard supply control unit -J519- , left headlight
48 40 Onboard supply control unit -J519- , right headlight
49 – Not used
50 – Not used
51 40 Secondary air pump relay -J299- (BGU)
Secondary air pump motor -V101-
51 50 Automatic glow period control module -J179- (BJB)
Glow plug 1 -Q10-
Glow plug 2 -Q11-
Glow plug 3 -Q12-
Glow plug 4 -Q13-
52 – Not used
53 25 Driver door control unit -J386-
Front passenger door control unit -J387-
54 50 Radiator fan control unit -J293-
Radiator fan -V7-
Right fan for coolant -V35-
Radiator fan thermal switch -F18-
Radiator fan -V7-

Passenger Comparment

Position of fuses on fuse holder C -SC-

Fuse box diagram

Volkswagen Caddy (III; 2003 - 2004) - fuse box diagram - passenger compartment (holder C)
Volkswagen Caddy (III; 2003 – 2004) – fuse box diagram – passenger compartment (holder C)



Assignment of the fuses in the engine compartment

No. A Function/component
1 – Not used
2 5 Trailer detector control unit -J345-
3 5 Heater/heat output switch -E16-
High pressure sender -G65-
4 – Not used
5 – Not used
6 – Not used
7 5 Heated driver seat regulator -E94-
Heated front passenger seat regulator -E95-
8 5 Left washer jet heater element -Z20-
Right washer jet heater element -Z21-
9 5 Airbag control unit -J234-
Front passenger side airbag deactivated warning lamp -K145-
10 5 Mobile telephone operating electronics control unit -J412-
11 10 Power steering control unit -J500-
12 – Not used
13 – Not used
14 5 Traction control system switch -E132-
TCS and ESP button -E256-
ABS control unit -J104-
15 10 Reversing light switch -F4-
Auxiliary heater operation relay -J485- (from May 2004)
Control unit with display for radio and navigation system -J503- (commercial equipment)
T16 – Self-diagnosis connection (T16/1)
16 5 Data bus diagnostic interface -J533-
17 7.5 Left tail light and rear fog light bulb -M41- (models without central locking)
18 – Not used
19 – Not used
20 – Not used
21 – Not used
22 5 Remote control receiver for auxiliary coolant heater -R149-
23 10 Brake light switch -F-
Left brake light bulb -M9-
Right brake light bulb -M10-
High level brake light bulb -M25-
ABS control unit -J104-
24 10 Light switch -E1-
Air conditioning system control unit -J301-
16-pin connector -T16- (self-diagnosis connection T16/16)
25 30 Heated driver seat control unit -J131-
Heated front passenger seat control unit -J132-
26 10 J… – Engine control units
27 15 Rear window wiper motor -V12- (from May 2004)
28 5
20		 Light switch -E1- (models with central locking)
Fog light switch -E7- (models without central locking)
Rear fog light switch -E18- (models without central locking)
29 15 Rear window wiper motor -V12- (up to April 2004)
30 25 Light switch -E1- (models without central locking)
Fuse 37 on fuse holder C -SC37-
Fuse 38 on fuse holder C -SC38-
31 15 Auxiliary heater operation relay -J485- (up to April 2004)
32 15 Washer pump -V5-
33 – Not used
34 – Not used
35 40 Fresh air blower -V2-
Auxiliary heater operation relay -J485-
36 – Not used
37 15 Right dipped beam bulb -M31- (models without central locking)
38 15 Left dipped beam bulb -M29- (models without central locking only)
39 – Not used
40 20 Trailer detector control unit -J345-
41 20 Trailer socket -U10-
42 15
30		 12 V socket -U5- (near handbrake lever)
12 V socket 2 -U18- (left luggage compartment)
43 15 Electric fuel pump 2 relay -J49- (BCA, BGU)
Fuel pump relay -J17- (BDJ, BJB)
Fuel system pressurisation pump -G6-
44 5 Interior monitoring sensor -G273-
Vehicle inclination sender -G384-
Alarm horn -H12-
45 5 Aerial selection control unit -J515-
46 7.5 Onboard supply control unit -J519- (Interior light)
47 25
30		 Cigarette lighter -U1-
Rear cigarette lighter -U9-
48 20 Headlight washer system relay -J39-
Headlight washer system pump -V11-
49 10 Driver door control unit -J386-
Front passenger door control unit -J387-
50 – Not used
51 – Not used
52 25 Fresh air blower relay -J13-
Onboard supply control unit -J519-
53 25 Convenience system central control unit -J393-
54 – Not used
55 – Not used
56 – Not used
57 – Not used
58 – Not used

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Caddy (III; 2005 – 2007) – fuse and relay box diagram

Posted on by admin

Volkswagen Caddy (III, 2005 – 2007) – fuse and relay box diagram

Year of production: 2005, 2006, 2007



In this article, we take a look at the third-generation

 Volkswagen Caddy (2K) before its first facelift, produced between 2003 and 2010. You will find fuse box diagrams for the 2005–2008 models, along with details on the location of the fuse panels inside the vehicle and the assignment of each fuse (fuse layout).

Location

Volkswagen Caddy (III; 2005 – 2007) – fuse box location
Volkswagen Caddy (III; 2005 – 2007) – fuse box location



  1. Fuses on fuse holder A -SA- (On the electronics box, on left in engine compartment)
  2. Fuses on fuse holder B -SB- (On left in engine compartment)
  3. Fuses on fuse holder C -SC- (Under left dash panel)



Engine Compartment

Fitting location of fuse holder A (A -SA-)

Fuse box diagram

Volkswagen Caddy (III; 2005 - 2007) - fuse box diagram - passenger comartment (fitting location of fuse holder A (A -SA-))
Volkswagen Caddy (III; 2005 – 2007) – fuse box diagram – passenger comartment (fitting location of fuse holder A (A -SA-))



Assignment of the fuses in the engine compartment (pre-fuse box)

No. A Function/component
1 150 Alternator -C- 90A / 110A
1 200 Alternator -C- 140A
2 80 Power steering control module -J500-
Electromechanical power steering motor -V187-
3 50 Radiator fan control unit -J293-
Radiator fan -V7-
Right fan for coolant -V35-
Radiator fan thermal switch -F18-
Radiator fan -V7-
3 80 Radiator fan control unit -J293-1)
4 502)
803)		 Onboard supply control unit -J519-2)
X-contact relief relay -J59-2)
Fuse 7 on fuse holder -SC7-
Fuse 8 on fuse holder -SC8-
Fuse 28 on fuse holder -SC28- to -SC33-
5 100 Not used (from May 2005 to November 2006)
Fuses on fuse holder C -SC- (from November 2006)
Fuse 20 on fuse holder -SC20- to -SC24-
Fuse 42 on fuse holder -SC42- to -SC52- (up to April 2009)
Fuse 42 on fuse holder -SC42- to -SC53- (from May 2009)
6 100 Fuses on fuse holder C -SC- (from May 2005 to November 2006)
Fuse 20 on fuse holder -SC20- to -SC24-
Fuse 42 on fuse holder -SC42- to -SC52-
Not used (from November 2006)
High heat output relay -J360- (from September 2007)
Auxiliary air heater element -Z35-
66) 50 Low heat output relay -J359-4)
Auxiliary air heater element -Z35-
7 50 Fuses on fuse holder C -SC-
Fuse 39 on fuse holder -SC39- to -SC41-5)
76) 100 High heat output relay -J360-5)
Auxiliary air heater element -Z35-
1) Only models with increased fan output
2) Only models with central locking
3) Only models without central locking
4) Only models with trailer coupling
5) Only models with auxiliary air heater (PTC)
6) from May 2008

Fitting location of E-box high fuse holder (B -SB-)

Fuse box diagram

Volkswagen Caddy (III; 2005 - 2007) - fuse box diagram - engine compartment (holder B -SB-)
Volkswagen Caddy (III; 2005 – 2007) – fuse box diagram – engine compartment (holder B -SB-)



Assignment of the fuses in the engine compartment (holder B)

No. A Function/component
1 – Not used
2 15
51)		 Steering column electronics control module -J527-
Not used (from May 2008)
3 5 Onboard supply control unit -J519-
4 30 ABS Control Module -J104-
5 15 Mechatronics unit for dual clutch gearbox -J743-
6 5 Control unit in dash panel insert -J285-
Steering column electronics control module -J527- (from May 2008)
7 40 Not used (up May 2008)
Terminal 15 voltage supply relay 2 -J681- (from May 2008)
8 15 Control module with display for radio and navigation system -J503-
Radio -R-
9 10
51)		 Mobile telephone operating electronics control module -J412-
10 10 Motronic current supply relay -J271- (BUD, BSX)
Term. 30 voltage supply relay -J317- (BDJ, BST, BLS, BSU, BJB, BCA, BMM)
Motronic control module -J220- (BCA)
Engine control module -J623- (BSX, BUD)
11 20 Auxiliary heater control unit -J364-
12 5 Data bus diagnostic interface -J533-
13 25
151)		 Engine control module -J623- (BSX, BUD)
Simos control module -J361- (BGU, BSE, BSF)
13 30 Diesel direct injection system control module -J248- (BDJ, BLS, BJB, BST, BSU, BMM)
Motronic control module -J220- (BCA)
14 20 Ignition coil 1 with output stage -N70- (BCA, BSX, BUD)
Ignition coil 2 with output stage -N127- (BCA, BSX, BUD)
Ignition coil 3 with output stage -N291- (BCA, BSX, BUD)
Ignition coil 4 with output stage -N292- (BCA, BSX, BUD)
Ignition transformer -N152- (BGU, BSE, BSF, BSX)
15 5 Fuel pump relay -J17- (BDJ, BST, BLS, BSU, BJB, BMM)
Glow plug relay -J52- (BDJ, BST)
Automatic glow period control module -J179- (BLS, BSU, BJB, BMM)
15 10 Fuel pump switch-off relay -J333- (BSX)
Cylinder 1 injector -N30- (BUD)
Cylinder 2 injector -N31- (BUD)
Cylinder 3 injector -N32- (BUD)
Cylinder 4 injector -N33- (BUD)
Gas injector 1 -N366- (BSX)
Gas injector 2 -N367- (BSX)
Gas injector 3 -N368- (BSX)
Gas injector 4 -N369- (BSX)
16 30 ABS Control Module -J104-
17 20 Onboard supply control unit -J519-
Signal horn relay -J413-
Treble horn -H2-
Bass horn -H7-
18 30 Special vehicle control unit -J608-
19 30 Windscreen wiper motor -V-
20 40 Glow plug 3 -Q12- (BDJ, BST)
Glow plug 4 -Q13- (BDJ, BST)
21 10 Lambda probe heater -Z19- (BLS, BMM)
21 15 Lambda probe heater -Z19- (BGU, BSE, BSF, BCA, BSX, BUD)
Lambda probe 1 heater after catalytic converter -Z29- (BGU, BSE, BSF, BCA, BSX, BUD)
22 5 Brake pedal switch -F47- (up to May 2006)
Clutch position sender -G476-
23 5 Secondary air pump relay -J299- (BGU, BSE)
Exhaust gas recirculation valve -N18- (BDJ, BST)
23 10 Exhaust gas recirculation valve -N18- (BJB, BSU)
Charge pressure control solenoid valve -N75- (BJB, BLS, BSU, BMM)
Exhaust gas recirculation cooler changeover valve -N345- (BJB, BLS, BSU, BMM)
Tank shut-off valve 1 -N361- (BSX)
Tank shut-off valve 2 -N362- (BSX)
Tank shut-off valve 3 -N363- (BSX)
High-pressure valve for gas operation -N372- (BSX)
Tank shut-off valve 4 -N429- (BSX)
24 10 Exhaust gas recirculation valve -N18- (BCA)
Cylinder 1 injector -N30- (BSX)
Cylinder 2 injector -N31- (BSX)
Cylinder 3 injector -N32- (BSX)
Cylinder 4 injector -N33- (BSX)
Activated charcoal filter solenoid valve 1 -N80- (BCA, BGU, BSE, BSF, BUD)
Variable intake manifold changeover valve -N156- (BGU, BSE, BSF)
Intake manifold flap motor -V157- (BDJ, BST)
Radiator fan control unit -J293-
Protective resistor -N235-
25 40 Onboard supply control unit -J519- , right headlight
26 40 Onboard supply control unit -J519- , left headlight
27 40 Secondary air pump relay -J299- (BGU, BSE)
Secondary air pump motor -V101-
Glow plug 1 -Q10- (BDJ, BST)
Glow plug 2 -Q11- (BDJ, BST)
27 50 Automatic glow period control module -J179- (BJB, BLS, BSU, BMM)
Glow plug 1 -Q10-
Glow plug 2 -Q11-
Glow plug 3 -Q12-
Glow plug 4 -Q13-
28 40 Terminal 15 voltage supply relay 2 -J681-
29 30 Driver door control unit -J386- (only models with electric window regulators)
Front passenger door control unit -J387- (only models with electric window regulators)
30 30 Fuses on fuse holder C -SC- (special-purpose vehicles)
Fuse 18 on fuse holder -SC18-
Fuse 19 on fuse holder -SC19-
Fuse 36 on fuse holder -SC36-
Fuse 53 on fuse holder -SC53- to -SC56-
30 50 Low heat output relay -J358- (from September 2007)
Auxiliary air heater element -Z35-
1) from May 2007

Passenger Comparment

Position of fuses on fuse holder C -SC-

Fuse box diagram

Volkswagen Caddy (III; 2005 - 2007) - fuse box diagram - passenger compartment (holder C -SC-)
Volkswagen Caddy (III; 2005 – 2007) – fuse box diagram – passenger compartment (holder C -SC-)



Assignment of the fuses in the passenger compartment (holder C)

No. A Function/component
1 –
10		 Not used (applicable up to May 2006)
10-pin connector -T10c- (from November 2006; for models with electric interface only)
1 10
151)		 2-way radio switch -E72- (applies to special vehicles only)
Engine continues to run without key button -E489- (applies to special vehicles only)
Special vehicle control unit -J608- (up November 2006; applies to special vehicles only)
4-pin connector -T4g- (applies to special vehicles only)
2 5 Fuel pump relay -J17- (BCA, BGU, BSE, BSF, BUD, BSX)
Terminal 15 voltage supply relay -J329- (BGU, BSE, BSF, BUD, BSX)
Data bus diagnostic interface -J533-
Engine control unit -J623-
3 5 Headlight range control regulator -E102-
Left headlight range control motor -V48-
Right headlight range control motor -V49-
Traction control system switch -E132- (from November 2006)
TCS and ESP button -E256- (from November 2006)
Selector lever -E313- (from November 2006; only models with direct shift gearbox)
Brake light switch -F- (from November 2006)
ABS control unit -J104- (from November 2006)
Trailer detector control unit -J345- (from November 2006)
Power steering control unit -J500- (from November 2006; only models with power steering)
Selector lever sensors control unit -J587- (from November 2006; only models with direct shift gearbox)
Mechatronic unit for dual clutch gearbox -J743- (from November 2006; only models with direct shift gearbox)
4 5 Mobile telephone operating electronics control unit -J412- (only models with telephone)
5 15 Air mass meter -G70- (BLS, BSU, BJB, BDJ, BST)
Heater element for crankcase breather -N79- (BCA, BGU, BSE, BSF, BUD, BLS, BSU, BJB)
Reversing light switch -F4- (from November 2006)
Auxiliary heater operation relay -J485- (from November 2006; only models with auxiliary coolant heater)
16-pin connector -T16- (from November 2006; self-diagnosis connection)
5 10 Heater element for crankcase breather -N79- (BSX)
Activated charcoal filter system solenoid valve 1 -N80- (BSX)
16-pin connector -T16- (from November 2006; self-diagnosis connection)
Reversing light switch -F4- (from November 2006)
Auxiliary heater operation relay -J485- (from November 2006; only models with auxiliary coolant heater)
6 5 Airbag control unit -J234-
Front passenger side airbag deactivated warning lamp -K145-
7 5 Heater/heat output switch -E16- (only models with seat heating and without central locking)
Air conditioning system control unit -J301- (only models with seat heating and without central locking)
Not used (from November 2006)
8 5 Left washer jet heater element -Z20- (only models without central locking)
Right washer jet heater element -Z21- (only models without central locking)
Not used (from November 2006)
9 10 Power steering control unit -J500- (only models with power steering)
Not used (from November 2006)
10 10 Reversing light switch -F4-
Auxiliary heater operation relay -J485- (only models with auxiliary coolant heater)
16-pin connector -T16- (self-diagnosis connection)
Not used (from November 2006)
11 – Not used (applicable up to May 2006)
11 10 2-pin connector -T2ab- (applies to special vehicles only, applicable from June 2006)
12 – Not used (applicable up to May 2006)
12 5 Interior light switch (taxi) -E115- (only taxi)
Taxi sign switch -E138- (only taxi)
Hands-free system button -E487- (only taxi)
Taxi meter -G41- (only taxi)
12 10 2-pin connector -T2ac- (applies to special vehicles only)
28-pin connector -T28a- (applies to special vehicles only)
13 5 Trailer detector control unit -J345- (only models with trailer operation and without central locking)
Not used (from November 2006)
14 5 Traction control system switch -E132-
TCS and ESP button -E256-
ABS control unit -J104-
Brake light switch -F- (applicable from June 2006)
Not used (from November 2006)
15 5 Selector lever -E313- (only models with direct shift gearbox)
Selector lever sensors control unit -J587- (only models with direct shift gearbox)
Mechatronic unit for dual clutch gearbox -J743- (only models with direct shift gearbox)
Not used (from November 2006)
16 5 Heater/heat output switch -E16- (only models without air conditioning system)
High pressure sender -G65- (only models with air conditioning system)
Oil level and oil temperature sender -G266- (only for models with flexible service interval display)
Control unit in dash panel insert -J285-
17 7.5 Left tail light and rear fog light bulb -M41- (models without central locking)
Rear fog light cut-out contact switch -F216- (only models with trailer operation and without central locking)
18 5 Not used (applicable up to May 2006)
Taxi alarm remote control, control unit -J601- (only taxi, applicable from June 2006)
10-pin connector -T10c- (for models with electric interface only) (from November 2006)
19 5 Not used (applicable up to May 2006)
10-pin connector -T10c- (for models without electric interface only, applicable from June 2006)
19 10 Taxi meter -G41- (only taxi, applicable from June 2006)
Two-way radio -R8- (only taxi, applicable from June 2006)
20 5 Automatic gearbox control unit -J217-
20 10 10-pin connector -T10c- (from November 2006; for models with electric interface only)
21 5
101)		 Selector lever -E313- (only models with direct shift gearbox)
Selector lever sensors control unit -J587- (only models with direct shift gearbox)
Tiptronic switch -F189- (from November 2006; only models with direct shift gearbox)
Automatic gearbox control unit -J217- (from November 2006)
16-pin connector -T16- (from November 2006; self-diagnosis connection)
Light switch -E1- (from November 2006)
Heater/heat output switch -E16- (from November 2006)
Air conditioning system control unit -J301- (from November 2006)
Remote control receiver for auxiliary coolant heater -R149- (from November 2006; only models with remote control receiver for auxiliary coolant heater)
22 5 Remote control receiver for auxiliary coolant heater -R149- (only models with remote control receiver for auxiliary coolant heater)
Not used (from November 2006)
23 10 Brake light switch -F- (applicable up to May 2006)
23 10 3-pin connector -T3r- (applies to special vehicles only, applicable from June 2006)
24 10
51)		 Light switch -E1- (up November 2006)
Heater/heat output switch -E16- (up November 2006)
Air conditioning system control unit -J301- (up November 2006)
16-pin connector -T16- (up November 2006; self-diagnosis connection)
Interior monitoring sensor -G273- (from November 2006)
Vehicle inclination sender -G384- (from November 2006)
Alarm horn -H12- (from November 2006)
25 – Not used
26 20 Injector, cylinder 1 -N30- (BCA, BGU, BSE, BSF, BUD)
Injector, cylinder 2 -N31- (BCA, BGU, BSE, BSF, BUD)
Injector, cylinder 3 -N32- (BCA, BGU, BSE, BSF, BUD)
Injector, cylinder 4 -N33- (BCA, BGU, BSE, BSF, BUD)
27 20 Not used (up November 2006)
Automatic gearbox control unit -J217- , under front left wheel housing liner (from November 2006)
28 5 Light switch -E1- (models with central locking)
28 20 Rear fog light switch -E18- (from November 2006; only models without central locking)
29 15 Rear window wiper motor -V12- (models with rear window wiper only)
30 5 Heater/heat output switch -E16- (only models with seat heating and central locking)
Air conditioning system control unit -J301- (only models with seat heating and central locking)
30 25 Light switch -E1- (only models without central locking)
31 15 Onboard supply control unit -J519-
32 5 Left washer jet heater element -Z20- (only models with central locking)
Right washer jet heater element -Z21- (only models with central locking)
33 40 Heater/heat output switch -E16-
Air conditioning system control unit -J301-
Auxiliary heater operation relay -J485- (only models without auxiliary coolant heater)
34 – Not used
35 – Not used
36 – Not used (applicable up to May 2006)
36 20 10-pin connector -T10ai- (applies to special vehicles only, applicable from June 2006)
37 15 Right dipped beam bulb -M31- (models without central locking)
38 15 Left dipped beam bulb -M29- (models without central locking only)
38 10 Fluorescent light in rear of high roof -W41- (applies to special vehicles only, applicable from June 2006)
Fluorescent light in centre of high roof -W42- (applies to special vehicles only, applicable from June 2006)
39 – Not used
40 20 Trailer detector control unit -J345-
41 20 Trailer socket -U10-
42 15 12 V socket -U5- (without 12 V socket, in luggage compartment)
42 30 12 V socket -U5- (near handbrake lever)
12 V socket 2 -U18- (left luggage compartment)
43 15 Electric fuel pump 2 relay -J49- (BCA, BGU, BSE, BSF, BUD, BSX)
Fuel pump relay -J17- (BDJ, BJB, BLS, BSU, BJB, BSE, BSF, BUD, BSX)
44 5 Interior monitoring sensor -G273-
Vehicle inclination sender -G384-
Alarm horn -H12-
Not used (from November 2006)
45 5 Aerial selection control unit -J515- (applicable up to May 2006)
45 20 Headlight washer system relay -J39- (from November 2006; only models with headlight washer system)
Headlight washer system pump -V11- (from November 2006; only models with headlight washer system)
45 30 10-pin connector -T10ai- (applies to special vehicles only, applicable from June 2006)
46 7.5 Onboard supply control unit -J519- (Interior light)
47 25 Cigarette lighter -U1-
48 20 Headlight washer system relay -J39- (up November 2006)
Headlight washer system pump -V11- (up November 2006)
48 30 Heated front seats control unit -J774- (from November 2006; only models with lateral support heater)
49 10 Driver door control unit -J386- (only models with central locking)
Front passenger door control unit -J387- (only models with central locking)
50 25 Convenience system central control unit -J393-
51 30 Heated driver seat control unit -J131- (up November 2006)
Heated front passenger seat control unit -J132- (up November 2006)
Heated front seats control unit -J774-
52 25 Fresh air blower relay -J13- (only models with auxiliary heater)
Onboard supply control unit -J519-
Heated rear window -Z1-
53 – Not used
54 – Not used
55 – Not used
56 – Not used
57 5 Not used (applicable up to May 2006)
Accident data memory -J754- (applies to special vehicles only, applicable from June 2006)
10-pin connector -T10c- (from November 2006; for models with electric interface only)
58 10 Not used (applicable up to May 2006)
4-pin connector -T4g- (applies to special vehicles only, applicable from June 2006)
1) from November 2006

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Caddy (III; 2008 – 2010) – fuse and relay box diagram

Posted on by admin

Volkswagen Caddy (III; 2008 – 2010) – fuse and relay box diagram

Year of production: 2008, 2009, 2010



In this article, we take a look at the third-generation Volkswagen Caddy (2K) before its first facelift, produced between 2003 and 2010. You will find fuse box diagrams for the 2008 – 2010 models, along with details on the location of the fuse panels inside the vehicle and the assignment of each fuse (fuse layout).

Location

Volkswagen Caddy (III; 2008 – 2010) – fuse box location
Volkswagen Caddy (III; 2008 – 2010) – fuse box location
  1. Fuses on fuse holder A -SA- (On the electronics box, on left in engine compartment)
  2. Fuses on fuse holder B -SB- (On left in engine compartment)
  3. Fuses on fuse holder C -SC- (Under left dash panel)

Engine Compartment

Fitting location of fuse holder A (A -SA-)

Fuse box diagram

Volkswagen Caddy (III; 2008 - 2010) - fuse box diagram - fitting location of fuse holder A (A -SA-)
Volkswagen Caddy (III; 2008 – 2010) – fuse box diagram – fitting location of fuse holder A (A -SA-)



Assignment of the fuses in the engine compartment (pre-fuse box)

No. A Function/component
1 150 Alternator -C- 90A / 110A
1 200 Alternator -C- 140A
2 80 Power steering control module -J500-
Electromechanical power steering motor -V187-
3 50 Radiator fan control unit -J293-
Radiator fan -V7-
Right fan for coolant -V35-
Radiator fan thermal switch -F18-
Radiator fan -V7-
4 502)
803)		 Onboard supply control unit -J519-2)
X-contact relief relay -J59-2)
Fuse 7 on fuse holder -SC7-
Fuse 8 on fuse holder -SC8-
Fuse 28 on fuse holder -SC28- to -SC33-
5 100 Fuses on fuse holder C -SC-
Fuse 20 on fuse holder -SC20- to -SC24-
Fuse 42 on fuse holder -SC42- to -SC52-
6 40 Low heat output relay -J359-4)
Auxiliary air heater element -Z35-
7 80 High heat output relay -J360-4)
Auxiliary air heater element -Z35-
1) Only models with continuously variable radiator fan
2) Only models with central locking
3) Only models without central locking
4) Only models with auxiliary air heater (PTC)

Fitting location of E-box high fuse holder (B -SB-)

Fuse box diagram

Volkswagen Caddy (III; 2008 - 2010) - fuse box diagram - engine compartment (holder B -SB-)
Volkswagen Caddy (III; 2008 – 2010) – fuse box diagram – engine compartment (holder B -SB-)



Assignment of the fuses in the engine compartment (holder B)

No. A Function/component
1 – Not used
2 – Not used
3 5 Onboard supply control unit -J519-
4 30 ABS Control Module -J104-
5 15 Mechatronics unit for dual clutch gearbox -J743-
6 – Not used
7 40 Terminal 15 voltage supply relay 2 -J681-
8 15 Control module with display for radio and navigation system -J503-
Radio -R-
9 5 Mobile telephone operating electronics control module -J412-
Not used (from May 2009)
10 10 Motronic current supply relay -J271- (BUD, BSX)
Term. 30 voltage supply relay -J317- (BDJ, BST, BLS, BMM, BSU, BJB)
Engine control module -J623- (BSX, BUD)
11 20 Auxiliary heater control unit -J364-
12 5 Data bus diagnostic interface -J533-
Not used (from May 2009)
13 15 Engine control module -J623- (BSX, BUD)
Simos control module -J361- (BSE, BSF)
13 30 Diesel direct injection system control module -J248- (BDJ, BJB, BLS, BMM, BST, BSU)
14 20 Ignition coil 1 with output stage -N70- (BSX, BUD)
Ignition coil 2 with output stage -N127- (BSX, BUD)
Ignition coil 3 with output stage -N291- (BSX, BUD)
Ignition coil 4 with output stage -N292- (BSX, BUD)
Ignition transformer -N152- (BSE, BSF, BSX)
15 5 Fuel pump relay -J17- (BDJ, BJB, BLS, BMM, BST, BSU)
Glow plug relay -J52- (BDJ, BST)
Automatic glow period control module -J179- (BJB, BLS, BMM, BSU)
15 10 Fuel pump switch-off relay -J333- (BSX)
Cylinder 1 injector -N30- (BUD)
Cylinder 2 injector -N31- (BUD)
Cylinder 3 injector -N32- (BUD)
Cylinder 4 injector -N33- (BUD)
Gas injector 1 -N366- (BSX)
Gas injector 2 -N367- (BSX)
Gas injector 3 -N368- (BSX)
Gas injector 4 -N369- (BSX)
16 30 Onboard supply control unit -J519- , right headlight
17 – Not used
18 30 Special vehicle control unit -J608-
19 30 Windscreen wiper motor -V-
20 40 Glow plug 3 -Q12- (BDJ, BST)
Glow plug 4 -Q13- (BDJ, BST)
20 10 Tank shut-off valve 1 -N361- (BSX) (from May 2009)
Tank shut-off valve 2 -N362- (BSX) (from May 2009)
Tank shut-off valve 3 -N363- (BSX) (from May 2009)
Tank shut-off valve 4 -N429- (BSX) (from May 2009)
Tank shut-off valve 5 -N430- (BSX) (from May 2009)
21 10 Lambda probe heater -Z19- (BLS, BMM)
21 15 Lambda probe heater -Z19- (BSE, BSF, BSX, BUD)
Lambda probe 1 heater after catalytic converter -Z29- (BSE, BSF, BSX, BUD)
22 5 Clutch position sender -G476-
23 5 Secondary air pump relay -J299- (BSE)
Exhaust gas recirculation valve -N18- (BDJ, BST)
23 10 Exhaust gas recirculation valve -N18- (BJB, BSU)
Charge pressure control solenoid valve -N75- (BJB, BLS, BMM, BSU)
Exhaust gas recirculation cooler changeover valve -N345- (BJB, BLS, BMM, BSU)
Tank shut-off valve 1 -N361- (BSX) (up May 2009)
Tank shut-off valve 2 -N362- (BSX) (up May 2009)
Tank shut-off valve 3 -N363- (BSX) (up May 2009)
High-pressure valve for gas operation -N372- (BSX)
Tank shut-off valve 4 -N429- (BSX) (up May 2009)
24 10 Cylinder 1 injector -N30- (BSX)
Cylinder 2 injector -N31- (BSX)
Cylinder 3 injector -N32- (BSX)
Cylinder 4 injector -N33- (BSX)
Activated charcoal filter solenoid valve 1 -N80- (BSE, BSF, BUD)
Variable intake manifold changeover valve -N156- (BSE, BSF)
Intake manifold flap motor -V157- (BDJ, BST)
Radiator fan control unit -J293-
Protective resistor -N235-
25 40 ABS Control Module -J104-
26 40 Onboard supply control unit -J519- , left headlight
27 40 Secondary air pump relay -J299- ( BSE)
Secondary air pump motor -V101-
Glow plug 1 -Q10- (BDJ, BST)
Glow plug 2 -Q11- (BDJ, BST)
27 50 Automatic glow period control module -J179- (BJB, BLS, BMM, BSU)
Glow plug 1 -Q10-
Glow plug 2 -Q11-
Glow plug 3 -Q12-
Glow plug 4 -Q13-
28 – Not used
29 30 Fuses on fuse holder C -SC- (special-purpose vehicles)
Fuse 18 on fuse holder -SC18-
Fuse 19 on fuse holder -SC19-
Fuse 35 on fuse holder -SC35- to -SC39-
Fuse 57 on fuse holder -SC57-
Fuse 58 on fuse holder -SC58-
30 50 Fuses on fuse holder C -SC- (only with trailer coupling) (up May 2009)
Fuse 39 on fuse holder -SC39- to -SC41-
Fuses on fuse holder C -SC- (only with trailer coupling) (from May 2009)
Fuse 40 on fuse holder -SC40- to -SC42-

Passenger Comparment

Position of fuses on fuse holder C -SC-

Fuse box diagram

Volkswagen Caddy (III; 2008 - 2010) - fuse box diagram - passenger compartment (holder C -SC-)
Volkswagen Caddy (III; 2008 – 2010) – fuse box diagram – passenger compartment (holder C -SC-)



Assignment of the fuses in the passenger compartment (holder C)

No. A Function/component
1 – Not used
2 – Not used
3 – Not used
4 – Not used
5 – Not used
6 – Not used
7 – Not used
8 – Not used
9 10 4-pin connector -T4g- (applies to special vehicles only)
10-pin connector -T10c- (for models with electric interface only)
10 5 Fuel pump relay -J17- (BSE, BSF, BUD, BSX)
Terminal 15 voltage supply relay -J329- (BSE, BSF)
Data bus diagnostic interface -J533-
Engine control unit -J623-
11 5 Parking aid control unit -J446- (only models with parking aid)
12 5 Taxi meter -G41- (only taxi)
Mirror taxi meter -G511- (only taxi)
12 10 2-pin connector -T2ac- (applies to special vehicles only)
28-pin connector -T28a- (applies to special vehicles only)
13 5 Headlight range control regulator -E102-
Left headlight range control motor -V48-
Right headlight range control motor -V49-
Traction control system switch -E132-
TCS and ESP button -E256-
Selector lever -E313- (only models with direct shift gearbox)
Brake light switch -F-
Brake light relay -J111- (only models without central locking)
ABS control unit -J104-
Trailer detector control unit -J345-
Power steering control unit -J500- (only models with power steering)
Selector lever sensors control unit -J587- (only models with direct shift gearbox)
Mechatronic unit for dual clutch gearbox -J743- (only models with direct shift gearbox)
Four-wheel drive control unit -J492-
14 5 Air mass meter -G70- (BLS, BSU, BJB, BDJ, BST, BMM, CHWA)
Heater element for crankcase breather -N79- (BSE, BSF, BLS, BSU, BJB, BSX, BMM, CHWA)
Reversing light switch -F4-
Auxiliary heater operation relay -J485- (only models with auxiliary coolant heater)
Activated charcoal filter system solenoid valve 1 -N80- (BSX)
16-pin connector -T16- (self-diagnosis connection)
15 5 Airbag control unit -J234-
Front passenger side airbag deactivated warning lamp -K145-
16 5 Heater/heat output switch -E16- (only models without air conditioning system)
High pressure sender -G65- (only models with air conditioning system)
Oil level and oil temperature sender -G266- (only for models with flexible service interval display)
Climatronic control unit -J255- (only models with Climatronic)
Control unit in dash panel insert -J285-
Low heat output relay -J359- (only models with PTC (Positive Temperature Coefficient) heater)
High heat output relay -J360- (only models with PTC (Positive Temperature Coefficient) heater)
Automatic anti-dazzle interior mirror -Y7-
Air quality sensor -G238- (only models with Climatronic)
17 7.5 Left tail light and rear fog light bulb -M41- (models without central locking)
Rear fog light cut-out contact switch -F216- (only models with trailer operation and without central locking)
18 5 Taxi alarm remote control, control unit -J601- (only taxi)
10-pin connector -T10c- (for models with electric interface only)
19 5 10-pin connector -T10c- (for models with electric interface only)
19 10 Taxi meter -G41- (only taxi)
Mirror taxi meter -G511- (only taxi)
Two-way radio -R8- (only taxi)
20 7.5 Onboard supply control unit -J519- (Interior light)
21 10 Selector lever -E313- (only models with direct shift gearbox)
Selector lever sensors control unit -J587- (only models with direct shift gearbox)
Tiptronic switch -F189- (only models with direct shift gearbox)
Automatic gearbox control unit -J217-
16-pin connector -T16- (self-diagnosis connection)
Climatronic control unit -J255- (only models with Climatronic)
Heater/heat output switch -E16-
Air conditioning system control unit -J301-
Remote control receiver for auxiliary coolant heater -R149- (only models with remote control receiver for auxiliary coolant heater)
Light switch -E1-
Rain and light detector sensor -G397- (models with rain and light detector sensor only)
Control unit in dash panel insert -J285-
Steering column electronics control unit -J527-
Data bus diagnostic interface -J533-
22 10 Driver door control unit -J386-
Front passenger door control unit -J387-
23 5 Interior light switch (taxi) -E115- (only taxi)
Taxi sign switch -E138- (only taxi)
Hands-free system button -E487- (only taxi)
23 10 3-pin connector -T3r- (applies to special vehicles only)
10-pin connector -T10c- (for models with electric interface only)
24 5 Interior monitoring sensor -G273-
Vehicle inclination sender -G384-
Alarm horn -H12-
25 – Not used
26 10 2-pin connector -T2ab- (applies to special vehicles only)
27 15 Cut-out relay for air conditioning system magnetic coupling -J246- (only for models with hydraulic steering)
28 5 Light switch -E1- (models with central locking)
28 20 Rear fog light switch -E18- (only models without central locking)
29 15 Rear window wiper motor -V12- (models with rear window wiper only)
30 25 Light switch -E1- (only models without central locking)
31 5 Heater/heat output switch -E16- (only models without air conditioning system)
Air conditioning system control unit -J301- (only models with air conditioning system)
Climatronic control unit -J255- (only models with air conditioning system)Left washer jet heater element -Z20-
Right washer jet heater element -Z21-
32 15 Windscreen and rear window washer pump -V59-
33 40 Heater/heat output switch -E16-
Air conditioning system control unit -J301-
Auxiliary heater operation relay -J485- (only models with auxiliary coolant heater)
34 – Not used
35 10 Fluorescent light in rear of high roof -W41- (applies to special vehicles only)
Fluorescent light in centre of high roof -W42- (applies to special vehicles only)
36 – Not used
37 15 Right dipped beam bulb -M31- (models without central locking)
38 15 Left dipped beam bulb -M29- (models without central locking only)
39 20 10-pin connector -T10ai- (applies to special vehicles only)
40 20 Trailer detector control unit -J345-
41 20 Trailer detector control unit -J345-
42 20 Trailer detector control unit -J345-
43 15 Electric fuel pump 2 relay -J49- (BSE, BSF, BUD, BSX)
Fuel pump relay -J17- (BDJ, BST, BLS, BSU, BJB, BSE, BSF, BUD, BSX, BMM)
44 40 Fresh air blower control unit -J126-
45 20 Headlight washer system relay -J39- (only models with headlight washer system)
Headlight washer system pump -V11- (only models with headlight washer system)
46 15 Treble tone horn -H2-
Bass tone horn -H7-
Horn relay -J413-
47 25 Cigarette lighter -U1-
48 30 Heated front seats control unit -J774-
49 30 Driver door control unit -J386- (only for model with electric window regulator)
Front passenger door control unit -J387- (only for model with electric window regulator)
50 25 Convenience system central control unit -J393-
51 30 10-pin connector -T10ai- (applies to special vehicles only)
52 25 Fresh air blower relay -J13- (only models with auxiliary heater)
Onboard supply control unit -J519-
Heated rear window -Z1-
53 15 12 V socket -U5- (near handbrake lever)
53 30 12 V socket -U5- (near handbrake lever)
12 V socket 2 -U18- (left luggage compartment)
54 – Not used
55 – Not used
56 – Not used
57 5 2-way radio switch -E72- (applies to special vehicles only)
Engine continues to run without key button -E489- (applies to special vehicles only)
Accident data memory -J754- (applies to special vehicles only)
10-pin connector -T10c- (for models with electric interface only)
58 10 4-pin connector -T4g- (applies to special vehicles only)
59 – Not used
60 – Not used

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Caddy (III; 2010 – 2015) – fuse and relay box diagram

Posted on by admin

Volkswagen Caddy (III; 2010 – 2015) – fuse and relay  box diagram

Year of production: 2010, 2011, 2012, 2013, 2014, 2015



In this article, we take a look at the third-generation  Volkswagen Caddy (2K) before its first facelift, produced between 2003 and 2010. You will find fuse box diagrams for the 2010 – 2015 models, along with details on the location of the fuse panels inside the vehicle and the assignment of each fuse (fuse layout).



Location

Volkswagen Caddy (III; 2010 – 2015) – fuse box location
Volkswagen Caddy (III; 2010 – 2015) – fuse box location



  1. Fuses on fuse holder A -SA- (On the electronics box, on left in engine compartment)
  2. Fuses on fuse holder B -SB- (On left in engine compartment)
  3. Fuses on fuse holder C -SC- (Under left dash panel)

Engine Compartment

Fitting location of fuse holder A (A -SA-)

Fuse box diagram

Volkswagen Caddy (III; 2010 - 2015) - fuse box diagram - fitting location of fuse holder A (A -SA-)
Volkswagen Caddy (III; 2010 – 2015) – fuse box diagram – fitting location of fuse holder A (A -SA-)



Assignment of the fuses in the engine compartment (pre-fuse box)

No.
 A
 Function/component
1 150 Alternator -C-
200 Alternator -C-1)
2 80 Power steering control unit -J500-
Electromechanical power steering motor -V187-
3 50 Radiator fan control unit -J293-
4 80 X-contact relief relay -J59-

t Fuse holder C -SC- (-SC28- up to -SC33- )
5 80 Fuse holder C -SC- (-SC20- up to -SC24- and -SC43- up to -SC53- )
6 40 Low heat output relay -J359-
7 80 High heat output relay -J360-
1) Models with 140 A generator only

Fitting location of E-box high fuse holder (B -SB-)

Fuse box diagram

Volkswagen Caddy (III; 2010 - 2015) - fuse box diagram - engine compartment (holder B -SB-)
Volkswagen Caddy (III; 2010 – 2015) – fuse box diagram – engine compartment (holder B -SB-)



Assignment of the fuses in the engine compartment (holder B)

No.
 A
 Function/component
1 – –
2 30 Mechatronic unit for dual clutch gearbox -J743-
3 5 Battery monitoring control unit -J367-
Onboard supply control unit -J519- (T52a/24)
4 20 ABS control unit -J104-
ABS hydraulic unit -N55-
5 15 Mechatronic unit for dual clutch gearbox -J743-
6 5 Control unit in dash panel insert -J285-
Steering column electronics control unit -J527-
7 40 Terminal 15 voltage supply relay -J329-
Fuse holder C -SC- (-SC9- up to -SC16- and -SC25- up to -SC27- )
8 15 Control unit with display for radio and navigation -J503-
Radio -R-
Voltage stabiliser -J532-3)
Control module with display unit for radio and navigation system -J503-
Radio -R-
Fuse 57 on fuse holder C -SC57-
Fuse 58 on fuse holder C -SC58-
9 5 Mobile telephone operating electronics control unit -J412-4)
10 5 Main relay -J271-
Engine control unit -J623-
Engine component current supply relay -J757-
11 30 Auxiliary heater control unit -J364-
12 5 Data bus diagnostic interface -J533-
13 15 Engine control unit -J623- (petrol engine)
30 Engine control unit -J623- (diesel engine)
14 15 Fuel pressure regulating valve -N276- (diesel engine)
Fuel metering valve -N290- (diesel engine)
20 Ignition transformer -N152-
Ignition coil 1 with output stage -N70-
Ignition coil 2 with output stage -N127-
Ignition coil 3 with output stage -N291-
Ignition coil 4 with output stage -N292-
15 5 Low heat output relay -J359- (diesel engine)
High heat output relay -J360- (diesel engine)
Fuel pump relay -N17-
Electric fuel pump 2 relay -J49-
Automatic glow period control unit -J179-
10 Lambda probe heater -Z19-
Lambda probe 1 heater after catalytic converter -Z29-
Low heat output relay -J359-
High heat output relay -J360-
Fuel pump switch-off relay -J333-2)
Gas injection valve 1 -N366-1)
Gas injection valve 2 -N367-1)
Gas injection valve 3 -N368-1)
Gas injection valve 4 -N369-1)
15 High-pressure valve for gas mode -N372-2)
Valve for gas tank -N495-2)
Sensor for gas level gauge -G707-2)
Gas injection valve 1 -N366-2)
Gas injection valve 2 -N367-2)
Gas injection valve 3 -N368-2)
Gas injection valve 4 -N369-2)
16 30 Onboard supply control unit -J519- (T52c/42)
Light bulb for right foglamp -L23-
Right cornering light bulb -L149-
Rear left fog light bulb -L46- , or rear right fog light bulb -L47-
Right daytime running light bulb -L175-
Left side light bulb -M1-
Right tail light bulb -M2-
Rear left turn signal bulb -M6-
Front right turn signal bulb -M7-
Left brake light bulb -M9-
Right reversing light bulb -M17-
Left turn signal repeater bulb -M18-
High-mounted brake light bulb -M25-
Right headlight dipped beam bulb -M31-
Right headlight main beam bulb -M32-
17 15 Horn relay -J413-
18 30 Special vehicle control unit -J608-
19 30 Wiper motor control unit -J400-
20 10 Fuel tank shut-off valve 1 -N361-1)
Fuel tank shut-off valve 2 -N362-1)
Fuel tank shut-off valve 3 -N363-1)
Fuel tank shut-off valve 4 -N429-1)
Fuel tank shut-off valve 5 -N430-1)
Coolant circulation pump -V50-
21 10 Lambda probe heater -Z19- (diesel engine)
15 Fuel pump control unit -J538-
Lambda probe heater -Z19-
Lambda probe 1 heater after catalytic converter -Z29-
22 5 Clutch position sender -G476-
Brake light switch -F-5)
23 5 Additional coolant pump relay -J496-
10 Air mass meter -G70- (Diesel engine)
Charge pressure control solenoid valve -N75- (Diesel engine)
Exhaust gas recirculation cooler changeover valve -N345- (Diesel engine)
Control unit for gas mode -J659-
Relay for gas shut-off valves -J908-1)
High-pressure valve for gas mode -N372-1)
15 Fuel pressure regulating valve -N276-
24 10 Radiator fan control unit -J293-
Secondary air pump relay -J299-
Additional coolant pump relay -J496-
Activated charcoal filter solenoid valve 1 -N80-
Coolant regulating valve -N515-
Variable intake manifold changeover valve -N156-
Coolant circulation pump 2 -V178-
Injector, cylinder 1 -N30-1)
Injector, cylinder 2 -N31-1)
Injector, cylinder 3 -N32-1)
Injector, cylinder 4 -N33-1)
25 40 ABS hydraulic pump -V64-
ABS control unit -J104-
26 30 Onboard supply control unit -J519- (T52a/1)
Left cornering light bulb -L148-
Left fog light bulb -L22-
Rear left fog light bulb -L46- , or rear right fog light bulb -L47-
Left daytime running light bulb -L174-
Right side light bulb -M3-
Left tail light bulb -M4-
Front left turn signal bulb -M5-
Rear right turn signal bulb -M8-
Right brake light bulb -M10-
Left reversing light bulb -M16-
Right turn signal repeater bulb -M19-
Left headlight dipped beam bulb -M29-
Left headlight main beam bulb -M30-
27 40 Secondary air pump motor -V101-
50 Automatic glow period control unit -J179-
28 – –
29 30 Fuse 18 on fuse holder C -SC18-
Fuse 19 on fuse holder C -SC19-
50 Fuse 35 on fuse holder C -SC35-
Fuse 39 on fuse holder C -SC39-
Fuse 54 on fuse holder C -SC54-
Fuse 55 on fuse holder C -SC55-
Fuse 59 on fuse holder C -SC59-
Fuse 60 on fuse holder C -SC60-
30 50 Fuse holder C -SC- (-SC40- up to -SC42- )
1) for vehicles with engine code BSX only
2) for vehicles with engine code CHGA only
3) for vehicles with start/stop system only
4) for vehicles without start/stop system only
5) effective since November 2011

Passenger Comparment

Position of fuses on fuse holder C -SC-

Fuse box diagram

Volkswagen Caddy (III; 2010 - 2015) - fuse box diagram - passenger compartment (holder C -SC-)
Volkswagen Caddy (III; 2010 – 2015) – fuse box diagram – passenger compartment (holder C -SC-)



Assignment of the fuses in the passenger compartment (holder C)

No.
 A
 Function/component
1 – –
2 – –
3 – –
4 – –
5 – –
6 – –
7 – –
8 – –
9 10 -Special vehicles-
4-pin connector -T4aa- , Pin 1 3)
10-pin connector -T10l- , Pin 4 (Interface for special functions)
10 5 Fuel pump relay -J17-
Main relay -J271-
Gas mode control unit -J659-
Terminal 50 voltage supply relay -J682-
Starter relay 1 -J906-
Voltage stabiliser -J532-
Data bus diagnostic interface -J533-
Engine control unit -J623-
11 5 Parking aid control unit -J446-
Park assist steering control unit -J791-
12 5 -Special vehicles-
Taximeter -G41-
Mirror taximeter -G511-
103) -Special vehicles-3)
2-pin connector -T2ab- , Pin 1
2-pin connector -T2ac- , Pin 1
28-pin connector -T28b- , Pin 13
204) -Special vehicles-4)
8-pin connector -T8k- , Pin 8
28-pin connector -T28a- , Pin 20
28-pin connector -T28b- , Pin 20
13 7.5 Brake light switch -F-3)
Headlight range control adjuster -E102-
TCS and ESP button -E256-
Tyre pressure monitor display button -E492-
Start/Stop operation button -E693-
ABS control unit -J104-
Trailer detector control unit -J345-
All-wheel drive control unit -J492-
Power steering control unit -J500-
Selector lever sensors control unit -J587-
Mechatronic unit for dual clutch gearbox -J743-
Left headlight range control motor -V48-
Right headlight range control motor -V49-
Control unit for cornering light and headlight range control -J745-
14 10 Reversing light switch -F4-
Air mass meter -G70-
Auxiliary heater operation relay -J485-
Control unit in dash panel insert -J285-
Heater element for crankcase breather -N79-
Activated charcoal filter solenoid valve 1 -N80-
Diagnostic connection -U31-16-pin connector -T16- , Pin 1
15 5 Airbag control unit -J234-
Front passenger side airbag deactivated warning lamp -K145-
16 5 Light switch -E1-
Heater/heat output switch -E16-
High-pressure sender -G65-
Air quality sensor -G238-
Oil level and oil temperature sender -G266-
Automatic anti-dazzle interior mirror -Y7-
17 – –
18 10 -Special vehicles-
Taxi alarm remote control control unit -J601-
10 -Special vehicles-
10-pin connector -T10l- , Pin 6 (Interface for special functions)
19 10 -Special vehicles-
Taximeter -G41-
Mirror taximeter -G511-
Taxi alarm remote control control unit -J601-
Two-way radio -R8-
Printer -R98-
10 -Special vehicles-
10-pin connector -T10l- , Pin 7 (Interface for special functions)
20 20 Cigarette lighter -U1-7)
21 10 Light switch -E1-
Heater/heat output switch -E16-
Rain and light sensor -G397-
Heated rear window relay -J9-
Climatronic control unit -J255-
Air conditioning system control unit -J301-
Horn relay -J413-
Remote control receiver for auxiliary coolant heater -R149-
Selector lever sensors control unit -J587-
Diagnostic connection -U31-16-pin connector -T16- , Pin 16
Switch for interior lighting -E599- (Camper)
Rear interior light -W43- (Camper)
22 10 Onboard supply control unit -J519- (T52b/42) 2)
23 5 -Special vehicles-
Interior light switch (taxi) -E115-
Taxi sign switch -E138-
10-pin connector -T10l- , Pin 1 (Interface for special functions)
10 -Special vehicles-
3-pin connector -T3ak- , Pin 1 3)
  Flashing lights relay -J630-4)
24 5 Interior monitoring sensor -G273-
Vehicle inclination sender -G384-
Anti-theft alarm sensor -G578-
Alarm horn -H12-
Onboard supply control unit -J519- (T52c/1)
25 10 Output module for left headlight -J667-
26 10 Output module for right headlight -J668-
27 – –
28 20 12-V socket 3 -U19- , in storage compart.
29 15 Rear window wiper motor -V12-
30 – –
31 5 Heater/heat output switch -E16-
Left washer jet heater element -Z20-
Right washer jet heater element -Z21-
32 – –
33 40 Air conditioning system control unit -J301-
Heater/heat output switch -E16-
34 – –
35 10 -Special vehicles-3)
Fluorescent light in rear of high roof -W41-
Fluorescent light in centre of high roof -W42-
36 – –
37 – –
38 – –
39 20 -Special vehicles-
10-pin connector -T10ai- , Pin 1 3)
30 -Special vehicles-
4-pin connector -T4ad- , Pin 1 4)
40 20 Trailer detector control unit -J345-
41 20 Trailer detector control unit -J345-
42 20 Trailer detector control unit -J345-
43 15 Fuel pump relay -J17-
Electric fuel pump 2 relay -J49-
Supplementary fuel pump -V393-
44 40 Fresh air blower control unit -J126-
Fresh air blower -V2-
45 20 Headlight washer system relay -J39-
Headlight washer system pump -V11-
46 10 Onboard supply control unit -J519- (T52b/42) 1)
Front interior light -W1-
Luggage compartment light -W3-
Glove compartment light -W6-
Rear interior light -W43-
30 Driver door control unit -J386-2)
47 30 Cigarette lighter -U1-6)
X-contact relief relay -J59-7)8)
Fuse holder C -SC- (-SC28- up to -SC33- ) 7)8)
48 30 Heated front seats control unit -J774-
49 30 Driver door control unit -J386-1)
Front passenger door control unit -J387-
50 20 Onboard supply control unit -J519- (T52b/1)
Rear window wiper motor -V12-
Windscreen and rear window washer pump -V59-
Washer pump -V5-
51 15 Trailer voltage supply relay -J941-
Trailer socket -U10- (T13/10)
30 -Special vehicles-
10-pin connector -T10ai- , Pin 4
10-pin connector -T10ai- , Pin 5
52 25 Heated rear window relay -J9-
Heated rear window -Z1-
Heated rear window in left wing door -Z26-
Heated rear window in right wing door -Z27-
Fresh air blower relay -J13-
Fresh air blower series resistor with overheating fuse -N24-
Fresh air blower -V2-
53 156)
207)		 12 V socket -U5- , in the rear centre console
12 V socket 2 -U18- , In rear left side panel
54 15 -Special vehicles-4)
Switch-over relay 1 for roof ventilator -J180-
55 15 -Special vehicles-4)
8-pin connector -T8m- , Pin 4
8-pin connector -T8n- , Pin 4
56 – –
57 5 Control unit in dash panel insert -J285-5)
Steering column electronics control unit -J527-5)
58 5 Mobile telephone operating electronics control unit -J412-5)
59 5 -Special vehicles-
Radio switch -E72-
Ignition bypass button -E489-
Button for daytime running light switch-off -E652-
Accident data memory -J754-
60 30 -Special vehicles-
3-pin connector -T3al- , Pin 1
1) before April 2011
2) after May 2011
3) before October 2011
4) after November 2011
5) for vehicles with start-stop system only
6) before October 2012
7) after November 2012
8) for vehicles with Climatronic only

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Iveco Daily (III; 2000 – 2006) – fuse and relay box diagram

Posted on by admin

Iveco Daily (III; 2000 – 2006) – fuse and relay box diagram



Year of production: 2000, 2001, 2002, 2003, 2004, 2005, 2006



This article covers the second-generation Iveco Daily (III), produced from 2000 to 2006. It includes fuse box diagrams for the 2000, 2001, 2002, 2003, 2004, 2005 and 2006 models, provides details on the location of the fuse panels inside the vehicle, and explains the function and layout of each fuse.

Passenger compartment

Fuse box diagram

Iveco Daily(III; 2000 - 2006) - fuse and relay box diagram - passenger compartment
Iveco Daily(III; 2000 – 2006) – fuse and relay box diagram – passenger compartment



Assignment of the fuses in the passenger compartment

No Function A
1 ID/TCA (.11): Thermal starter 40
1 UNIJET (.13-.15): Thermal starter 80
1 UNIJET F1A (.10-.12): Thermal starter, additional heater 30
2 Immobilizer/Warming/EDC 5
3 DDS device 5
4 Instrument cluster (+30) 5
5 Instrument cluster (+15) 5
6 Stalk unit (rear fog guard, flasher) 5
7 Stalk unit (low beams) 10
8 Stalk unit (high beams) 15
9 Stalk unit (side lights) 15
10 Windscreen wiper 15
11 Stalk unit (direction indicators/hazard warning lights) 15
12 Stalk unit (horns) 15
13 Reversing light 5
14 Side light, clearance, no. plate light 5
15 Side light cluster lighting 5
16 Left low beam headlamp 10
17 Right low beam headlamp 10
18 Left high beam headlamp 10
19 Right high beam headlamp/headlamp aming 10
20 Interior lighting/radio/cigar lighter 10
20 UNIJET F1A (.10-.12): Interior lighting/radio 10
21 Electric windscreen defrosting unit 30
21 UNIJET F1A (.10-.12): Cigar lighter 15
22 Heated fuel filter 15
23 EDC electronic control unit 25
24 EDC 10
25 Stop lights 5
26 13-pin current socket 15
27 13-pin current socket 15
28 13-pin current socket 10
29 38-pin diagnostic connector 5
30 Fog lamps 10
31 Climate control, additional heater, engine cooling 5
31 UNIJET F1A (.10-.12): Compressor, timer, engine fan 10
32 Climate control 5
33 Additional heater 20
34 Headlamp washer 20
35 Rear differential lock 5
36 ABS, EBD, ABD failure warning light 5
37 ABS 5
39 Heated mirrors 10
39 UNIJET F1A (.10-.12): Heated mirrors, heated rear-screen, heated windscreen 10
40 Power windows 30
40 UNIJET F1A (.10-.12): Power windows (left) 20
41 Heated rear-screen, heated windscreen 10/ 20
42 Self-levelling suspensions (Wabco) 5
43 Air bag failure warning light 5
44 Self-levelling suspensions (Wabco) 40
45 Air-bag 5
46 Solenoid valve for thermal starter 5
46 UNIJET F1A (.10-.12): Power windows (right) 20
47 Electric fuel pump 10
48 Door locking/alarm 30
49 Door locking/alarm 5
50 Rear differential lock 30
51 Total power takeoff 10
52 Front differential lock (4×4) 30
53 Self-levelling suspensions Techniek) 30
54 Electric hatch (van and 6+1) 15
55 Rototranslating door 15
Code Relays
25035 Switching on external lights
25003 Switching on fog lamps
25006 Switching on stop lights
25704 Total power takeoff engagement control
25104 Switching off Retarder with ABS on
25209 Loads cut-off during starting
25222 Thermal starter engagement enable
25223 Thermal starter fan control
25307 Climate control compressor engagement
25336 Engine cooling
25337 Climate control compressor disengagement
25340 Compressor on signal
25620 Fuel filter clogged signal
25705 Diagnostics enable
25810 Heated fuel filter circuit control
25811 Advance variator control (KSB)
25818 Heated windscreen switching on
25837 Electric fuel pump switching on
25858 EDC switching on
25926 Suspension raising enable
25927 Suspension lowering enable
25928 Rear-screen heating switching on
61002A Anti-retum from Trinary
61002В Anti-retum from TGC (bus)
66010 Timer for headlamp washer
WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Iveco Daily (V; 2011 – 2014) – fuse and relay box diagram

Posted on by admin

Iveco Daily (V; 2011 – 2014) – fuse and relay box diagram

Year of production: 2011, 2012, 2013, 2014



This article covers the second-generation  Iveco Daily V (5th generation), produced from 2011 to 2014. It includes fuse box diagrams for the 2011, 2012, 2013 and 2014 models, provides details on the location of the fuse panels inside the vehicle, and explains the function and layout of each fuse.

Passenger compartment (under the dashboard)

Fuse box diagram

Iveco Daily (V; 2011 - 2014) - fuse and relay box doagram - passenger compartment
Iveco Daily (V; 2011 – 2014) – fuse and relay box doagram – passenger compartment



Assignment of the fuses in the passenger compartment (under the dashboard)

No Function A
F12 Т1b relay (30-87) for right low beam headlight 7,5
F13 T1a relay (30-87) for left low beam headlight – headlight adjuster 7,5
F31 T54 relay (86) for headlight washers and T50 – T51 – T52 – T53 – eln motors and controls for electric windows 5
F32 T44 relay (30-86) for battery removal with minimum voltage – internal lighting 7,5
F33 Ooutswinging door 15
F34 Fitter socket 20
F36 T20 relay for MODUS car radio – tachograph – convergence – siren – parking sensor 15
F37 Instrument panel – stop lights – trailer socket 7,5
F38 Central locking 20
F42 ABS9 or ESP9 5
F43 T23a relay (86-87) for windscreen washer and T23b relay (86-87) 20
F47 T25a relay (86-87) and T25b (86-87) for driver’s side electric window 25
F48 T26a relay (86-87) and T26b (86-87) for passenger side electric window 25
F49 Control panel – tachograph – exp. module – fitter socket – ASR control – Telma (coil) – video camera – outswinging – rear differential lock 5
F50 Airbag 5
F51 Green filter – car radio – toe-in – parking sensors -CAF 5
F53 Instrument panel – timer for supplementary heater 5
F89 AVAILABLE –
F90 T11a relay (30-86) for left full beam headlight 7,5
F91 T11b relay (30-86) for right high beam headlight 7,5
F92 T12a relay (30-86) for left foglight 7,5
F93 T12b relay (30-86) for right foglight 7,5
No. Relays
T01а Left low beam headlight – headlight adjuster
T01b Right low beam headlight
Т11а Left high beam headlight
T11b Right high beam headlight
Т12а Left foglight
Т12b Right foglight
Т23а Windscreen washer
Т25а Driver’s side electric window UP
Т25b Driver’s side electric window DOWN
Т26а Passenger side electric window UP
Т26b Passenger side electric window DOWN
Т37а Rear doors central closing
Т37b Central closing (common)
Т37с Side doors central closing
T37d Rear door central closing
Т44 Battery removal with minimum voltage

Engine compartment (Fuse box above the battery)

Fuse box diagram

Iveco Daily (V; 2011 - 2014) - fuse and relay box doagram - engine compartment (above the battery)
Iveco Daily (V; 2011 – 2014) – fuse and relay box doagram – engine compartment (above the battery)



Assignment of the fuses in the engine compartment (above the battery)

No Function A
1 +30 positive from F75 for starter motor, alternator and retarder (if present) 500
2 +30 positive from F70 for SCM BUS-BAR 150
3 +30 positive from F73 for pre-heating glow plugs 60
4 +30 positive from F72 for braking node 40
5 +30 positive from F7I for Ist Body Computer power 80
6 +30 positive to F64 in SCM/A for IBS sensor for Stop & Start –

Engine compartment

Fuse box diagram

Iveco Daily (V; 2011 - 2014) - fuse and relay box doagram - engine compartment
Iveco Daily (V; 2011 – 2014) – fuse and relay box doagram – engine compartment



Assignment of the fuses in the engine compartment

No Function A
F01 Air suspensions 40
F02 Ignition switch 30
F03 Cab climate control fans and engine coolant supplementary heater 40
F04 Braking system (valves) 30
F05 Air suspensions 40
F06 SCM 1 /А – SCM 1 /В – SCM2 power supply 40
F07 T7 relay (30-87) for power discharge from ignition switch 40
F08 T8 relay (30-87) for fuel pump 15
F09 Automatic transmission 30
F11 T64 relay (30-87) for heated exterior mirrors and heated windscreen 15
F11 EDC FI A (primary loads) from MAIN RELAY injectors (CNG) 15
F14 Automatic transmission – MAIN RELAY T9 (86) 10
F15 T2 relay (30-87) for BOSCH cooling pump 10
F16 Cigarette lighter from T7 15
F17 EDC FIC (secondary loads) from MAIN RELAY Smart Drive Unit (CNG) 10/15
F18 Rear differential lock 30
F19 T6 relay (30-87) for horn 7,5
F20 13 pin socket 10
F21 TI4 relay (30) for cylinder solenoid valves (CNG) 7,5
F22 EDC F1A and F1C (primary loads) from MAIN RELAY – lambda probe 20
F22 Waste gate (CNG) – lambda probes (CNG) 15
F23 T19 relay (30-87) for wipers 30
F24 Power socket from T7 15
F30 T3 relay (30-87) for side marker lamps 7,5
F81 Automatic transmission 30
F82 Body computer 2nd power 70
F83 T30 relay (30-87) for heating fans inside cab 40
F84 Solenoid valve power for the cylinders 15
F84 T5 and T14 relays for Baruffaldi coupling 7,5
F85 T31 relay (30-87) for fuel filter and sediment filter heater 25
F87 EDC – automatic transmission 7,5
F87 5SF – automatic transmission 7,5
Relay
T02 BOSCH cooling pump 20
T02 Baruffaldi coupling from trinary (CNG) 20
Т03 Side marker lamps 30
T05 Ist gear Baruffaldi coupling 30
T06 Horn 20
T07 Power discharge from ignition switch 50
T08 Fuel pump 20
T09 MAIN RELAY 30
T10 Engine start-up prevention 30
T14 2nd gear Baruffaldi coupling 20
T14 Cylinder solenoid valves (CNG) 20
T17 Windscreen wiper 1or 2nd speed 10/20
T19 Indscreen wiper speed activation 10/20
T20 Diagnostics with MODUS 20
Т30 Cab heating fans 50
T31 Fuel filter heater and sediment filter 30
SCM1/A
F60 Supplementary climate control 30
F61 T51 relay (30-87) for air conditioner compressor 7,5
F62 T52 relay (30-87) for right heated rear window 10
F63 Left heated rear window blow-by – unit heater – T56 relay (86) for compressor 10
F64 IBS sensor for Stop & Start 5
F65 T7 relay (30-87) for heated seats 20
Relay
T49 Stop & start 30
T50 AVAILABLE –
T51 Compressor activation from climate control 20
T52 Heated rear windows 20
SCM1/B
F66 T54 relay (30-87) for headlight washers 15
F67 AVAILABLE –
F68 AVAILABLE –
F69 Optional 4448 for bus 5
F77 AVAILABLE –
F78 AVAILABLE  –
Relay
T53 Unit heater 20
T54 Headlight washers 20
T55 Power Take Off 10/20
T56 Stop lights with TELMA retarder activated 10/20
SCM2
T63 AVAILABLE –
T64 External heated mirrors – heated windscreen 20

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Iveco Daily (II; 1989 – 2000) – fuse and relay box diagram

Posted on by admin

Iveco Daily (1989 – 2000) – fuse and relay  box diagram

Year of production: 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000



This article covers the second-generation   Iveco Daily II (2nd generation), produced from 1989 to 2000. It includes fuse box diagrams for the 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999 and 2000 models, provides details on the location of the fuse panels inside the vehicle, and explains the function and layout of each fuse.

Fuse box diagram

Iveco Daily (II; 1989 - 2000) - fuse and relay box diagram
Iveco Daily (II; 1989 – 2000) – fuse and relay box diagram



Assignment of the fuses in the fuse box

No. A Function
1 5 Lh front parking light – Lh number plate light- Rh rear parking light – Rh front and Lh rear marker
2 5 lights – Dashboard. Rh front parking light – Rh number plate light -Lh rear parking light – Lh front and Rh rear
3 7,5 marker lights. Lh low beam light
4 7,5 Rh low beam light
5 7,5 Lh high beam light
6 7,5 Rh high beam light
7 3 Electronic speedometer or tachograph
8 5 Brake – instrument – telltale failure
9 10 Fog headlights
10 3 Rear fog lamps
11 5 Interior lighting (bus)
12 7,5 Not used
13 10 Hazard lights
И 5 Tractor unit turn signal lights
15 3 Engine stop
16 7,5 Reversing lights – stop lights
17 10 Homs
18 7,5 Interior lighting – Cigar lighter
19 15 Heated fuel oil filter
20 10 Windscreen wiper – Windscreen washer pump
21 15 Electric heater – Electromagnetic fan
22 7,5 Push switch lighting – flashing light
23 25 Power window – Electromagnetic fan
24 10 Emergency control pushbutton (Bus)
25 20 Air conditioning
26 20 Air conditioning
27 25 Air conditioning
28 25 Electric heater
29 40 Thermostarter control unit
Relays
E1 Low beam lights (switch contacts)
E2 High beam lights (N.O. contact)
E3 Users cutoff during starting stage (N.O. contact)
E4 Fog lamps (switch contacts)
E5 Heated fuel oil filter
E6 Emergency control unit
E7 Day lights + fog lamps
E8 Horns (N.O. contact)
E9 Windscreen wiper intermittent
E10 Flashing light (N.O. contact)
E11 Diode for emergency control unit (with day lights)
E12 Not used
E13 Brake system failure (switch contact)
E14a Emergency control unit (with day lights)
E14b Emergency control unit (with day lights)
E15 Direction indicators – single charge emergency
C Air conditioning

Engine compartment

Fuse box diagram

Iveco Daily (II; 1989 - 2000) - fuse and relay box diagram - engine compartment
Iveco Daily (II; 1989 – 2000) – fuse and relay box diagram – engine compartment



Assignment of the fuses in the engine compartment

Fuse Ampere rating [A] Description
1 30 Electro-hidraulic assembly (Power Pack)
2 20 Electronic control unit (from battery positive)
3 20 Electronic control unit (lock and key protection)



Relay Description
a Circuit protection diode casing
b Optical indicator ON button
c Reversing light
d Buzzer (acoustic indicator)

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.

Volkswagen Touareg (2005 – 2010) – fuse and relay box diagram

Posted on by admin

Volkswagen Touareg (2005 – 2010) – fuse and relay box diagram

Year of production: 2005, 2006, 2007, 2008, 2009, 2010

Fuse assignment in fuse box, left-side dash panel

Fuse box location

Fuse holder on the left side edge of the instrument panel.

Volkswagen Touareg - fuse and relay box location passenger -compartment (instrument panel left-side)
Volkswagen Touareg – fuse and relay box location passenger -compartment (instrument panel left-side)

Fuse box diagram

Volkswagen Touareg - fuse and relay box diagram - passenger compartment (instrument panel left-side)
Volkswagen Touareg – fuse and relay box diagram – passenger compartment (instrument panel left-side)



Assignment of the fuses in the left-side of the dash panel.

No.
 А
 Function/component
1 15
202+8)		 U1 – Cigarette lighter
U9 – Rear cigarette lighter
2 58,1+7)
152+7)		 J160 – Circulation pump relay2)
J708 – Residual heat relay2)
R149 – Remote control receiver for auxiliary coolant heater2)
U18 – 12 V socket 21)
U20 – 12 V socket 41)
3 15
202)		 U5 – 12 V socket
U19 – 12 V socket 3
4 20 J162 – Heater control unit
5 20 U18 – 12 V socket 22)
U19 – 12 V socket 42)
J807 – Relay for power sockets1)
6 15 J518 – Entry and start authorisation control unit3)
J708 – Residual heat relay1)
7 5 T16b – Diagnostic connection
J515 – Aerial selection control unit
G397 – Rain and light detector sensor
8 25
307)		 V – Windscreen wiper motor
9 15 J519 – Onboard supply control unit (windscreen wiper pump)
10 25
307)		 J388 – Rear left door control unit (window regulator)
11 15 J386 – Driver door control unit (central locking)
J388 – Rear left door control unit (central locking)
12 10 J519 – Onboard supply control unit (interior light)
13 – Not assigned
14 25
307)		 J386 – Driver door control unit (window regulator)
15 15 J393 – Convenience system central control unit (right tail light cluster)
16 20 J519 – Onboard supply control unit (fanfare)
17 30 J519 – Onboard supply control unit (left light)
18 20
257)		 J39 – Headlight washer system relay
19 – Not assigned
20 30 J519 – Onboard supply control unit (battery 1)
21 – Not assigned
22 30 J647 – Axle differential lock control unit
J605 – Rear lid control unit
23 10 J647 – Axle differential lock control unit
24 5 J502 – Tyre pressure monitor control unit
25 15 J352 – Steering column and belt height adjustment control unit
26 10 F36 – Clutch pedal switch
J… – Engine control units
J234 – Airbag control unit
J285 – Control unit in dash panel insert
J519 – Onboard supply control unit
K145 – Front passenger side airbag deactivated warning lamp
N378 – Driver seat belt inertia reel magnet
N379 – Front passenger side seat inertia reel magnet
27 5 E183 – Interior monitoring switch
W11 – Rear left reading light
W12 – Rear right reading light
W14 – Front passenger side illuminated vanity mirror
W20 – Driver side illuminated vanity mirror
W51 – Rear lid light
28 – Not assigned
29 – Not assigned
30 – Not assigned
31 – Not assigned
32 – Not assigned
33 15 J527 – Steering column electronics control unit
34 5 G273 – Interior monitoring sensor
G384 – Vehicle inclination sender
J285 – Control unit in dash panel insert2)
35 30 J519 – Onboard supply control unit
36 30 E470 – Driver seat adjustment operating unit
37 – Not assigned
38 – Not assigned
39 5A J9 – Heated rear window relay
J32 – Air conditioning system relay
J329 – Terminal 15 voltage supply relay
J755 – Transport mode relay
J807 – Relay for power sockets1)
40 5 J285 – Control unit in dash panel insert
41 15 J518 – Entry and start authorisation control unit
42 30 J245 – Sliding sunroof adjustment control unit
43 – Not assigned
44 30 E470 – Driver seat adjustment operating unit
J136 – Seat and steering column adjustment control unit with memory
J810 – Driver seat adjustment control unit
45 25 J786 – Heated rear seats control unit
46 – Not assigned
47 10 J647 – Axle differential lock control unit
48 5 J769 – Lane change assist control unit
J770 – Lane change assist control unit 2
49 5 J236 – Servotronic control unit
50 10 G266 – Oil level and oil temperature sender
N79 – Crankcase breather heater element4)
51 5 T16b – Diagnostic connection
F321 – Parking brake contact switch
G238 – Air quality sensor
G550 – Sensor for automatic distance control
J755 – Transport mode relay
52 30
157)		 V12 – Rear window wiper motor
53 5 E1 – Light switch
J527 – Steering column electronics control unit
J393 – Convenience system central control unit
54 10 E102 – Headlight range control regulator5)
J667 – Power output module for left headlight6)
V48 – Left headlight range control motor5)
V49 – Right headlight range control motor5)
55 15 J486 – Fresh air blower relay for 2nd speed
56 40 J32 – Air conditioning system relay
J309 – Solar cell isolation relay
J486 – Fresh air blower relay, 2nd speed
SB55 – Fuse 55 on fuse holder B
V305 – Motor for front Bitron blower regulation
57 40 V306 – Motor for rear Bitron blower regulation8)
J403 – Adaptive suspension compressor relay7)
1) Only one battery onboard supply
2) Only auxiliary battery and two battery onboard supply
3) Only V10 TDI
4) Only models with engine codes BHK, BHL
5) Only models with halogen headlights
6) Only models with cornering light
7) From November 2007
8) Up to November 2007

Fuse assignment in fuse box, right-side dash panel

Fuse box location

Volkswagen Touareg - fuse and relay box location passenger -compartment (instrument panel right-side)
Volkswagen Touareg – fuse and relay box location passenger -compartment (instrument panel right-side)



Fuse box diagram

Volkswagen Touareg - fuse and relay box diagram - passenger compartment (instrument panel right-side)
Volkswagen Touareg – fuse and relay box diagram – passenger compartment (instrument panel right-side)



Assignment of the fuses in the right-side of the dash panel.

No.
 А
 Function/component
1 15
202)		 J345 – Trailer detector control unit
2 5 J446 – Parking aid control unit
3 15 J345 – Trailer detector control unit
4 5 J412 – Mobile telephone operating electronics control unit
5 15
252)		 J345 – Trailer detector control unit
6 30 J104 – ABS control unit
7 5 J646 – Transfer box control unit
8 30 J519 – Onboard supply control unit (right light)
9 10 Individualisation
R190 – Satellite digital radio tuner1)
10 5 J772 – Reversing camera system control unit
R78 – TV tuner
11 20 J503 – Control unit with display for radio and navigation system
R – Radio
R – Preparation for radio and navigation system with TV (models for Japan)
12 30 R12 – Amplifier
13 – Not assigned
14 15 J393 – Convenience system central control unit
15 25
303)		 J389 – Rear right door control unit (window regulator)
16 10
53)		 W3 – Luggage compartment light
17 – Not assigned
18 30 J9 – Heated rear window relay
19 – Not assigned
20 30 U13 – AC/DC converter with socket 12 V – 230 V
U27 – AC/DC converter with socket 12 V – 115 V1)
21 10 F266 – Bonnet contact switch
22 25 J774 – Heated front seats control unit
23 10 J255 – Climatronic control unit
24 30 E471 – Front passenger seat adjustment operating unit
J521 – Front passenger seat adjustment with memory control unit
25 5 E265 – Rear Climatronic operating and display unit
J301 – Air conditioning system control unit
26 – Not assigned
27 15 J197 – Adaptive suspension control unit
28 – Not assigned
29 10
53)		 J217 – Automatic gearbox control unit
30 20 J714 – Power latching system relay
31 15 J393 – Convenience system central control unit
32 10 J387 – Front passenger door control unit (central locking)
J389 – Rear right door control unit (central locking)
33 15 Individualisation
34 25
303)		 J387 – Front passenger side door control unit (window regulator)
35 30 E471 – Front passenger seat adjustment operating unit
36 5 J603 – Vehicle position recognition control unit
J702 – Roof display unit
37 – Not assigned
38 10 J104 – ABS control unit
39 5 J410 – Heated windscreen relay for left side
J411 – Heated windscreen relay for right side
J745 – Cornering light and headlight range control unit
Individualisation
40 10 J646 – Transfer box control unit
41 10 J345 – Trailer detector control unit
42 5 E284 – Garage door operating unit
J530 – Garage door operation control unit
43 5 F41 – Reversing switch
44 5 E94 – Heated driver seat regulator
E95 – Heated front passenger seat regulator
E128 – Heated rear left seat switch with regulator
E129 – Heated rear right seat switch with regulator
E281 – Operating unit to regulate suspension height
Z20 – Left washer jet heater element
Z21 – Right washer jet heater element
45 – Not assigned
46 – Not assigned
47 10 J668 – Power output module for right headlight
48 10 J197 – Adaptive suspension control unit
49 5 Y7 – Automatic anti-dazzle interior mirror
50 5 E256 – TCS and ESP button
51 15 J217 – Automatic gearbox control unit
52 5 F125 – Multifunction switch
F189 – Tiptronic switch
N380 – Selector lever lock for position P solenoid
53 30 J411 – Heated windscreen relay for right side
54 30 J410 – Heated windscreen relay for left side
55 – Not assigned
56 40 J104 – ABS control unit
57 40 J646 – Transfer box control unit
1) Only American markets
2) From May 2008
3) From November 2007

Fuses and relay position assignment in pre-fuse box, under driver seat

Fuse box diagram

Volkswagen Touareg - fuse and relay box diagram - passenger compartment (pre-fuse, under driver seat)
Volkswagen Touareg – fuse and relay box diagram – passenger compartment (pre-fuse, under driver seat)



Pre-fuse box (under driver seat).

No.
 А
 Function/component
SD1 150 Left fuse carrier
SD2 150 Right fuse carrier
SD3 60 Right fuse carrier
SD4 60
403)		 J701 – Voltage supply relay 21)
V306 – Motor for rear Bitron blower regulation3)
SD5 60
403)		 J329 – Terminal 15 voltage supply relay
SD6 – Not assigned
SD7 250 J713 – Charger relay for second battery
SD8 1501)
602)		 Left fuse carrier
J701 – Voltage supply relay 11)
SD9 5 J519 – Onboard supply control unit
SD10 10
53)		 J519 – Onboard supply control unit1)
SD11 5 J519 – Onboard supply control unit1)
SD12 – Not assigned
SD13 40 J403 – Adaptive suspension compressor relay
V306 – Motor for rear Bitron blower regulation1,3)
SD14 – Not assigned
Relays
1 Battery master/isolator switch -E74-
2 Terminal 15 voltage supply relay -J329- (433)
3 Second battery charging circuit relay -J713-
1) Only V10 TDI
2) Only models with additional battery
3) From November 2007

Relay locations for E-box on left under dash panel near centre console

Fuse box diagram

Volkswagen Touareg - fuse and relay box diagram - passenger compartment (e-box; left-side under dashpanel)
Volkswagen Touareg – fuse and relay box diagram – passenger compartment (e-box; left-side under dashpanel)



Relay panel E-Box 1 (on left under dash panel near center console).

No.
 Function/component
D1 Servotronic control unit -J236- (476)
D2 Power latching system relay -J714- (404)
D3 Adaptive suspension compressor relay -J403- (373)
D4 Power sockets relay -J807- (404)
D5 Air conditioning system relay -J32- (100) / (370) optional installation
D6 Fresh air blower relay, 2nd speed -J486- (404), only manually operated air conditioning system
D7 Heated rear window relay -J9- (53)
D8 Circulation pump relay -J160- (404), only VR6 with auxiliary heater
D9 Alternator cut-in relay -J442- (53)
E1 Solar cells isolation relay -J309- (79)
E2 Not assigned
E3 Heated windscreen relay for left side -J410- (53)
E4 Not assigned
E5 Voltage supply relay 2 -J710- (432), only V10 TDI
E6 Not assigned
E7 Headlight washer system relay -J39- (53)
E8 Residual heat relay -J708- (404)
E9 Heated windscreen relay for right side -J411- (53)

Relay carrier on E-box on right under dash panel, near right a-pillar (only right-hand drive)

Fuse box diagram

Volkswagen Tourareg - fuse and relay box diagram - relay carrier on E-box on right-side under dash panel, near right a-pillar (only right-hand drive)
Volkswagen Tourareg – fuse and relay box diagram – relay carrier on E-box on right-side under dash panel, near right a-pillar (only right-hand drive)



Relay panel E-box 2 (on right under dash panel, near right a-pillar)

No. Function/component
D1 Servotronic control unit -J236- (476)
D2 Power latching system relay -J714- (404)
D3 Adaptive suspension compressor relay -J403- (373)
D4 Power sockets relay -J807- (404)
D5 Air conditioning system relay -J32- (100) / (370) optional installation
D6 Fresh air blower relay, 2nd speed -J486- (404), only manually operated air conditioning system
D7 Heated rear window relay -J9- (53)
D8 Circulation pump relay -J160- (404), only VR6 with auxiliary heater
D9 Alternator cut-in relay -J442- (53)
E1 Solar cells isolation relay -J309- (79)
E2 Residual heat relay -J708- (404)
E3 Heated windscreen relay for left side -J410- (53)
E4 Voltage supply relay 2 -J710- (432), only V10 TDI
E5 Heated windscreen relay for right side -J411- (53)
E6 Headlight washer system relay -J39- (53)

Engine compartment relay & fuse box (2.5 l (R5) TDI engine)

Fuse box diagram

Volkswagen Touareg - fuse and relay box diagram - engine compartment relay & fuse box (2.5 l (R5) TDI engine)
Volkswagen Touareg – fuse and relay box diagram – engine compartment relay & fuse box (2.5 l (R5) TDI engine)



Assignment of the fuses in the Engine compartment (2.5L (R5) TDI engine)

No.
 A
 Function/component
1 60 J293 – Radiator fan control unit
2 30 J671 – Radiator fan control unit 21)
3 – Not assigned
4 – Not assigned
5 – Not assigned
6 – Not assigned
7 – Not assigned
8 – Not assigned
9 30 J623 – Engine control unit
10 10 G65 – High-pressure sender
J17 – Fuel pump relay
J255 – Climatronic control unit
J293 – Radiator fan control unit
J301 – Air conditioning system control unit
J445 – Fuel cooling pump relay
J496 – Additional coolant pump relay
J671 – Radiator fan control unit 2
N75 – Charge pressure control solenoid valve
N79 – Crankcase breather heater element
N280 – Air conditioner compressor regulating valve
N345 – Exhaust gas recirculation cooler changeover valve
11 – Not assigned
12 10 J179 – Automatic glow period control unit
J496 – Additional coolant pump relay
13 25 G6 – Fuel system pressurisation pump
G23 – Fuel pump
J17 – Fuel pump relay
J445 – Fuel cooling pump relay
J715 – Tank circuit pressurisation relay
V166 – Fuel cooling pump
14 – Not assigned
15 – Not assigned
16 – Not assigned
17 10 G39 – Lambda probe
Z19 – Lambda probe heater
18 – Not assigned
Relays
A1 Not assigned
A2 Terminal 30 voltage supply relay -J317- (109)
A3 Automatic glow period control unit -J179- (475)
A4 Fuel pump relay -J17- (53)
A5 Additional coolant pump relay -J496- (404)
A6 Fuel cooling pump relay -J445- (404)
B1 Not assigned
B2 Not assigned
B3 Not assigned
B3 Not assigned
B4 Not assigned
B5 Not assigned
B6 Not assigned
C19 Tank circuit pressurisation relay -J715- (404) (Only auxiliary coolant heater)
C20 Terminal 50 voltage supply relay -J682- (433)
1) Only models for tropical climate zones and models with towing coupling

Engine compartment relay & fuse box (3.0l (V6) diesel engine)

Fuse Box diagram

Volkswagen Touareg - fuse and relay box diagram - engine compartment relay & fuse box (3.0 l (V6) diesel engine)
Volkswagen Touareg – fuse and relay box diagram – engine compartment relay & fuse box (3. l (V6) diesel engine)



Assignment of the fuses in the Engine compartment (3.0L (V6) diesel engine))

No.
 A
 Function/component
1 60
301)		 J293 – Radiator fan control unit
2 30 J671 – Radiator fan control unit 2
3 – Not assigned
4 80 J360 – High heat output relay3)
5 40 J359 – Low heat output relay3)
6 – Not assigned
7 15 N276 – Fuel pressure regulating valve
N290 – Fuel metering valve
J17 – Fuel pump relay3)
8 – Not assigned
9 30 J248 – Diesel direct injection system control unit
J623 – Engine control unit
10 10 G65 – High-pressure sender
J17 – Fuel pump relay
J179 – Automatic glow period control unit
J255 – Climatronic control unit
J293 – Radiator fan control unit
J301 – Air conditioning system control unit
J338 – Throttle valve module3)
J442 – Alternator cut-in relay2)
J445 – Fuel cooling pump relay
J496 – Additional coolant pump relay
J671 – Radiator fan control unit 2
J724 – Turbocharger 1 control unit
J865 – Control unit for charge air cooler bypass3)
N18 – Exhaust gas recirculation valve
N280 – Air conditioner compressor regulating valve
N345 – Exhaust gas recirculation cooler changeover valve
N381 – Exhaust gas recirculation cooler changeover valve 23)
N428 – Valve block 2 in front passenger side rear seat3)
V157 – Intake manifold flap motor
V275 – Intake manifold flap 2 motor
V400 – Pump for exhaust gas recirculation cooler3)
11 15 J445 – Fuel cooling pump relay3)
J832 – Relay for supplementary fuel pump3)
V166 – Fuel cooling pump3)
V393 – Supplementary fuel pump3)
12 10 J496 – Additional coolant pump relay
13 25
203)		 G6 – Fuel system pressurisation pump
G23 – Fuel pump
J17 – Fuel pump relay3)
J445 – Fuel cooling pump relay
J715 – Tank circuit pressurisation relay
V166 – Fuel cooling pump
14 15 G698 – Evaluation unit for reducing agent level3)
N473 – Reversing valve for reducing agent3)
V437 – Reducing agent pump3)
Z103 – Heater for reducing agent pump3)
15 10 J317 – Terminal 30 voltage supply relay
J623 – Engine control unit3)
16 30 J891 – Control unit for reducing agent heater
17 20
151)		 J583 – NOx sensor control unit3)
J881 – NOx sensor 2 control unit3)
G39 – Lambda probe
Z19 – Lambda probe heater
18 – Not assigned
Relays
A1 Not assigned
A2 Terminal 30 voltage supply relay -J317- (219) / (643) optional installation
A3 Automatic glow period control unit -J179- (475) / (639) / (647) optional installlation
A4 Not assigned
A5 Additional coolant pump relay -J496- (404 / (449) optional installation
A6 Fuel cooling pump relay -J445- (404) / (449) optional installation
B1 Not assigned
B2 Fuel pump relay -J17- (53)
B3 Not assigned
B3 High heat output relay -J360- (100)
B4 Low heat output relay -J359- (100)
B5 Not assigned
B6 Supplementary fuel pump relay -J832- (449)
C19 Tank circuit pressurisation relay -J715- (404) (Only auxiliary coolant heater)
C20 Terminal 50 voltage supply relay -J682- (433)
1) Depends on equipment
2) Up to May 2007
3) Only models with engine code CATA

Engine compartment relay & fuse box (5.0 l (V10) TDI engine)

Fuse Box Diagram

Volkswagen Touareg - fuse and relay box diagram - engine compartment relay & fuse box (5.0 l (V10) TDI engine)
Volkswagen Touareg – fuse and relay box diagram – engine compartment relay & fuse box (5.0 l (V10) TDI engine)



Assignment of the fuses in the Engine compartment (5.0L (V10) TDI engine))

No.
 A
 Function/component
1 60 J293 – Radiator fan control unit
2 601)
30		 J671 – Radiator fan control unit 2
V177 – Radiator fan 2
3 – Not assigned
4 – Not assigned
5 – Not assigned
6 60 J701 – Voltage supply relay 1
7 10 J708 – Residual heat relay
J496 – Additional coolant pump relay
J445 – Fuel cooling pump relay
V166 – Fuel cooling pump
8 30 J624 – Engine control unit 2
9 30 J623 – Engine control unit
10 10 G65 – High-pressure sender
J17 – Fuel pump relay
J293 – Radiator fan control unit
J671 – Radiator fan control unit 2
N345 – Exhaust gas recirculation cooler changeover valve
N381 – Exhaust gas recirculation cooler changeover valve 2
V336 – Metering pump for post-injection in particulate filter for cylinder bank 12)
V337 – Metering pump for post-injection in particulate filter for cylinder bank 22)
11 15 F265 – Map-controlled engine cooling system thermostat
J255 – Climatronic control unit
J724 – Turbocharger 1 control unit
J725 – Turbocharger 2 control unit
N280 – Air conditioner compressor regulating valve
V135 – Particulate filter additive pump2)
V157 – Intake manifold flap motor
V275 – Intake manifold flap 2 motor
V280 – Turbocharger 1 control motor
V281 – Turbocharger 2 control motor
12 5 J179 – Automatic glow period control unit
J445 – Fuel cooling pump relay
J496 – Additional coolant pump relay
J703 – Glow period control unit 2
13 253)
30		 G6 – Fuel system pressurisation pump
G23 – Fuel pump
J17 – Fuel pump relay
J715 – Tank circuit pressurisation relay3)
14 – Not assigned
15 10 J317 – Terminal 30 voltage supply relay
16 10 J581 – Battery parallel circuit relay
17 20 G39 – Lambda probe
G108 – Lambda probe 2
Z19 – Lambda probe heater
Z28 – Lambda probe heater 2
18 – Not assigned
Relays
A1 Glow period control unit 2 -J703- (475)
A2 Terminal 30 voltage supply relay 2 -J689- (219)
A3 Automatic glow period control unit -J179- (475)
A4 Not assigned
A5 Additional coolant pump relay -J496- (404)
A6 Fuel cooling pump relay -J445- (404)
B1 Terminal 30 voltage supply relay -J317- (219)
B2 Fuel pump relay -J17- (53)
B3 Not assigned
B3 Not assigned
B4 Voltage supply relay 1 -J701- (100) / (370) optional installation
B5 Not assigned
B6 Not assigned
C19 Tank circuit pressurisation relay -J715- (404) (Not for American markets)
C20 Terminal 50 voltage supply relay -J682- (433)
1) Only models for tropical climate zones and models with towing coupling
2) Only American markets
3) Not American markets

Engine compartment relay & fuse box (3.2 l (V6) petrol engine)

Fuse Box Diagram

Volkswagen Touareg - fuse box diagram - engine compartment relay & fuse box (3.2 l (V6) petrol engine)
Volkswagen Touareg – fuse box diagram – engine compartment relay & fuse box (3.2 l (V6) petrol engine)



Assignment of the fuses in the Engine compartment (3.2L (V6) petrol engine)

No.
 A
 Function/component
1 60 J293 – Radiator fan control unit
2 30 J671 – Radiator fan control unit 2
3 40 V101 – Secondary air pump motor
4 – Not assigned
5 – Not assigned
6 – Not assigned
7 20 N30 – Injector, cylinder 1
N31 – Injector, cylinder 2
N32 – Injector, cylinder 3
N70 – Ignition coil 1 with power output stage
N127 – Ignition coil 2 with power output stage
N291 – Ignition coil 3 with power output stage
8 20 N33 – Injector, cylinder 4
N83 – Injector, cylinder 5
N84 – Injector, cylinder 6
N292 – Ignition coil 4 with power output stage
N323 – Ignition coil 5 with power output stage
N324 – Ignition coil 6 with power output stage
9 30 J220 – Motronic control unit
N156 – Variable intake manifold changeover valve
N205 – Inlet camshaft control valve 1
N318 – Exhaust camshaft control valve 1
10 10 G65 – High-pressure sender
J293 – Radiator fan control unit
J569 – Brake servo relay
J671 – Radiator fan control unit 2
N80 – Activated charcoal filter solenoid valve 1
N115 – Activated charcoal filter solenoid valve 2
V144 – Fuel system diagnostic pump
11 15 G266 – Oil level and oil temperature sender
J255 – Climatronic control unit
N280 – Air conditioner compressor regulating valve
12 5 J299 – Secondary air pump relay
J496 – Additional coolant pump relay
13 15 G23 – Fuel pump
14 15 G6 – Fuel system pressurisation pump
15 10 J17 – Fuel pump relay
J49 – Electric fuel pump 2 relay
J220 – Motronic control unit
J271 – Motronic current supply relay
J670 – Motronic current supply relay 2
16 15 V192 – Vacuum pump for brakes
17 15 G39 – Lambda probe
G108 – Lambda probe 2
18 7.5 G130 – Lambda probe after catalytic converter
G131 – Lambda probe 2 after catalytic converter
Relays
A1 Terminal 30 voltage supply relay 2 -J689- (53)
A2 Not assigned
A3 Terminal 30 voltage supply relay -J317- (167
A4 Secondary air pump relay -J299- (100) / (370) optional installation
A5 Additional coolant pump relay -J496- (404)
A6 Fuel pump relay -J17- (53)
B1 Not assigned
B2 Not assigned
B3 Not assigned
B3 Not assigned
B4 Not assigned
B5 Not assigned
B6 Brake servo relay -J569- (404) (Only models with automatic gearbox)
C19 Electric fuel pump 2 relay -J49- (404)
C20 Terminal 50 voltage supply relay -J682- (433)

Engine compartment relay & fuse box (3.6 l (V6) FSI engine)

Fuse Box Diagram

Volkswagen Touarge - fuse and relay box diagram - engine compartment relay & fuse box (3.6 l (V6) FSI engine)
Volkswagen Touarge – fuse and relay box diagram – engine compartment relay & fuse box (3.6 l (V6) FSI engine)



Assignment of the fuses in the Engine compartment (3.6L (V6) FSI engine)

No.
 A
 Function/component
1 60 J293 – Radiator fan control unit
2 301) J671 – Radiator fan control unit 2
V7 – Radiator fan
3 – Not assigned
4 – Not assigned
5 – Not assigned
6 – Not assigned
7 20 N70 – Ignition coil 1 with output stage
N127 – Ignition coil 2 with output stage
N291 – Ignition coil 3 with output stage
8 20 N292 – Ignition coil 4 with output stage
N323 – Ignition coil 5 with output stage
N324 – Ignition coil 6 with output stage
9 30 J623 – Engine control unit
10 10 G65 – High-pressure sender
J293 – Radiator fan control unit
J496 – Additional coolant pump relay
J671 – Radiator fan control unit 21)
V144 – Fuel system diagnostic pump
11 10 J255 – Climatronic control unit
J301 – Air conditioning system control unit
J442 – Alternator cut-in relay2)
N280 – Air conditioner compressor regulating valve
12 10 N80 – Activated charcoal filter system solenoid valve 1
N205 – Inlet camshaft control valve 1
N316 – Intake manifold flap valve
N318 – Exhaust camshaft control valve 1
13 25 J538 – Fuel pump control unit
14 15 N276 – Fuel pressure regulating valve
15 10 J623 – Engine control unit
J271 – Motronic current supply relay
J670 – Motronic current supply relay 2
16 15 J496 – Additional coolant pump relay
17 15 G39 – Lambda probe
G108 – Lambda probe 2
Z19 – Lambda probe heater
Z28 – Lambda probe heater 2
18 7.5 G130 – Lambda probe after catalytic converter
G131 – Lambda probe 2 after catalytic converter
Z29 – Lambda probe 1 heater after catalytic converter
Z30 – Lambda probe 2 heater after catalytic converter
Relays
A1 Not assigned
A2 Not assigned
A3 Motronic current supply relay -J271- (614)
A4 Not assigned
A5 Additional coolant pump relay -J496- (404)
A6 Not assigned
B1 Not assigned
B2 Not assigned
B3 Not assigned
B3 Not assigned
B4 Motronic current supply relay 2 -J670- (614) to May 2007
B5 Not assigned
B6 Not assigned
C19 Not assigned
C20 Terminal 50 voltage supply relay -J682- (433)
1) Only models for tropical climate zones and models with towing coupling
2) Up to May 2007

Engine compartment relay & fuse box (4.2 l (V8) FSI engine)

Volkswagen Touareg - fuse and relay box diagram - Engine compartment relay & fuse box (4.2 l (V8) FSI engine)
Volkswagen Touareg – fuse and relay box diagram – Engine compartment relay & fuse box (4.2 l (V8) FSI engine)



Assignment of the fuses in the Engine compartment (4.2L (V8) FSI engine)

No.
 A
 Function/component
1 60 J671 – Radiator fan control unit 2
V177 – Radiator fan 2
2 601)
30		 J293 – Radiator fan control unit
V7 – Radiator fan
3 40 J299 – Secondary air pump relay
V101 – Secondary air pump motor
4 – Not assigned
5 – Not assigned
6 – Not assigned
7 20 N70 – Ignition coil 1 with output stage
N127 – Ignition coil 2 with output stage
N291 – Ignition coil 3 with output stage
N292 – Ignition coil 4 with output stage
N323 – Ignition coil 5 with output stage
N324 – Ignition coil 6 with output stage
N325 – Ignition coil 7 with output stage
N326 – Ignition coil 8 with output stage
8 – Not assigned
9 30 J623 – Engine control unit
10 10 G70 – Air mass meter
G246 – Air mass meter 2
J299 – Secondary air pump relay
N80 – Activated charcoal filter solenoid valve 1
V144 – Fuel system diagnostic pump
11 – Not assigned
12 20 F265 – Map-controlled engine cooling system thermostat
G65 – High-pressure sender
J151 – Continued coolant circulation relay
J255 – Climatronic control unit
J301 – Air conditioning system control unit
J293 – Radiator fan control unit
J442 – Alternator cut-in relay2)
J671 – Radiator fan control unit 2
N205 – Inlet camshaft control valve 1
N208 – Inlet camshaft control valve 2
N280 – Air conditioner compressor regulating valve
N318 – Exhaust camshaft control valve 1
N319 – Exhaust camshaft control valve 2
V157 – Intake manifold flap motor
V183 – Variable intake manifold motor
13 25 J538 – Fuel pump control unit
14 10 N290 – Fuel metering valve
N402 – Fuel metering valve 2
15 10 J271 – Motronic current supply relay
J623 – Engine control unit
16 15 J569 – Brake servo relay
V192 – Vacuum pump for brakes
17 10 G39 – Lambda probe
G108 – Lambda probe 2
18 10 G130 – Lambda probe after catalytic converter
G131 – Lambda probe 2 after catalytic converter
Relays
A1 Not assigned
A2 Not assigned
A3 Automatic glow period control unit -J179- (475)
A4 Secondary air pump relay -J299- (100) / (370) optional installation
A5 Continued coolant circulation relay -J151- (404)
A6 Not assigned
B1 Not assigned
B2 Not assigned
B3 Not assigned
B3 Not assigned
B4 Engine components current supply relay -J757- (614)
B5 Not assigned
B6 Brake servo relay -J569- (404) (Only models with automatic gearbox)
C19 Not assigned
C20 Terminal 50 voltage supply relay -J682- (433)
1) Only models with towing coupling
2) Up to May 2007

Engine compartment relay & fuse box (6.0 l (W12) petrol engine)

Fuse Box Diagram

Volkswagen Touareg - fuse box diagram - Engine compartment relay & fuse box (6.0l (W12) petrol engine
Volkswagen Touareg – fuse box diagram – Engine compartment relay & fuse box (6.0l (W12) petrol engine



Assignment of the fuses in the Engine compartment (6.0L (W12) petrol engine)

No.
 A
 Function/component
1 60 J671 – Radiator fan control unit 2
V177 – Radiator fan 2
2 601)
30		 J293 – Radiator fan control unit
V7 – Radiator fan
3 40 J299 – Secondary air pump relay
V101 – Secondary air pump motor
4 40 J545 – Secondary air pump relay 2
V189 – Secondary air pump motor 2
5 30 N325 – Ignition coil 7 with output stage
N326 – Ignition coil 8 with output stage
N327 – Ignition coil 9 with output stage
N328 – Ignition coil 10 with output stage
N329 – Ignition coil 11 with output stage
N330 – Ignition coil 12 with output stage
S7 – Fuse in relay plate fuse holder
6 30 N70 – Ignition coil 1 with output stage
N127 – Ignition coil 2 with output stage
N291 – Ignition coil 3 with output stage
N292 – Ignition coil 4 with output stage
N323 – Ignition coil 5 with output stage
N324 – Ignition coil 6 with output stage
S8 – Fuse in relay plate fuse holder
7 10 N85 – Injector, cylinder 7
N86 – Injector, cylinder 8
N299 – Injector, cylinder 9
N300 – Injector, cylinder 10
N301 – Injector, cylinder 11
N302 – Injector, cylinder 12
8 10 N30 – Injector, cylinder 1
N31 – Injector, cylinder 2
N32 – Injector, cylinder 3
N33 – Injector, cylinder 4
N83 – Injector, cylinder 5
N84 – Injector, cylinder 6
9 30 J623 – Engine control unit
J624 – Engine control unit 2
10 10 G65 – High-pressure sender
J255 – Climatronic control unit
J293 – Radiator fan control unit
J301 – Air conditioning system control unit
J442 – Alternator cut-in relay2)
J671 – Radiator fan control unit 2
V144 – Fuel system diagnostic pump
11 15 N80 – Activated charcoal filter solenoid valve 1
N205 – Inlet camshaft control valve 1
N208 – Inlet camshaft control valve 2
N280 – Air conditioner compressor regulating valve
N318 – Exhaust camshaft control valve 1
N319 – Exhaust camshaft control valve 2
12 5 J49 – Electric fuel pump 2 relay
J299 – Secondary air pump relay
J545 – Secondary air pump relay 2
J624 – Engine control unit 2
13 15 G6 – Fuel system pressurisation pump
J17 – Fuel pump relay
14 15 G23 – Fuel pump
J49 – Electric fuel pump 2 relay
15 10 J17 – Fuel pump relay
J271 – Motronic current supply relay
J623 – Engine control unit
J624 – Engine control unit 2
16 15 J496 – Additional coolant pump relay
J569 – Brake servo relay
V51 – Continued coolant circulation pump
V192 – Vacuum pump for brakes
17 30 G39 – Lambda probe
G108 – Lambda probe 2
G285 – Lambda probe 3
G286 – Lambda probe 4
Z19 – Lambda probe heater
Z28 – Lambda probe heater 2
Z62 – Lambda probe heater 3
Z63 – Lambda probe heater 4
18 15 G130 – Lambda probe after catalytic converter
G131 – Lambda probe 2 after catalytic converter
G287 – Lambda probe 3 after catalytic converter
G288 – Lambda probe 4 after catalytic converter
Z29 – Lambda probe 1 heater after catalytic converter
Z30 – Lambda probe 2 heater after catalytic converter
Z64 – Lambda probe 3 heater after catalytic converter
Z65 – Lambda probe 4 heater after catalytic converter
Relays
A1 Not assigned
A2 Not assigned
A3 Motronic current supply relay -J271- (100) / (370) optional installation
A4 Secondary air pump relay -J299- (100) / (370) optional installation
A5 Additional coolant pump relay -J496- (404)
A6 Electric fuel pump 2 relay -J49- (404)
B1 Not assigned
B2 Not assigned
B3 Not assigned
B3 Secondary air pump relay 2 -J545- (100) / (370) optional installation
B4 Not assigned
B5 Not assigned
B6 Brake servo relay -J569- (404) (Only models with automatic gearbox)
C19 Fuel pump relay -J17- (404)
C20 Terminal 50 voltage supply relay -J682- (433)
1) Only models with towing coupling
2) Up to May 2007

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
